17Pictorial index
SEQUOIA_OM_USA_OM0C047UFuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 244
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 244
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 525
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 428
Tire size/inflation pressure . . . . . . . . . . . . . . . . . .
. . . . . . . . . . P. 531
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 336
Checking/rotation/tire pressure warning system . . . . . . . . . . . P. 428
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 493
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 416
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 416
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 526
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 515
Camera
*2
Headlights/parking lights/front side marker lights/
daytime running lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
Front turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 225
Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 236
Stop/tail lights/rear side marker lights . . . . . . . . . . . . . . . . P. 227
Hill-start assist control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 324
Rear turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 225
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 220
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
Light bulbs of the exterior lights for driving
(Replacing method: P. 453, Wattages: P. 532)
*1: If equipped
*2: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”

2254-2. Driving procedures
4
Driving
SEQUOIA_OM_USA_OM0C047U
Turn signal lever
The lever will return to its original position after operation.
Right turn
Lane change to the right (move
the lever partway and release
it)
The right hand signals will flash 3
times.
Lane change to the left (move
the lever partway and release
it)
The left hand signals will flash 3
times.
Left turn
■ Turn signals can be operated when
The engine switch is in ON.
■ If the indicator flashes faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
Operating instructions

4536-3. Do-it-yourself maintenance
6
Maintenance and care
SEQUOIA_OM_USA_OM0C047U
Light bulbs
Check the wattage of the light bulb to be replaced. ( P. 532)
■Rear
You may replace the following bulbs by yourself. The difficulty
level of replacement varies depending on the bulb. If necessary
bulb replacement seems diffic ult to perform, contact your
Toyota dealer.
For more information about replacing other light bulbs, contact
your Toyota dealer.
Preparing for light bulb replacement
Bulb locations
Stop/tail and rear side marker
lights
Rear turn signal lights
Back-up lights Tail lights
License plate light

4546-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C047U■
Stop/tail, rear side marker light
s and rear turn signal lights
Open the back door and remove the cover.
To protect the cover, place a rag between the flathead screwdri ver or
equivalent and cover as shown in the illustrations.
Left side (vehicles without speaker in the luggage)
Replacing light bulbs
1
Right sideLeft side (vehicles with
speaker in the luggage)

4556-3. Do-it-yourself maintenance
6
Maintenance and care
SEQUOIA_OM_USA_OM0C047U
Turn the bulb bases counter-
clockwise.Stop/tail and rear side
marker light
Rear turn signal light
Remove the light bulb. Stop/tail and rear side
marker light
Rear turn signal light
When installing, reverse the steps listed.2
3
4

4596-3. Do-it-yourself maintenance
6
Maintenance and care
SEQUOIA_OM_USA_OM0C047U■
Replacing the following bulbs
If any of the lights listed below has burnt out, have it replac
ed by
your Toyota dealer.
● Headlight low beams
● Headlight high beams
● Front side marker lights
● Daytime running lights
● Parking lights
● Front turn signal lights
● Front fog lights
● Side turn signal lights (if equipped)
● High mounted stoplight
● Outer foot lights (if equipped)
■LED light bulbs
The following lights consist of a number of LEDs. If any LEDs burn out, take
your vehicle to your Toyota dealer to have the light replaced.
●Headlight low beams
● Headlight high beams
● Front side marker lights
● Daytime running lights
● Parking lights
● Front turn signal lights
● Front fog lights
● Side turn signal lights (if equipped)
● High mounted stoplight
● Outer foot lights (if equipped)
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the lens does not indicate a
malfunction. Contact your Toyota dealer for more information in the following
situations:
● Large drops of water have built up on the inside of the lens.
● Water has built up inside the lens.

5328-1. Specifications
SEQUOIA_OM_USA_OM0C047UA: Wedge base bulbs (clear)
B: Wedge base bulbs (amber)
C: Double end bulbs
Light bulbs
Light BulbsBulb No.WTy p e
Exterior Stop/tail and rear side
marker lights
7443 21/5 A
Rear turn signal lights — 21 B
Tail lights 194 3.8 A
Back-up lights 921 16 A
License plate lights 168 5 A
Outer foot light (if equipped) — 5 A
Interior Vanity lights (if equipped) 7065 1.4 C
Personal/interior lights
Front
— 5 A
Center— 5 A
Rear— 5 A
Interior light 7506 5 C
Foot well lighting — 1.4 A
Door courtesy lights 168 5 A

582Alphabetical index
SEQUOIA_OM_USA_OM0C047U
Flat tire...................................... 493
Floor mats .................................. 26
FluidAutomatic transmission......... 529
Brake .................................... 530
Power steering ...................... 530
Washer ................................. 427
Fog lights ................................. 236 Replacing light bulbs............. 459
Switch ................................... 236
Four-wheel drive system .................................... 317
Front passenger occupant
classification system .............. 51
Front personal lights ............... 359
Front seats ............................... 136 Adjustment ............................ 136
Cleaning................................ 404
Correct driving posture ........... 28
Driving position memory ....... 149
Head restraints ..................... 154
Seat heaters ......................... 354
Seat position memory ........... 149
Seat ventilators ..................... 354
Front side marker lights.......... 227 Light switch ........................... 227
Replacing light bulbs............. 459
Front turn signal lights ........... 225 Replacing light bulbs............. 459
Turn signal lever ................... 225
Fuel ........................................... 244 Capacity ................................ 525
Fuel gauge .............................. 94
Fuel pump shut off system.... 471
Information ............................ 533
Refueling............................... 244
Type ...................................... 525
Warning light ......................... 474 Fuel consumption ................... 104
Fuel filler door ......................... 246
Refueling .............................. 244
Fuel pump shut off system..... 471
Fuses ........................................ 450
Garage door opener ................ 387
Gauges ....................................... 94
Glove box ................................. 362
Grocery bag hooks.................. 374
Hands-free system (for cellular phone)
*
Head restraints ........................ 154
Headlights ................................ 227 Automatic High Beam
system .......... ...................... 231
Light switch ........................... 227
Replacing light bulbs ............ 459
Heaters Air conditioning system ....... ................. 342, 350
Outside rear view mirrors ..... 345
Seat heaters ......................... 354
Hill-start assist control ........... 324
Hood ......................................... 416
F
G
H

583Alphabetical index
SEQUOIA_OM_USA_OM0C047U
HooksCargo hooks ......................... 373
Cargo net hooks ................... 373
Grocery bag hooks ............... 374
Retaining hooks (floor mat)..... 26
Horn .......................................... 157
I/M test ...................................... 412
Identification Engine................................... 524
Vehicle .................................. 524
Ignition switch
(engine switch) ...................... 214
Illuminated entry system ........ 360
Immobilizer system ................... 76
Indicators ................................... 91
Initialization Maintenance ......................... 408
Moon roof.............................. 173
Power back window .............. 169
Power windows ..................... 166
Tire pressure warning
system ......... ....................... 430
Inside rear view mirror ............ 158
Instrument panel light
control ...................................... 96
Interior lights............................ 357
Intuitive parking assist............ 290 Function ................................ 290
Warning message ......... 483, 485 Jack
Vehicle-equipped jack .......... 494
Jack handle .............................. 497
Jam protection function Moon roof ............................. 172
Power back door................... 121
Power back window .............. 169
Power windows..................... 166
Keyless entry ........................... 108 Wireless remote control ........ 108
Keys .......................................... 108 Engine switch ....................... 214
Key number plate ................. 108
Keyless entry ........................ 108
Replacing the battery............ 448
Wireless remote control key...................................... 108
Knee airbags .............................. 40
Lane Departure Alert (LDA) .... 268
Language ................................. 100
LATCH anchors ......................... 64
LDA (Lane Departure Alert) .... 268
Lever Auxiliary catch lever.............. 416
Hood lock release lever ........ 416
Shift lever.............................. 220
Turn signal lever ................... 225
Wiper lever ................... 238, 241
License plate lights ................. 227
Light switch ........................... 227
Replacing light bulbs ............ 458
Wattage ................................ 532
Light bulbs Replacing.............................. 453
Wattage ................................ 532
I
J
K
L
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

584Alphabetical index
SEQUOIA_OM_USA_OM0C047U
LightsFog light switch ..................... 236
Front Interior light.................. 359
Headlight switch.................... 227
Illuminated entry system ....... 360
Interior lights list .................... 357
Personal lights ...................... 359
Rear interior light .................. 359
Replacing light bulbs............. 453
Turn signal lever ................... 225
Vanity lights .......................... 378
Wattage ................................ 532
Load capacity........................... 193
Lock steering column ................................... 156
Luggage compartment features .................................. 373
Maintenance Do-it-yourself maintenance ... 413
General maintenance ........... 409
Maintenance data ................. 522
Maintenance requirements ... 407
Reset the maintenance data .................................... 408
Malfunction indicator lamp ..... 472
Master warning light........ 474, 481
Meter ........................................... 94 Indicators ................................ 91
Instrument panel light control................................... 96
Meters ..................................... 94
Multi-information display ......... 98
Warning lights ......................... 89 Mirrors
Inside rear view mirror .......... 158
Outside rear view mirror
defoggers ........................... 345
Outside rear view mirrors ..... 161
Vanity mirrors ....................... 378
Moon roof ................................. 171 Door lock linked moon roof
operation ............................ 173
Jam protection function ........ 172
Operation .............................. 171
MP3 disc
*
Multi-information display.......... 98 Drive information .................... 99
Language.............................. 100
LDA (Lane Departure Alert)................................... 268
PCS (Pre-Collision system)......... ...................... 255
Settings................................. 100
Warning message................. 481
Navigation system
*
Noise from under vehicle ........... 8
Odometer ................................... 94
Off-road precaution s ............... 331
Oil Differential oil ........................ 529
Engine oil ...................... 418, 526
Transfer oil............................ 529
Opener
Back door ............................. 120
Fuel filler door ....................... 246
Hood ..................................... 416
M
N
O
