engine TOYOTA T100 1996 Factory Service Manual

Downloaded from www.Manualslib.com manuals search engine AC0G2−01
− AIR CONDITIONINGEXPANSION VALVE
AC−61
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page AC−60).

Downloaded from www.Manualslib.com manuals search engine AC08H−02
AC−62
− AIR CONDITIONINGWATER VALVE
1996 Author: Date:
1996 TOYOTA T100 (RM449U)
WATER VALVE
ON−VEHICLE INSPECTION
1. WARM UP ENGINE
2. DISCONNECT WATER VALVE CONTROL CABLE
3. INSPECT WATER VALVE OPERATION
(a) Check that warm air blown out the vent when the water valve lever is moved to ”WARM” position.
(b) Check that cool air blown out when the water valve is moved to the ”COOL” position.
If operation is not as specified, replace the water valve.
4. CONNECT WATER VALVE CONTROL CABLE
After connection, adjust the control cable.

Downloaded from www.Manualslib.com manuals search engine AC0G3−01
I04699
I04700
Heater Radiator Pipe
Water Hose
Hose Clip
Lower
Second RidgeUpper
− AIR CONDITIONINGWATER VALVE
AC−63
1996 TOYOTA T100 (RM449U)
REMOVAL
1. DRAIN ENGINE COOLANT FROM RADIATOR
HINT:
It is not necessary to drain out all coolant.
2. DISCONNECT WATER VALVE CONTROL CABLE
FROM WATER VALVE
HINT:
At the time of installation, please refer to the following item.
After installation, adjust the control cable (See page AC−91).
3. DISCONNECT WATER HOSES
(a) Using pliers grip the claws of hose clip and slide the clip
along the hose.
(b) Disconnect the water hose.
HINT:
At the time of installation, please refer to the following item.
Push the water hose onto the heater radiator pipe as far
as second ridge on the pipe.
Push the water hose onto the pipe of water valve pipe as
far as water valve.
4. REMOVE WATER VALVE
Remove the bolt and water valve.

Downloaded from www.Manualslib.com manuals search engine AC0G4−01
AC−64
− AIR CONDITIONINGWATER VALVE
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page AC−63).

Downloaded from www.Manualslib.com manuals search engine N05818
AC0G5−01
− AIR CONDITIONINGBLOWER MOTOR
AC−65
1999 Author: Date:
1996 TOYOTA T100 (RM449U)
BLOWER MOTOR
REMOVAL
REMOVE BLOWER MOTOR
(a) Disconnect the connector.
(b) Remove the 3 screws and blower motor.

Downloaded from www.Manualslib.com manuals search engine AC0G6−01
I02318
1
2
AC−66
− AIR CONDITIONINGBLOWER MOTOR
1996 TOYOTA T100 (RM449U)
INSPECTION
INSPECT BLOWER MOTOR OPERATION
Connect the positive (+) lead from the battery to terminal 1 and
the negative (−) lead to terminal 2, then check that the motor op-
erations smoothly.
If operation is not as specified, replace the blower motor.

Downloaded from www.Manualslib.com manuals search engine AC0G7−01
− AIR CONDITIONINGBLOWER MOTOR
AC−67
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page AC−65).

Downloaded from www.Manualslib.com manuals search engine N05817
AC0G8−01
AC−68
− AIR CONDITIONINGBLOWER RESISTOR
2002 Author: Date:
1996 TOYOTA T100 (RM449U)
BLOWER RESISTOR
REMOVAL
REMOVE BLOWER RESISTOR
(a) Disconnect the connector.
(b) Remove the 2 screws and blower resistor.

Downloaded from www.Manualslib.com manuals search engine AC0G9−01
N09039
1 2
3 4
− AIR CONDITIONINGBLOWER RESISTOR
AC−69
1996 TOYOTA T100 (RM449U)
INSPECTION
INSPECT BLOWER RESISTOR RESISTANCE
Tester connectionConditionSpecified condition
1 − 2 − 3 − 4ConstantContinuity
If continuity is not as specified, replace the blower resistor.

Downloaded from www.Manualslib.com manuals search engine AC0GA−01
AC−70
− AIR CONDITIONINGBLOWER RESISTOR
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page AC−68).
