buttons TOYOTA SIENNA 2007 XL20 / 2.G Navigation Manual

ii
Important information about
this manual
For safety reasons, this manual indicates
items requiring particular attention with the
following marks.
CAUTION
This is a warning against anything
which may cause injury to people if the
warning is ignored. You are informed
about what you must or must not do in
order to reduce the risk of injury to
yourself and others.
NOTICE
This is a warning against anything
which may cause damage to the ve-
hicle or its equipment if the warning is
ignored. You are informed about what
you must or must not do in order to
avoid or reduce the risk of damage to
your vehicle and its equipment.
INFORMATION
This provides additional information.
Safety Instruction
To use this system in the safest possible
manner, follow all the safety tips shown be-
low.
This system is intended to assist in reaching
the destination and, if used properly, can do
so. The driver is solely responsible for the
safe operation of your vehicle and the safety
of your passengers.
Do not use any feature of this system to the
extent it becomes a distraction and prevents
safe driving. The first priority while driving
should always be the safe operation of the
vehicle. While driving, be sure to observe all
traffic regulations.Prior to the actual use of this system, learn
how to use it and become thoroughly familiar
with it. Read the entire Navigation System
Owner’s Manual to make sure you under-
stand the system. Do not allow other people
to use this system until they have read and
understood the instructions in this manual.
For your safety, some functions may become
inoperable when driving. Unavailable
touch−screen buttons are dimmed. Only
when the vehicle is not moving, can the des-
tination and route selection be done.

v
8“DISPLAY” button
Push this button to display the “Display”
screen. 145. . . . . . . . . . . . . . . . . . . . . . . . . . .
9“OFF”
Touch this touch−screen button to obtain a
broader view. Some of the buttons on the
screen are not displayed. They are dis-
played again by touching “ON”.
84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10Zoom in touchscreen button
Touch this touch−screen button to magnify
the map scale. 15. . . . . . . . . . . . . . . . . . . . .
11Foot print map touchscreen button
Touch this touch−screen button to display
the foot print map and the building informa-
tion. 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12“MAP/VOICE” button
Push this button to repeat a voice guidance,
cancel one touch scroll, start guidance, and
display the current position. 9, 10, 52. . . .
13“DEST” button
Push this button to display the “Destination”
screen. vi, 24. . . . . . . . . . . . . . . . . . . . . . . . .
14Screen configuration touchscreen
button
Touch this touch−screen button to change
the screen mode. 13. . . . . . . . . . . . . . . . . . .
15“MENU” button
Push this button to display the “Menu”
screen. viii, 66, 214. . . . . . . . . . . . . . . . . . . .
16Distance and time to destination
Displays the distance, the estimated travel
time to the destination, and the estimated ar-
rival time at the destination. 52. . . . . . . . . .
17“GPS” mark (Global Positioning
System)
Whenever your vehicle is receiving signals
from the GPS, this mark is displayed.
202 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Speech command system indicator
This indicator is shown by pushing the
speech command switch. The speech com-
mand system can be operated while this in-
dicator is shown. 142. . . . . . . . . . . . . . . . . .

vii
7“Map”
A destination can be selected simply by
touching the location on the displayed map.
40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8“Intersection”
The names of two intersecting streets can be
entered. This is helpful if only the general vi-
cinity, not the specific address, is known.
40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9“Freeway Ent./Exit”
The name of a freeway (interstate) entrance
or exit can be entered. 41. . . . . . . . . . . . . . .
10“?”
Function help for the “Destination” screen
can be viewed on this screen. 8. . . . . . . . .
11“Change”
To change the search area, touch this
touch−screen button. 24. . . . . . . . . . . . . . . .
12Quick access touchscreen buttons
One of 5 preset destinations can be selected
by touching the screen directly. To use this
function, it is necessary to set the “Quick ac-
cess” for each memory point. (To register a
“Quick Access”, see “ — Editing memory
points” on page 71.) 27. . . . . . . . . . . . . . . . .
13Home touchscreen button
A personal home address can be selected
without entering the address each time. To
use this function, it is necessary to set
“Home” for the memory point. (To register
“Home”, see “ — Registering home” on page
75.) 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14“Phone #”
A destination can be entered by the tele-
phone number. 42. . . . . . . . . . . . . . . . . . . . .
15“Coordinates”
A destination can be set by using latitude
and longitude as coordinates. 42. . . . . . . .

4
Touch screen operation
This system is operated mainly by the touch−
screen buttons on the screen.
To prevent damage to the screen, lightly
touch the touchscreen buttons on the
screen with the finger. When a touch
screen button on the screen is touched, a
beep sounds.
Do not use objects other than the finger to
touch the screen.
INFORMATION
If the system does not respond to a
touch on a touchscreen button,
move the finger away from the screen
and then touch it again.
Dimmed touchscreen buttons can-
not be operated.
Wipe off fingerprints on the surface of
the display using a glass cleaning
cloth.
The displayed image may become
darker and moving images may be
slightly distorted when the display is
cold.
Under extremely cold conditions, the
map may not be displayed and the
data input by a user may be deleted.
Also, the touchscreen buttons may
be harder than usual to depress.
When you look at the screen through
polarised material such as polarised
sunglasses, the screen may be dark
and hard to see. If so, change the
angle of the screen or take off your
sunglasses.Inputting letters and
numbers/list screen operation
When searching for an address or a name, or
entering a memo, letters and numbers can be
input via the touch screen.
INFORMATION
Key layout can be changed. (See “ In-
put key layout” on page 82.)

13 DESTINATION INFORMATION
When the cursor is set on a destination icon,
the name and “Info.” are displayed on the top
of the screen.
Touch “Info.”.
Information such as the name, address, and
phone number are displayed.
To delete a destination, touch “Delete”.
If
is touched, the registered tele-
phone number can be called.
— Switching the screens
Any one of the screen configurations can be
selected.
1. Touch this touchscreen button to dis-
play the following screen.
2. To select the desired screen configura-
tion, touch one of the following touch
screen buttons.

14 Depending on the conditions, certain screen
configuration buttons cannot be selected.
:To display the single map screen.
(See page 14.)
:To display the dual map screen. (See
page 14.)
:To display the compass mode
screen. (See page 15.)
:To display the turn list screen. (See
page 50.)
:To display the arrow screen. (See
page 50.)
:To display the freeway information
screen. (See page 48.)
:To display the intersection guidance
screen or the guidance screen on the
freeway. (See page 49.)
Screen configurations
SINGLE MAP
This is a regular map screen.
While on a different screen, touching
will display the single map screen.
The screen shows the single map.DUAL MAP
A map can be displayed split in two.
While on a different screen, touching
will display the dual map screen.
The screen shows the dual map. The map on
the left is the main map.
The right side map can be edited by touching
any specific point on the right side map.

25 SELECTING THE SEARCH AREA ON THE
INPUT SCREEN
Change the search area in order to set a des-
tination from a different area by using “Ad-
dress”, “POI Name”, “Freeway Ent./Exit”, or
“Intersection”.
1. Touch the search area button like
“US9” on the input screen to display a
map of the United States and Canada di-
vided into 11 areas. (For map database in-
formation and updates, see “Map database
information and updates” on page 204.)
2. Touch one of “US1” through “CAN” to
select a search area.
3. Touch “OK” and the previous screen
returns.U.S.A.
ButtonStates included in the search area
“US1”
Idaho
Oregon
Washington
“US2”California
Nevada
“US3”
Arizona
Colorado
Montana
New Mexico
Utah
Wyoming
“US4”
Iowa
Kansas
Minnesota
Missouri
North Dakota
Nebraska
South Dakota
“US5”Oklahoma
Texas
“US6”
Illinois
Indiana
Kentucky
Michigan
Ohio
Wisconsin

27
— Destination search by
Quick access
Touch any of the quick access touch
screen buttons on the “Destination”
screen.
The screen changes and displays the map
location of the quick access point and the
route preference. (See “Starting route guid-
ance” on page 43.)
To use this function, it is necessary to set
“Quick access” for each memory point. (To
register “Quick Access”, see page 73.)
INFORMATION
Guidance starts from the current vehicle
position to the quick access point if “En-
ter” is touched even while driving.
— Destination search by
“Address”
There are 2 ways to input a destination by ad-
dress.
Touch “Address” on the “Destination”
screen.
(a) Inputting a house number and a street
name
1. Touch numerals directly on the screen
to input a house number.
After inputting a house number, touch “OK”
to display the screen for inputting a street
name.
It is possible to input a street name first.
Touch “Street” to display the screen for in-
putting a street name.

36 SETTING THE CURRENT POSITION AS
THE SEARCH POINT
Touch “Current Position”.
The search point is set at the current position,
and the “POI Category” screen will be dis-
played.SETTING THE SEARCH POINT VIA THE
MAP SCREEN
1. Touch “Map”.
When an arrow facing the desired point is
touched, the map scrolls in that direction. Re-
leasing the finger from the arrow will stop the
scrolling
2. Touch “Enter”.
The search point is set and the “POI Catego-
ry” screen will be displayed.SETTING THE SEARCH POINT FROM
DESTINATIONS
1. Touch the destination buttons at the
bottom of the screen.When an arrow facing the desired point is
touched, the map scrolls in that direction. Re-
leasing the finger from the arrow will stop the
scrolling
2. Touch “Enter”.
The search point is set and the “POI Catego-
ry” screen will be displayed.

144 When you touch “Show List”, you can
search another spot in its category.
INFORMATION
In the following conditions, the system
may not recognize the command proper-
ly.
The command is not correct or clear.
There are background noises such as
wind noise, etc.
Help screen
This system has a function which displays
the voice recognition help screen. You
can see the command list and operating
guide on it.
(a) Command List
1. Touch the “Command List” tab on the
upper side of the screen and the touch
screen buttons on the right side of the
screen to select the desired category.
2. You can scroll through the list of the
command list by touching “
” or “”.
Touch “OK” after you check it.(b) Operating Guide
1. Touch the “Operating Guide” tab on
the upper side of the screen and the
touchscreen buttons on the right side of
the screen to select the desired category.
2. You can scroll through the list of the op-
erating guide by touching “
” or “”.
Touch “OK” after you check it.
