AUDIO/VIDEO SYSTEM
202
U6058GS
SETUP MENU
There are initial setting touchscreen
buttons on the “Setup Menu” screen.
After you change the initial setting, touch
. The initial setting screen will be
turned off and return to the previous
screen.
When “Default” is touched, all menus are
initialized.
The initial setting can be changed.
Audio language
You can change the audio language.
1. Touch “Audio Language”.
2. Touch the language you want to
hear on the “Audio Language” screen.
If you cannot find the language you want to
hear on this screen, touch “Other” and
enter a language code. For the entry of
language code, see the following “ENTER
AUDIO LANGUAGE CODE”.
To return to the “Setup Menu” screen,
touch the
.
Subtitle language
You can change the subtitle language.
1. Touch “Subtitle Language”.
2. Touch a language you want to read
on the “Subtitle Language” screen.
If you cannot find the language you want to
read on this screen, touch “Other” and
enter a language code. For the entry of
language code, see the following “ENTER
AUDIO LANGUAGE CODE”.
To return to the “Setup Menu” screen,
touch the
.
DVD language
You can change the language on the
DVD video menu.
1. Touch “DVD Language”.
2. Touch the language you want to
read on the “DVD Language” screen.
If you cannot find the language you want to
read on this screen, touch “Other” and
enter a language code. For the entry of
language code, see the following “ENTER
AUDIO LANGUAGE CODE”.
To return to the “Setup Menu” screen,
touch
.

SETUP
263
No.Function
6
Displayed POI icon categories can
be set. (See “ POI category
change (Select POI icons)” on
page 266.)
7
Buttons displayed on the map
screen when “ Off” is touched
can be set. (See “
 Screen layout
function (“ Off” function)” on
page 267.)
8
The current vehicle position mark
can be adjusted manually. Miscal-
culation of the distance caused by
tire replacement can also be ad-
justed. (See “
 Current position/
tire change calibration” on page
267.)
9
Display of pop −up information can
be set to “On” or “Off” . (See “Pop−up information” on the page
269.)
Driving speeds
The speed that is used for the calculation
of the estimated travel time and the esti-
mated arrival time can be set.
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Detailed Navi. Settings” on
the “Navigation Settings” screen.
4. Touch “Driving Speeds”.
5. Touch or to set the average
vehicle speeds for “Residential”, “Main
Streets”, and “Freeways”.
To set the default speeds, touch “De-
fault” .
6. After setting of the desired speeds
is completed, touch “Save”.

INDEX
343
I
If the message “System initializing”
will be displayed 249 . . . . . . . . . . . . . . . . .
If the player malfunctions 178, 209 . . . . . . .
Important information
about this manual 3 . . . . . . . . . . . . . . . . . .
Incoming call display 306 . . . . . . . . . . . . . . . .
INFO/PHONE button 10, 23, 126, 143, 335, 336
. . . . . . . . . . . .
Information about the icon 36
. . . . . . . . . . . .
Information items 318
. . . . . . . . . . . . . . . . . . .
Information screen 23
. . . . . . . . . . . . . . . . . .
Initial screen 26
. . . . . . . . . . . . . . . . . . . . . . . .
Initializing the Bluetooth
audio settings 316
. . . . . . . . . . . . . . . . . . . .
Initializing the Bluetooth
phone settings 305
. . . . . . . . . . . . . . . . . . .
Initializing the detailed phone settings 308
. . . . . . . . . . . . . . . . . . . . . . . . .
Input numbers 28
. . . . . . . . . . . . . . . . . . . . . .
Input symbols 29
. . . . . . . . . . . . . . . . . . . . . . .
Inputting letters and numbers/ List screen operation 28
. . . . . . . . . . . . . .
Inserting discs 166
. . . . . . . . . . . . . . . . . . . . .
Inserting the disc 186
. . . . . . . . . . . . . . . . . . .
Interrupt call 141
. . . . . . . . . . . . . . . . . . . . . . .
Intersection & Freeway button 20, 67 . . . . .
Intersection guidance screen 39, 79 . . . . . .
iPod compatibility 222
. . . . . . . . . . . . . . . . . .
iPod information 222
. . . . . . . . . . . . . . . . . . . .
iPod operation 212
. . . . . . . . . . . . . . . . . . . . .
K
Keyboard layout 252
. . . . . . . . . . . . . . . . . . . .
L
Language 252
. . . . . . . . . . . . . . . . . . . . . . . . .
Last 5 cities 57, 63
. . . . . . . . . . . . . . . . . . . . .
Limitations of the
navigation system 324
. . . . . . . . . . . . . . . .
Line color 252
. . . . . . . . . . . . . . . . . . . . . . . . .
List 29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
List All Categories button 61, 64, 93, 266
. . . . . . . . . . . . . . . . . . . . . .
List screen operation 28
. . . . . . . . . . . . . . . .
Listening to satellite radio 161
. . . . . . . . . . .
Listening to the radio 155
. . . . . . . . . . . . . . .
LOAD·CLOSE button 146, 166, 167, 335
. . . . . . . . . . . . . . . . . .
Local POI list 94
. . . . . . . . . . . . . . . . . . . . . . .
M
Maintenance 316
. . . . . . . . . . . . . . . . . . . . . . .
Maintenance information 27
. . . . . . . . . . . . .
Maintenance information setting 317 . . . . . .
Manage phone 272
. . . . . . . . . . . . . . . . . . . . .
Maneuvering when parking 237
. . . . . . . . . .
Map button 20, 70
. . . . . . . . . . . . . . . . . . . . . .
Map data 336
. . . . . . . . . . . . . . . . . . . . . . . . . .
Map Data button 23, 336
. . . . . . . . . . . . . . .
Map database information and updates 326
. . . . . . . . . . . . . . . . . . . . .
Map DVD 336
. . . . . . . . . . . . . . . . . . . . . . . . .
Map icons 44
. . . . . . . . . . . . . . . . . . . . . . . . . .
Map scale 42
. . . . . . . . . . . . . . . . . . . . . . . . . .
Map screen operation 33
. . . . . . . . . . . . . . . .
MAP/VOICE button 10, 33, 34, 82 . . . . . . . .
Mark button 10, 35
. . . . . . . . . . . . . . . . . . . . .
Marks shown on DVD video discs 210 . . . .
Memory point names 112
. . . . . . . . . . . . . . .
Message button 157
. . . . . . . . . . . . . . . . . . . .
Microphone 46, 123
. . . . . . . . . . . . . . . . . . . .
Mid 152
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MP3 173, 191
. . . . . . . . . . . . . . . . . . . . . . . . .
My places 101
. . . . . . . . . . . . . . . . . . . . . . . . .
N
Names of areas to be avoided 117 . . . . . . .
Navi. button 22, 102, 261 . . . . . . . . . . . . . . .
Navigation settings 102, 261 . . . . . . . . . . . .
Navigation settings screen 102, 261 . . . . . .
Navigation system function index 18 . . . . . .
North−up 10, 43
. . . . . . . . . . . . . . . . . . . . . . . .
North−up symbol 43
. . . . . . . . . . . . . . . . . . . .
O
Off function 10, 262, 267
. . . . . . . . . . . . . . . .
One−touch scroll 34
. . . . . . . . . . . . . . . . . . . .
Operating a Bluetooth
audio player 178
. . . . . . . . . . . . . . . . . . . . .
Operating a DVD video disc 195
. . . . . . . . .
Operating a MP3 disc 191
. . . . . . . . . . . . . . .
Operating a MP3/WMA disc 173
. . . . . . . . .
Operating a video CD 206
. . . . . . . . . . . . . . .
Operating an audio CD 170, 188
. . . . . . . . .
Operating
by voice recognition 141, 280
. . . . . . . . .
OPP (Object Push Profile) 122
. . . . . . . . . . .
Orientation of the map 43
. . . . . . . . . . . . . . .
Overview buttons and guidance screen 10
. . . . . . . . . . . . . .
12/05/16 SIENNA (Mid)_Navi_U
OM45475U

INDEX
344
P
Parental lock
202
. . . . . . . . . . . . . . . . . . . . . .
Pause guidance 91
. . . . . . . . . . . . . . . . . . . . .
Pausing and resuming guidance 91 . . . . . . .
PBAP
(Phone Book Access Profile) 122 . . . . . . .
Phone button 22, 23, 270
. . . . . . . . . . . . . . .
Phonebook 133, 280
. . . . . . . . . . . . . . . . . . .
Playing a Bluetooth  audio 183
. . . . . . . . . .
Playing a disc 169, 188
. . . . . . . . . . . . . . . . .
Playing a DVD disc 197
. . . . . . . . . . . . . . . . .
Playing a MP3 disc 191
. . . . . . . . . . . . . . . . .
Playing a MP3/WMA disc 173
. . . . . . . . . . . .
Playing a USB memory or iPod 212 . . . . . .
Playing a video CD 206
. . . . . . . . . . . . . . . . .
Playing an audio CD 170, 188
. . . . . . . . . . .
POI as a destination 95
. . . . . . . . . . . . . . . . .
POI category change 266
. . . . . . . . . . . . . . .
POI information 36
. . . . . . . . . . . . . . . . . . . . .
Point of Interest button 20, 59
. . . . . . . . . . . .
POIs near the search point 64
. . . . . . . . . . .
POIs to be displayed 93
. . . . . . . . . . . . . . . . .
Pop−up information 262, 269
. . . . . . . . . . . .
Portable audio players 155, 178
. . . . . . . . .
Position/direction calibration 268
. . . . . . . . .
Preset destination 14, 54
. . . . . . . . . . . . . . . .
Preset destination touch screen buttons 20, 54
. . . . . . . . . . . . . . . . . . . . . . .
Presetting a satellite radio channel 162 . . .
Presetting a station 156
. . . . . . . . . . . . . . . . .
Previous Destinations button 20, 65 . . . . . . .
PWR·VOL knob 146, 149
. . . . . . . . . . . . . . .
Q
Quick guide 10
. . . . . . . . . . . . . . . . . . . . . . . .
Quick reference 20, 22, 23, 146
. . . . . . . . . .
R
Radio data system 157
. . . . . . . . . . . . . . . . .
Radio ID 160
. . . . . . . . . . . . . . . . . . . . . . . . . .
Radio operation 155, 160
. . . . . . . . . . . . . . .
RAND button
172, 177, 185, 190, 194, 218
. . . . . . . . . .
RDS 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear system lock 252, 254
. . . . . . . . . . . . . .
Rear view monitor system 232
. . . . . . . . . . .
Rear view monitor system camera 235 . . . .
Receive on the Bluetooth  phone 139 . . . .
Reconnecting the Bluetooth
audio 183
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Reconnecting the Bluetooth
phone 131
. . . . . . . . . . . . . . . . . . . . . . . . . .
Region code 210
. . . . . . . . . . . . . . . . . . . . . . .
Registering a Bluetooth  phone 273 . . . . . .
Registering address book entries 109 . . . . .
Registering areas to avoid 115
. . . . . . . . . . .
Registering home 12, 103
. . . . . . . . . . . . . .
Registering preset destinations 14, 106 . . .
Registering the phonebook data 284 . . . . . .
Registering the speed dial 290
. . . . . . . . . . .
Registering the voice tag 298
. . . . . . . . . . . .
Removing a Bluetooth  audio 313 . . . . . . . .
Reordering destinations 84
. . . . . . . . . . . . . .
Resume guidance 92
. . . . . . . . . . . . . . . . . . .
Ring volume setting 271
. . . . . . . . . . . . . . . .
Route button 10, 84, 85, 86, 87, 89, 91 . . . .
Route guidance 77
. . . . . . . . . . . . . . . . . . . . .
Route guidance screen 78
. . . . . . . . . . . . . .
Route overview 87
. . . . . . . . . . . . . . . . . . . . .
Route preference 89
. . . . . . . . . . . . . . . . . . . .
Route preview 88
. . . . . . . . . . . . . . . . . . . . . .
Route trace 96
. . . . . . . . . . . . . . . . . . . . . . . . .
RPT button
172, 177, 185, 190, 194, 218
. . . . . . . . . .
