4216-2. Using the interior lights
6
Interior features
Turns the lights on/off
When the personal/interior light
main switch is in the off position,
the rear ceiling lights will not turn
on even if the switch is on.
■Adjusting the rear personal/interior lights angle (if equipped)
■ Illuminated entry system
Vehicles without a smart key system
The lights automatically turn on/off according to the engine switch position,
whether the doors are locked/ unlocked, and whether the doors are open/
closed.
Vehicles with a smart key system
The lights automatically turn on/off according to engine switch mode, the
presence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are open/closed.
■ To prevent battery discharge
If the interior lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes.
■ Customization
Settings (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 626)
Rear ceiling lights (if equipped)
Push the edge of the light lens.
NOTICE
■Rear ceiling lights (if equipped)
Do not hang anything on the gap between the ceiling light cover and the
ceiling or pull the ceiling light cover strongly.
Doing so may cause damage.

422
SIENNA_OM_01999-08001_(U)
6-3. Using the storage features
List of storage features
Auxiliary boxes ( P. 430)
Cup holders ( P. 426)
Door pockets ( P. 429) Bottle holders (
P. 428)
Glove boxes ( P. 423)
Console box (if equipped)
(  P. 424)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.
● When driving or when the storage compartments are not in use, keep the
lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
1
2
3
4
5
6

SIENNA_OM_01999-08001_(U)
4236-3. Using the storage features
6
Interior features
Upper glove box
Push the button.
Open the lid.
Lower glove box
The lower glove box can be opened by pulling the lever and can be
locked and unlocked by using th e master key (vehicles without a
smart key) or the mechanical key (vehicles with a smart key system).
Unlock
Lock
Open
Glove boxes
1
2
1
2
3

424
SIENNA_OM_01999-08001_(U)
6-3. Using the storage features
Press the tab.
■Sliding the console box (type B)
From front
From rear
■ Console box light
The console box light turns on when the headlight switch is on.
Console box (if equipped)
Ty p e AType B
Press the tab and slide the console box.
Pull up the lever and slide the console
box.

SIENNA_OM_01999-08001_(U)
4256-3. Using the storage features
6
Interior features
WARNING
■Console box adjustment precaution (type B)
● Do not adjust the position of the console box while the vehicle is moving.
This may cause the driver to mishandle the vehicle and may lead to an
accident that results in death or serious injury.
● Be careful not to get hands or feet pinched between the console box and
the rear sliding console or rear seat.
● Be careful not to allow the console box to hit any passenger while adjust-
ing its position.
● After adjusting the console box, make sure it is securely locked in position.

426
SIENNA_OM_01999-08001_(U)
6-3. Using the storage features
Cup holders
FrontConsole box type A
(if equipped)
Press in and release the front cup
holder.
Console box type B
(if equipped)Console box type C
(if equipped)
Pull the lid down.
Second seat (if equipped)Rear
Removing the second center seat.
(  P. 156)

SIENNA_OM_01999-08001_(U)
4276-3. Using the storage features
6
Interior features
■Cup holder light (console box type)
The cup holder light turns on when the headlight switch is on.
WARNING
Do not place anything other than cups or beverage cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury. If possible, cover hot drinks to prevent
burns.

428
SIENNA_OM_01999-08001_(U)
6-3. Using the storage features
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Bottle holders
FrontRear
II63SN007
WARNING
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
Rear: Make sure items in the sliding door bottle holder will not interfere with
the motion of the door before operating the door. Items that protrude from
the bottle holder may prevent door opening or damage the vehicle.

SIENNA_OM_01999-08001_(U)
4296-3. Using the storage features
6
Interior features
Door pockets
FrontRear
NOTICE
Rear: Make sure magazines are not bent
or protruding from the sliding door pock-
ets. Do not insert anything too big so that
the shape of the sliding door pockets is
distorted. Such objects may obstruct the
opening/closing of the sliding doors,
damage the sliding door pockets or the
vehicle body, and may result in a mal-
function.

430
SIENNA_OM_01999-08001_(U)
6-3. Using the storage features
Auxiliary boxes
Ty p e AType B
Push the lid. Push down the knob.
Type C (if equipped)Type D
Type E (if equipped)Type F
Lift the lid.
