display TOYOTA SIENNA 2010 XL30 / 3.G Navigation Manual

OTHER FUNCTIONS
170
You can select the Bluetooth phone
from a maximum of 6 numbers.
“Empty” is displayed when you have not
registered a Bluetooth  phone yet.
Bluetooth  mark is displayed when you
choose the phone.
Although you can register up to 6
Bluetooth  phones in the system, only one
Bluetooth  phone can function at a time.
3. Touch “OK”.
When the result message is displayed, you
can use the Bluetooth  phone. When another Bluetooth
 phone is trying
to connect, this screen is displayed.
Touch “Yes” or “No”.

OTHER FUNCTIONS
171

Displaying Bluetooth
information
You can see or set the information of the
Bluetooth  phone on the system.
“Device Name” The name of Bluetooth  phone
. . . . . .
which is displayed on the screen.
You can change it into a desired
name.
“Bluetooth
∗ Device Address”
The address peculiar to the sys-
. . . . . .
tem. You cannot change it.
1. Select the desired phone and touch
“Information”.
∗: Bluetooth is a registered trademark of
Bluetooth SIG. Inc.
2. Touch “Change”.
3. When you complete the setting,
touch
.

OTHER FUNCTIONS
172

Changing a Device Name
You can change a Device Name. If you
change a Device Name, the name regis-
tered in your cellular phone is not
changed.
1. Touch “Change”.
2. Use the software keyboard to input
the Device name.
Changing the Bluetooth settings
You can change the display and settings of
Bluetooth  information on the system.
The information displays the following
items.
“Device Name” The name in the Bluetooth
. . . . . .
network. You can change it.
“Passkey” The password when you register
. . . . . .
your cellular phone in the sys-
tem. You can change it into the
figure of 4 −8 digits.
“Bluetooth
∗ Device Address”
The address peculiar to the
. . . . . .
system. You can not change it. If
you have registered two
Bluetooth  phones with the
same Device Name or Passkey
and you cannot distinguish one
from the other , refer to it.
∗: Bluetooth is a registered trademark of
Bluetooth SIG. Inc.

OTHER FUNCTIONS
175

Displaying the information of the
Bluetooth
 phone you delete
You can display the information of the
Bluetooth  phone before you delete it
and you can make sure whether the
telephone you delete is correct or not.
1. Select the telephone you want to
display the information about.
2. When you complete confirming it,
touch
. The speech command system enables
you to operate the navigation system
and audio/video system by giving a
command.
1. Push the talk switch.
A beep sounds and on screen message is
displayed with
an indicator at the top left.
Speech command system

OTHER FUNCTIONS
176
2. Say a command while the indicator
is shown on the display.
If you want to check the command list,
touch “Help” to display the help screen.
(See “Help screen” on page 178.) When
you touch “Cancel”, the previous
screen returns.
If the navigation system does not respond
or the confirmation screen does not disap-
pear, please push the talk switch and try
again.
If no command is given, a beep sounds
and the indicator disappears 6 seconds
later.
If the system does not recognize your
speech, the system will respond with this
message (“System does not recognize
this command, please rephrase your com-
mand.”). Start the operation from the be-
ginning.
 Microphone
It is unnecessary to speak directly into
the microphone when giving a com-
mand.

OTHER FUNCTIONS
177
Speech command example: Searching
for a route to your home.
1. Push the talk switch.
2. Say “Home” .
You can also say the street name or ad-
dress.
∗ (ex. say “Woodridge Avenue” .)∗: “Hawaii” or Hawaii area is not covered by
the voice recognition.
If your home is not registered, you will hear
“Home is not registered”.
3. If the system recognized the com-
mand, the recognition result “Home” is
displayed on the top of the screen with
the screen message. (Displayed mes-
sage and the switches on the screen
depend on the situation.)
Touch or say “Cancel”, and the system will
be canceled. T ouch or say “Help”, and dis-
plays the “Help” screen.
4. Touch “Enter” or say “Enter des-
tination” , and the system starts search-
ing for a route to your home. (If the des-
tination is already registered, “Add” or
“Replace” is displayed on the screen.)
Touch or say “Cancel”, and the search will
be canceled.
When you search the destination by
“POI Name”, this screen is displayed.
Touch “Enter” or say “Enter destination” .
When you touch “Show List”, you can
search another spot in its category.

OTHER FUNCTIONS
179
(b) Operating Guide
1. Touch the “Operating Guide” tab on
the upper side of the screen and the
touch screen buttons on the right side
of the screen to select the desired cate-
gory.
2. You can scroll through the list of the
operating guide by touching
or .
Touch “OK” after you check it. You can adjust the brightness, contrast
color
and tone of the screen. You can also
turn the display off, and change the screen
to either day or night mode.
Contrast and brightness adjustment
The brightness and contrast of the screen
can be adjusted depending on the bright-
ness of your surroundings. You can also
turn the display off.
1. Push the “DISPLAY” button.
Screen adjustment

OTHER FUNCTIONS
180
2. Touch the desired button to adjust
contrast and brightness.
“Contrast” “+”:
Strengthens the contrast of the screen.
“Contrast” “”:
Weakens the contrast of the screen.
“Brightness” “+”:
Brightens the screen.
“Brightness” “”:
Darkens the screen.
3. After adjusting the screen, touch
“OK”.
If your vehicle is equipped with the rear
seat entertainment system, the rear
screen turns on or off when “Rear” is
touched.
The screen goes off when “Screen Off” is
touched. To turn the display screen back
on, push any button such as “INFO”, etc.
The selected screen appears.
INFORMATION
When you do not touch any touch
screen button on the “Display”
screen for 20 seconds, the previous
screen will be displayed.
Color and tone adjustment (with rear
seat entertainment system)
The color and tone of the screen can be
adjusted while a DVD video or video CD is
being played.
1. Push the “DISPLAY” button.
2. Touch the desired button to adjust
color and tone.
“Color” “R”:
Strengthens the red color of the screen.
“Color” “G”:
Strengthens the green color of the screen.
“Tone” “+”: Strengthens the tone of the
screen.
“Tone” “”: Weakens the tone of the
screen.
3. After adjusting the screen, touch
“OK”.
The rear screen turns on or off when
“Rear” is touched.
The screen turns off when “Screen Off” is
touched. To turn the screen back on, push
any button such as “INFO” , etc. The se-
lected screen appears.
INFORMATION
When you do not touch any touch
screen button on the “Display”
screen for 20 seconds, the previous
screen will be displayed.

OTHER FUNCTIONS
181

Changing between day mode and
night mode
Depending on the position of the headlight
switch, the screen changes to either day
mode or night mode.
To display the screen in the day mode
even with the headlight switch on,
touch “Day Mode” on the adjustment
screen for brightn ess and contrast con-
trol.
If the screen is set in the day mode with the
headlight switch turned on, this condition is
memorized in the system even with the en-
gine turned off.
1. Push the “INFO” button.
2. Touch “Screen Setting”.
Screen setting

OTHER FUNCTIONS
185
The language of the touch screen but-
tons, popup messages and the voice
guidance can be changed.
1. Push the “INFO” button.
2. Touch “Language”.
3. Touch “English”, “Français” or “Es-
pañol” to select a language. If a screen other than for the navigation
system is displayed, the current screen
would
change to the “CAUTION” screen by
pushing the “MAP/VOICE” , “DEST” or
“MENU” button.
4. Touch “OK”.
The language is changed and the screen
returns to the map display.
Select language
