coolant capacity TOYOTA SIENNA 2010 XL30 / 3.G Owners Manual

546 6-1. Specifications
Cooling system
Ignition system
Electrical system
Capacity
(Reference)12.0 qt. (11.3 L, 10.0 Imp.qt.)
Coolant typeUse either of the following.
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non- silicate, non-amine, non-nitrite, and non-borate
coolant with long-life hybrid organic acid technol-
ogy
Do not use plain water alone.
Spark plug
Make
Gap DENSO FK20HR11
0.043 in. (1.1 mm)
NOTICE
■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust spark plug gap.
Battery
Open voltage at
68 F (20 C): 12.6  12.8 V Fully charged
12.2  12.4 V Half charged
11 . 8
 12.0 V Discharged
(Voltage checked 20 minutes after the engine and
all the lights turned off)
Charging rates 5 A max.

559
6-1. Specifications
6
Vehicle specifications
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or
excessive loading, either sepa-
rately or in combination, can caus e heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

581
Alphabetical index
Emergency, in case of
If the back door opener is
inoperative ........................... 49
If the engine will not start...... 529
If the shift lever cannot be shifted ................................ 530
If the vehicle has discharged battery ................................ 532
If the warning buzzer sounds... ........................... 504
If the warning light turns
on ....................................... 504
If you have a flat tire .... 515, 516
If you lose your keys/ wireless remote control
transmitter .......................... 531
If you think something is
wrong ................................. 500
If your vehicle becomes stuck................................... 539
If your vehicle needs to be towed ................................. 496
If your vehicle overheats ...... 536
Engine Compartment........................ 438
Engine switch ....................... 167
Hood ..................................... 434
How to start the engine ................................ 167
Identification number ............ 543
If the engine will not start...... 529
Ignition switch ....................... 167
Overheating .......................... 536 Engine coolant
Capacity ................................546
Checking ...............................444
Preparing and checking before winter ..................................226
Engine coolan t temperature
gauge ......................................174
Engine immobilizer system.....111
Engine oil
Capacity ................................545
Checking ...............................439
Preparing and checking before winter ..................................226
Engine oil maintenance
data .........................................442
Event data recorder .................502
Floor mat...................................401
Fluid Brake .....................................446
Power steering ......................448
Washer ..................................453
Fog lights Replacing light bulbs .............486
Switch....................................190
Wattage .................................549
Front automatic air conditioning system..............246E
