Page 3 of 628
3TABLE OF CONTENTS
Owners Manual_USA_M0C043_en
1
2
3
4
5
6
7
8
9
3-5. Opening, closing the win- dows and moon roof
Power windows ............. 174
Moon roof ...................... 177
Panoramic moon roof.... 180
4-1. Before driving Driving the vehicle......... 187
Cargo and luggage ....... 194
Vehicle load limits ......... 197
Trailer towing................. 198
Dinghy towing ............... 211
4-2. Driving procedures Power (ignition) switch .. 212
Automatic transmission . 217
Turn signal lever............ 221
Parking brake ................ 222
Brake Hold .................... 225
4-3. Operating the lights and wipers
Headlight switch ............ 228
Fog light switch ............. 231
AHB (Automatic High Beam) .................................... 231
Light bar ........................ 235
Windshield wipers and washer......................... 235
Rear window wiper and washer......................... 239
4-4. Refueling Opening the fuel tank cap.................................... 2414-5. Using the driving support
systems
Toyota Safet y Sense 2.5244
PCS (Pre-Collision System) .................................... 249
LTA (Lane Tracing Assist) .................................... 261
RSA (Road Sign Assist). 272
Dynamic radar cruise control with full-speed range ... 275
BSM (Blind Spot Monitor) .................................... 286
Intuitive parking assist ... 294
RCTA (Rear Cross Traffic Alert) ............................ 301
PKSB (Parking Support Brake) .......................... 307
Parking Support Brake func- tion (static objects) ...... 312
Parking Support Brake func- tion (rear-crossing vehicles)
.................................... 315
Panoramic view monitor 317
Multi-terrain Monitor ...... 352
Electronically modulated air suspension .................. 363
Driving mode s elect switch
.................................... 366
Four-wheel drive system 369
AUTO LSD system ........ 37
1
Re ar dif
ferential lock system
.................................... 372
Crawl Control................. 373
Multi-terrain Select ........ 377
4Driving
Page 5 of 628
5TABLE OF CONTENTS
Owners Manual_USA_M0C043_en
1
2
3
4
5
6
7
8
9
7-1. Essential information Emergency flashers ...... 502
If your vehicle has to be stopped in an emergency.................................... 502
If the vehicle is submerged or water on the road is rising.................................... 503
7-2. Steps to take in an emer- gency
If your vehicle needs to be towed........................... 505
If you think something is wrong .......................... 507
If a warning light turns on or a warning buzzer sounds 509
If a warning message is dis- played.......................... 519
If you have a flat tire...... 523
If the hybrid system will not start ............................. 532
If you lose your keys ..... 534
If the fuel door cannot be opened ........................ 534
If the electronic key does not operate properly .......... 535
If the vehicle 12-volt battery is discharged................... 538
If your vehicle overheats 543
If the vehicle becomes stuck .................................... 5468-1. Specifications
Maintenance data (fuel, oil level, etc.) .................... 548
Fuel information............. 558
Tire information ............. 560
8-2. Customization Customizable features... 570
8-3. Initialization Items to initialize ............ 581
9-1. For owners Reporting safet y defects for
U.S. owners ................. 584
Reporting safet y defects for
Canadian owners ........ 584
Seat belt instructions for Canadian owners (in
French) ........................ 585
SRS airbag instructions for Canadian owners (in
French) ........................ 587
What to do if... (Troubleshoot- ing) .............................. 596
Alphabetical Index ......... 599
7When trouble arises8Vehicle specifications
9For owners
Index
Page 18 of 628
18Pictorial index
Owners Manual_USA_M0C043_en
Power switch ................................................... ................... P.212
Starting the hybrid system/changing the modes .................. P. 2 1 2
Emergency stop of the hybrid system ............................ ...... P.502
When the hybrid system will not start .......................... ........ P.532
Warning messages ............................................... ............... P.519
Multimedia system
*1
Air conditioning system ............................. ....................... P.406
Usage................................................................................... P.406
Rear window defogger ........................................... .............. P.408
Shift lever.................................................... ........................ P.217
Changing the shift position.................................... ............... P.218
Precautions for towing .. ....................................... ................ P.505
When the shift lever does not move............................. ........ P.218
Tilt and telescopic st eering control switch
*2/tilt and telescopic
steering lock release lever
*2P.158
Adjustment ..................................................... ...................... P.158
Driving position memory
*2.................................................... P.152
Hood lock release lever ........................................ ............. P.464
*1: Refer to “MULTIMEDIA OWNER’S MANUAL”.
*2: If equipped
Page 20 of 628
20Pictorial index
Owners Manual_USA_M0C043_en
Trailer brake control switc h .............................................. P.388
Light bar switch
*............................................................... .P.235
*: If equipped
Front-wheel drive control switch
*..................................... P.369
“DRIVE MODE” switch ...................................................... P.366
“TOW HAUL” switch .............................................. ............ P.220
Mode select switch .................................... P.220, 36 6, 373, 377
“MTS” switch
*............................................................... ...... P.377
“DAC/CRAWL” switch
*...................................................... P.373
Trailer Backup Guide switch
*............................................ P.391
Camera switch .................................................. .................. P.319
VSC OFF switch ................................................. ................ P.384
Emergency flasher switch ....................................... .......... P.502
Height control mode select switch
*.................................. P.363
Height control switch
*....................................................... P.363
Rear differential lock switch
*............................................ P.372
Brake hold switch .............................................. ................ P.225
Page 31 of 628
311-1. For safe use
Owners Manual_USA_M0C043_en
1
For safety and security
1 To fasten the seat belt, push the plate into the buckle until
a click sound is heard.
2 To release the seat belt,
press the release button .
If the seat belt cannot be pulled out
of the retractor, firmly pull the belt
and release it.
■Emergency locking retractor
(ELR)
The retractor will lock the belt during
a sudden stop or on impact. It may
also lock if you lean forward too
quickly. A slow, easy motion will
allow the belt to extend so that you
can move around fully.
■Automatic locking retractor
(ALR)
When a passenger’s shoulder belt is
completely extended and then
retracted even slightly, the belt is
locked in that position and cannot
be extended. This feature is used to
hold the child restraint system
(CRS) firmly. To free the belt again,
fully retract the belt and then pull the
belt out once more. ( P. 5 4 )
■After using the seat belts on the
second seats (8-passenger
models)
Stow the seat belt buckle in the
pockets.
WARNING
●Do not wear the seat belt
extender if you can fasten the
seat belt without the extender.
●Do not use the seat belt
extender when installing a child
restraint system because the
belt will not securely hold the
child restraint system, increas-
ing the risk of death or serious
injury in the event of an acci-
dent.
●The personalized extender may
not be safe on another vehicle,
when used by another person,
or at a different seating position
other than the one originally
intended.
NOTICE
■When using a seat belt
extender
When releasing the seat belt,
press on the buckle release but-
ton on the extender, not on the
seat belt.
This helps prevent damage to the
vehicle interior and the extender
itself.
Fastening and releasing
the seat belt (except for
the third row center seat)
Page 33 of 628
331-1. For safe use
Owners Manual_USA_M0C043_en
1
For safety and security
the buckle until a clicking
sound is heard.
Plate A
Plate B
Buckle 1
To release the hooked
buckle, push the buckle
release button .
2 Insert the mechanical key
( P.112) or plate B into the
notch of buckle and remove
the belt.
Retract the belt slowly when releas-
ing and stowing the seat belt.
Mechanical key
Plate B
Buckle
3 Stow in the holder in the
order of plate B and then
plate A.
In order to securely fix it, firmly
WARNING
■When using the s eat belt for
the third row center seat
Do not use the seat belt for the
third row center seat with either
buckle released. Fastening only
one of the buckles may result in
death or serious injury in case of
sudden braking or a collision.
Releasing and stowing
the seat belt (for the third
row center seat)
Page 34 of 628
341-1. For safe use
Owners Manual_USA_M0C043_eninsert it to the back.
Plate A
Plate B
4 Stow the seat belt buckle in
the pocket.
■Emergency locking retractor
(ELR)
The retractor will lock the belt during
a sudden stop or on impact. It may
also lock if you lean forward too
quickly. A slow, easy motion will
allow the belt to extend so that you
can move around fully.
■Automatic locking retractor
(ALR)
When a passenger’s shoulder belt is
completely extended and then
retracted even slightly, the belt is
locked in that position and cannot
be extended. This feature is used to
hold the child restraint system
(CRS) firmly. To free the belt again,
fully retract the belt and then pull the
belt out once more. ( P. 5 4 )
1Push the seat belt shoulder
anchor down while pressing
the release button .
2 Push the seat belt shoulder
anchor up while pressing the
release button .
Move the height adjuster up and
down as needed until you hear a
click.
Adjusting the seat belt
shoulder anchor height
(front seats)
Page 44 of 628
441-1. For safe use
Owners Manual_USA_M0C043_en
WARNING
●Do not sit on the edge of the
seat or lean against the dash-
board.
●Do not allow a child to stand in
front of the SRS front passenger
airbag unit or sit on the knees of
a front passenger.
●Do not allow the front seat occu-
pants to hold items on their
knees.
●Do not lean against the door,
the roof side rail or the front,
side and rear pillars.
●Do not allow anyone to kneel on
the passenger seats toward the
door or put their head or hands
outside the vehicle.
●Do not attach anything to or
lean anything against areas
such as the dashboard, steering
wheel pad and lower portion of
the instrument panel.
These items can become pro-
jectiles when the SRS driver,
front passenger and knee air-
bags deploy.
●Do not attach anything to areas
such as a door, windshield, side
windows, front or rear pillar, roof
side rail and assist grip.
Page 63 of 628
631-2. Child safety
Owners Manual_USA_M0C043_en
1
For safety and security
High back type
4 Sit the child in the child
restraint system. Fit the seat
belt to the child restraint sys-
tem according to the manu-
facturer’s instructions and
insert the plate into the
buckle. Make sure that the
belt is not twisted.
Check that the shoulder belt is cor-
rectly positioned over the child’s
shoulder and that the lap belt is as
low as possible. ( P.29)
■Removing a child restraint
system installed with a seat
belt
Press the buckle release button
and fully retract the seat belt.
When releasing the buckle, the
child restraint system may spring
up due to the rebound of the seat
cushion. Release the buckle while
holding down the child restraint system.
Since the seat belt automatically
reels itself, slowly return it to the
stowing position.
WARNING
■When installing a child
restraint system
Observe the following precau-
tions.
Failure to do so may result in
death or serious injury.
●Do not allow children to play
with the seat belt. If the seat belt
becomes twisted around a
child’s neck, it may lead to
choking or other serious injuries
that could result in death.
If this occurs and the buckle
cannot be unfastened, scissors
should be used to cut the belt.
●Ensure that the belt and plate
are securely locked and the
seat belt is not twisted.
●Shake the child restraint system
left and right, and forward and
backward to ensure that it has
been securely installed.
●After securing a child restraint
system, never adjust the seat.
Page 73 of 628
731-3. Emergency assistance
Owners Manual_USA_M0C043_en
1
For safety and security
necessary assistance required.
If you accidentally press the “SOS”
button, tell the response-center
agent that you are not experiencing
an emergency.
■Enhanced Roadside Assis-
tance
Enhanced Roadside Assistance
adds GPS data to the already
included warranty-based Toyota
roadside service.
Subscribers can press the
“SOS” button to reach a Safety
Connect response-center agent,
who can help with a wide range
of needs, such as: towing, flat
tire, fuel delivery, etc. For a
description of the Roadside
Assistance services and their
limitations, please see the
Safety Connect Terms and Con-
ditions, which are available at
Toyota.com.
Important! Read this informa-
tion about exposure to radio fre-
quency signals before using
Safety Connect;
The Safety Connect system
installed in your vehicle is a low-
power radio transmitter and
receiver. It receives and also
sends out radio frequency (RF)
signals.
In August 1996, the Federal
Communications Commission (FCC) adopted RF exposure
guidelines with safety levels for
mobile wireless phones. Those
guidelines are consistent with
the safety standards previously
set by the following U.S. and
international standards bodies.
ANSI (American National
Standards Institute) C95.1
[1992]
NCRP (National Council on
Radiation Protection and
Measurement) Report 86
[1986]
ICNIRP (International Com-
mission on Non-Ionizing Radi-
ation Protection) [1996]
Those standards were based on
comprehensive and periodic
evaluations of the relevant sci-
entific literature. Over 120 scien-
tists, engineers, and physicians
from universities, and govern-
ment health agencies and
industries reviewed the avail-
able body of research to
develop the ANSI Standard
(C95.1).
The design of Safety Connect
complies with the FCC guide-
lines in addition to those stan-
dards.
Safety information for
Safety Connect
