1703-3. Adjusting the seats
3-3.Adjusting the seats
Manual seat (passenger’s
side only)Seat position adjustment
lever
Seatback angle adjustment
lever
Power seatSeat position adjustment
switch
Seatback angle adjustment
switch
Seat cushion (front) angle
adjustment switch (driver’s
side only)
Vertical height adjustment
switch (driver’s side only)
Lumbar support adjustment
switch (driver’s side only) (if
equipped)
Pelvic support adjustment
(driver’s side only) (if
equipped)
■When adjusting the seat
●Make sure that any surrounding
passengers or objects are not
contacting the seat.
●Take care when adjusting the seat
so that the head restraint does not
touch the ceiling.
Front seats
The seats can be adjusted
(longitudinally, vertically,
etc.). Adjust the seat to
ensure the correct driving
posture.
Adjustment procedure
A
B
A
B
C
D
E
F

1713-3. Adjusting the seats
3
Before driving
■Power easy access system (if
equipped)
The driver’ seat and steering wheel
move in accordance with power
switch mode and the driver’ seat
belt condition. ( P.179)
■Jam protection function (vehi-
cles with driving position mem-
ory)
While the driving position is recalled
or the power easy access system is
operating, if an object is stuck
behind the front sea t, the front seat
will stop and then slightly move for-
ward.
When the jam protection function
operates, the seat stops at a posi-
tion other than the set seat position.
Check the seat position.
WARNING
■When adjusting the seat posi-
tion
●Take care when adjusting the
seat position to ensure that
other passengers are not
injured by the moving seat.
●Do not put your hands under the
seat or near the moving parts to
avoid injury.
Fingers or hands may become
jammed in the seat mechanism.
●Make sure to leave enough
space around the feet so they
do not get stuck.
■Seat adjustment
●To reduce the risk of sliding
under the lap bel t during a colli-
sion, do not recline the seat
more than necessary.
If the seat is too reclined, the lap
belt may slide past the hips and
apply restraint forces directly to
the abdomen, or your neck may
contact the shoulder belt,
increasing the risk of death or
serious injury in the event of an
accident.
Adjustments should not be
made while driving as the seat
may unexpectedly move and
cause the driver to lose control
of the vehicle.
●Manual seat only: After adjust-
ing the seat, make sure that the
seat is locked in position.

1723-3. Adjusting the seats
■Second seat
Except ottoman seat (7-pas-
senger models)Seatback angle adjustment
lever
Seat position adjustment
lever
Except ottoman seat (8-pas-
senger models)Seatback angle adjustment
lever
Seat position adjustment
lever
Ottoman seatSeatback angle adjustment
lever
Seat position adjustment
lever
Ottoman angle adjustment
Rear seats
Reclining adjustments and
folding the seatbacks can
be done with lever opera-
tion.
Adjustment procedure
A
B
A
B
A
B
C

1733-3. Adjusting the seats
3
Before driving
lever
■Third seats
Seatback angle adjustment
strap
■When using the ottoman seats
(vehicles with o ttoman seats)
Adjust the angle of the cushion
while pulling the ottoman angle
adjustment lever.
If necessary, sli de the cushion to
adjust the ottoman to the desired
position.
WARNING
■Seat adjustment
●Be careful that the seat does
not hit passengers or luggage.
●To reduce the risk of sliding
under the lap bel t during a colli-
sion, do not recline the seat
more than necessary. If the seat
is reclined too far, the lap belt
may slide past the hips and
apply restraint forces directly to
the abdomen, or your neck may
contact the shoulder belt,
increasing the risk of death or
serious injury in the event of an
accident.
Adjustments should not be made
while driving as the seat may
unexpectedly move and cause
the driver to lose control of the
vehicle.
■When adjusting the seat posi-
tion or the ottoman (vehicles
with Ottoman seats)
Make sure to leave enough space
around the feet so as not to get
them caught.
■When using the ottoman
(vehicles with Ottoman seats)
●Do not sit on the ottoman. Seat
belts may not be properly worn
which may result in death or
serious injury.
●Stow the ottoman when you get
in and out of the vehicle or when
the ottoman is n ot in use to
avoid stumbling over it.
●Do not use the ottoman feature
when the vehicle is in motion.
The ottoman feature should
only be used when the vehicle
is stationary. If the ottoman fea-
ture is in use during an accident
the lap belt may slide past the
hips. This could also result in
restraint forces being applied to
the abdomen or your neck may
contact the shoulder belt,
increasing the risk of death or
serious injury.

1743-3. Adjusting the seats
■Getting in the vehicle
Pull the seatback angle adjust-
ment lever and fold down the
seatback. The cushion will tip
up. The seat can slide forward.
Move the seat to the frontmost
position.
■Getting out of the vehicle
Pull the strap and fold down the
seatback. The seat can slide for-
ward. The cushion will tip up.
Move the seat to the frontmost position.
Make sure that no passenger is
seated on the second seat before
pulling the strap.
■After passengers have
entered/exited the vehicle
Lift up the seatback. Either fold
cushion down or pull slide lever
to slide seat backward until it
locks.
1 Pull the lock release strap
and fold down the second
center seatback.
Make sure that the head restraint is
in the lowest position.
NOTICE
■To prevent an ottoman mal-
function (vehicles with Otto-
man seats)
●Do not place any objects in the
second passenger footwell that
could prevent the operation of
the ottoman.
●Do not place heavy luggage on
the ottoman.
●Do not place anything under the
ottoman when in use. There is a
possibility that something may
get caught and cause damage
when stowing the ottoman.
Moving a second seat for
third seat access
Removing the second
center seat (8-passenger
models)

1753-3. Adjusting the seats
3
Before driving
2Pull the lock release strap in
front of the cushion to
release the rear latch.
3 Pull the lock release strap
under the seat to remove the
seat.
Retract the cushion leg.
4After detaching the second
center seat, remove it from
the vehicle or store it
securely in the luggage com-
partment.
1 Latch the buckles onto the
anchors.
The cushion leg opens by itself.
2Unfold the seatback and lock
it.
Make sure the seat is locked in
place by trying to shake the seat-
back and lift up the seat cushion.
■Before folding the third
seats
1 Fold the outside head
restraints and lower the cen-
ter head restraint to the low-
Installing the second cen-
ter seat (8-passenger
models)
Folding down the third
seats

1763-3. Adjusting the seats
est position (P.183) and
stow the seat belt buckles.
2 Stow the center seat belt.
( P.38)
■Folding down the third seat-
backs
Pull the “TO RECLINE” strap
and fold down the seatback.
■Returning the third seat-
backs
Pull the “TO RECLINE” strap,
and raise the seatback and the
outside head restraints. Before stowing or returning third
seat, remove any items from the
floor area to prevent interfer-
ence with moving parts.
■Before stowing the third
seats
1 Lower the center head
restraint to the lowest posi-
tion ( P.183) and stow the
seat belt buckles.
2 Stow the center seat belt.
( P.38)
■Stowing the third seats
1 Pull the handle to move the
seat rearward. Then push the
seat down.
The outside head r estraints are
Stowing the third seats

1773-3. Adjusting the seats
3
Before driving
folded automatically.
2Push the seat against the
floor.
Open the flaps.
■Before returning the third
seats
Be sure to move the second
seats forward from the rearmost
position, as they may interfere
with the third seats returning
operation.
■Returning the third seats
1 Return the flaps.
Pull the handle and lift up the seat rearward.
2
Push the seat forward and
then engage the front leg
locks.
Make sure the front and rear legs
are locked securely.
3Raise the seatback and the
outside head restraints.
( P.175)
WARNING
■When folding the rear seat-
backs down
Observe the following precau-
tions. Failure to do so may result
in death or serious injury.
●Do not fold the seatbacks down
while driving.
●Stop the vehicle on level
ground, set the parking brake
and shift the shift lever to P.

1783-3. Adjusting the seats
WARNING
●Do not allow anyone to sit on a
folded seatback or in the lug-
gage compartment while driv-
ing.
●Do not allow child ren to enter
the luggage compartment.
●Be careful not to get any part of
your body pinched by a seat.
■After returning the rear seat-
backs or installing seats
Observe the following precau-
tions. Failure to do so may result
in death or serious injury.
●Make sure the seatback is
securely locked by pushing it
forward and rearward on the
top.
●Check that the seat belts are
not twisted or caught in the
seatback. If the seat belt gets
caught between the seatback’s
securing hook and latch, the
seat belt may be damaged.
●Make sure the seat is locked in
place by trying to shake the
seatback and lift up the seat
cushion.
■After removi ng the second
center seat (8-passenger
models)
●Remove the second center seat
from the vehicle or store it
securely in the luggage com-
partment.
●Do not sit on or place anything
on a seat that has been
removed from the vehicle.
■Stowing the third seats
●Make sure that the seat path is
clear before moving the seat.
Otherwise, injury may result
from contact with, or by being
pinched by parts of the seat.
●Do not sit on the third seat when
it is in the stowed position with
the seatback upright.
NOTICE
■To prevent damage to the
seat
●Avoid putting heavy loads on a
folded seat that is being used as
a temporary table.
●Do not sit on or put heavy loads
on the second center seat that
has been removed from the
vehicle. The metal tips of the
seat leg may be damaged, pre-
venting reinstallation of the
seat.
●The second center seat must be
reinstalled in its original position
(8-passenger models). If it is
installed in the w rong position,
the seat locks or bezels will be
damaged.
●Make sure that the path the seat
will move through is clear before
stowing or returning the third
seat.
●8-passenger models: Be sure to
raise the stowed second center
seat above the outer trim, when
removing from the storage box
of the luggage room.

1793-3. Adjusting the seats
3
Before driving
*: If equipped
When all of the following have
been performed, the driver’s
seat and steering wheel are
automatically adjusted to a posi-
tion that allows driver to enter
and exit the vehicle easily.
NOTICE
■Stowing the seat belt
The seat belts and the buckles
must be stowed before you fold
down the rear seatbacks.
Driving position mem-
ory*
This feature automatically
adjusts the positions of the
driver’s seat, steering
wheel, outside rear view
mirrors and head-up display
(if equipped) to make enter-
ing and exiting the vehicle
easier or to suit your prefer-
ences.
Two different driving posi-
tions can be recorded into
memory.
Each electronic key can be
registered to recall your pre-
ferred driving position.
Enabling easier driver
entry and exit (power easy
access system)
