(b) Clear the DTC.
The following actions will erase the DTCs and freezed
frame data.
(1) Operating the OBD II scan tool (complying with SAE
J1978) or TOYOTA hand−held tester to erase the
codes. (See the OBD II scan tool’s instruction book
for operating instructions.)
(2) Disconnecting the battery terminals or EFI fuse.
NOTICE:
If the TOYOTA hand−held tester switches the ECM from
normal mode to check mode or vice−versa, or if the igni-
tion switch is turned from ON to ACC or OFF during check
mode, the DTCs and freezed frame data will be erased.
4. FAIL−SAFE CHART
If any of the following codes is recorded, the ECM enters fail−safe mode.
DTC No.Fail−Safe OperationFail−Safe Deactivation Conditions
P0100
Ignition timing fixed at 5° BTDC
Injection time fixed
Starting − − − − − − − − 11.6 msec.
CTP switch ON − − − − 3.2 msec.
CTP switch OFF − − − − 6.0 msec.
Returned to normal condition
P0110Intake air temp. is fixed at 20°C (68°F)Returned to normal condition
P0115Engine coolant temp. is fixed at 80°(176°F)Returned to normal condition
P0120VTA is fixed at 0°
Following condition must be repeated at least 2 times
consecutively
When closed throttle position switch is ON:
0.1 V  VTA  0.95 V
P0135
P0141Heater circuit in which an abnormality is detected is
turned offIgnition switch OFF
P0325Max. timing retardationIgnition switch OFF
P0336Fuel cutReturned to normal condition
P1300Fuel cutReturned to normal condition
5. CHECK FOR INTERMITTENT PROBLEMS
HINT:
TOYOTA HAND−HELD TESTER only:
By putting the vehicle’s ECM in check mode, 1 trip detection logic is possible instead of 2 trip detection logic
and sensitivity to detect open circuits is increased. This makes it easier to detect intermittent problems.
(a) Clear the DTC (See step 3).
(b) Set the check mode (See step 3).
(c) Perform a simulation test (See page IN−16).
(d) Check the connector and terminal (See page IN−26).
(e) Handle the connector (See page IN−26).

Downloaded from www.Manualslib.com manuals search engine P00495
Outside
Inside
DI−8
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U)
6. BASIC INSPECTION
When the malfunction code is not confirmed in the DTC check, troubleshooting should be performed in the
order for all possible circuits to be considered as the causes of the problems. In many cases, by carrying
out the basic engine check shown in the following flow chart, the location causing the problem can be found
quickly and efficiently. Therefore, use of this check is essential in engine troubleshooting.
1 Is battery positive voltage 11 V or more when engine is stopped?
NO Charge or replace battery.
YES
2 Is engine cranked?
NO Proceed to page ST−15 and continue to trouble-
shoot.
YES
3 Does engine start?
NO Go to step 7.
YES
4 Check air filter.
PREPARATION:
Remove the air filter.
CHECK:
Visual check that the air filter is not dirty or excessive oily.
HINT:
If necessary, clean the filter with compressed air. First blow from
inside thoroughly, then blow from outside of the filter.
NG Repair or replace.
OK

Downloaded from www.Manualslib.com manuals search engine A00654
DLC1 E1
TE1
SST
− DIAGNOSTICSENGINE (3RZ−FE)
DI−9
1996 TOYOTA T100 (RM449U)
5 Check idle speed.
PREPARATION:
(a) Warm up the engine to normal operating temperature.
(b) Switch off all the accessories.
(c) Switch off the air conditioning.
(d) Shift the transmission into ”N” position.
(e) Connect the OBD II scan tool or TOYOTA hand−held tester to the DLC3 on the vehicle.
CHECK:
Use CURRENT DATA to check the idle speed.
OK:
Idle speed: 750 ± 50 rpm
NG Proceed to problem symptoms table on page
DI−21.
OK
6 Check ignition timing.
PREPARATION:
(a) Warm up the engine to normal operating temperature.
(b) Shift the transmission into ”N” position.
(c) Keep the engine speed at idle.
(d) Using SST, connect terminals TE1 and E1 of the DLC1.
SST 09843−18020
(e) Using a timing light, connect the tester to the No.1 high−
tension cord.
CHECK:
Check the ignition timing.
OK:
Ignition timing: Approx. 5° BTDC at idle
NG Proceed to IGNITION and continue to trouble-
shoot.
OK
Proceed to problem symptoms table on page
DI−21.

Downloaded from www.Manualslib.com manuals search engine A00770
ON
Fuel Return Hose
P25086
DI−10
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U)
7 Check fuel pressure.
PREPARATION:
(a) Be sure that enough fuel is in the tank.
(b) Connect the TOYOTA hand−held tester to the DLC3.
(c) Turn the ignition switch ON and push the TOYOTA hand−
held tester main switch ON.
(d) Use ”ACTIVE TEST” mode to operate the fuel pump.
CHECK:
Check for fuel pressure in the fuel return hose when it is pinched
off.
HINT:
At this time, you will hear a fuel flowing noise.
NG Proceed to page MF−1 and continue to trouble-
shoot.
OK
8 Check for spark.
PREPARATION:
(a) Disconnect the high−tension cord from the spark plug.
(b) Remove the spark plug.
(c) Install the spark plug to the high−tension cord.
(d) Disconnect the injector connector.
(e) Ground the spark plug.
CHECK:
Check if the spark occurs while engine is being cranked.
NOTICE:
To prevent excess fuel being injected from the injectors
during this test, don’t crank the engine for more than 5 ∼ 10
seconds at a time.
NG Proceed to page IG−1 and continue to trouble-
shoot.
OK
Proceed to problem symptoms table on page
DI−21.

Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSENGINE (3RZ−FE)
DI−11
1996 TOYOTA T100 (RM449U)
7. ENGINE OPERATING CONDITION
NOTICE:
The values given below for ”Normal Condition” are representative values, so a vehicle may still be
normal even if its value varies from those listed here. So do not decide whether a part is faulty or not
solely according to the ”Normal Condition” here.
(a) CARB mandated signals.
TOYOTA hand−held tester displayMeasurement ItemNormal Condition*
FUEL SYS #1
Fuel System Bank 1
OPEN: Air−fuel ratio feedback stopped
CLOSED: Air−fuel ratio feedback operating
Idling after warming up: CLOSED
CALC LOAD
Calculator Load:
Current intake air volume as a proportion of max.
intake air volumeIdling: 15.4 − 22.1 %
Racing without load (2,500 rpm): 14.7 − 21.5 %
COOLANT TEMP.Engine Coolant Temp. Sensor ValueAfter warming up: 80 ∼ 95°C (176 ∼ 203°F)
SHORT FT #1Short−term Fuel Trim Bank 10 ± 20 %
LONG FT #1Long−term Fuel Trim Bank 10 ± 20 %
ENGINE SPDEngine SpeedIdling: 650 − 750 rpm
VEHICLE SPDVehicle SpeedVehicle Stopped: 0 km/h (0 mph)
IGN ADVANCEIgnition Advance:
Ignition Timing of Cylinder No.1Idling: BTDC 7 − 13°
INTAKE AIRIntake Air Temp. Sensor ValueEquivalent to Ambient Temp.
MAFAir Flow Rate Through Mass Air Flow Meter
Idling: 2.7 − 3.9 gm/sec.
Racing without load (2,500 rpm):
9.2 − 13.3 gm/sec.
THROTTLE POS
Voltage Output of Throttle Position Sensor
Calculated as a percentage:
0 V →0 %, 5 V →100 %Throttle Fully Closed: 7 − 11 %
Throttle Fully Open: 65 − 75 %
O2S B1, S1Voltage Output of Oxygen Sensor
Bank 1, Sensor 1Idling: 0.1 − 0.9 V
O2FT B1, S1Oxygen Sensor Fuel Trim Bank 1, Sensor 1
(Same as SHORT FT #1)0 ± 20 %
O2S B1, S2Voltage Output of Oxygen Sensor
Bank 1, Sensor 2Driving (50 km/h, 31 mph): 0.1 − 0.9 V
*: If no conditions are specifically stated for ”ldling”, it means the shift lever is at N or P position, the A/C switch
is OFF and all accessory switches are OFF.

Downloaded from www.Manualslib.com manuals search engine DI−12
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U)
(b) TOYOTA Enhanced Signals.
TOYOTA hand−held tester displayMeasurement ItemNormal Condition*
MISFIRE RPMEngine RPM for first misfire rangeMisfire 0: 0 rpm
MISFIRE LOADEngine load for first misfire rangeMisfire 0: 0 g/r
INJECTORFuel injection time for cylinder No.1Idling: 2.5 − 4.3 ms
IAC DUTY RATIOIntake Air Control Valve Duty Ratio
Opening ratio rotary solenoid type IAC valveIdling: 24.8 − 50.0 %
STARTER SIGStarter SignalCranking: ON
CTP SWClosed Throttle Position Switch SignalThrottle Fully Closed: ON
A/C SIGA/C Switch SignalA/C ON: ON
STOP LIGHT SWStop Light Switch SignalStop light switch ON: ON
FC IDLFuel Cut Idle: Fuel cut when throttle valve fully
closed, during decelerationFuel cut operating: ON
FC TAUFuel Cut TAU: Fuel cut during very light loadFuel cut operating: ON
CYL #1, CYL #2, CYL #3, CYL #4Abnormal revolution variation for each cylinder0 %
IGNITIONTotal number of ignition for every 1,000
revolutions0 − 2,000
EGRT GASEGR Gas Temp. Sensor ValueEGR not operating: Temp. between intake air
temp. and engine coolant temp.
EGR SYSTEMEGR System Operating ConditionIdling: OFF
A/C CUT SIGA/C Cut SignalA/C S/W OFF: ON
FUEL PUMPFuel Pump SignalIdling: ON
EVAP (PURGE) VSVEVAP VSV SignalIdling: OFF
TOTAL FT B1Total Fuel Trim Bank 1: Average value for fuel
trim system of bank 1Idling: 0.8 − 1.2 V
O2 LR B1, S1
Oxygen Sensor Lean Rich Bank 1, Sensor 1 Re-
sponse time for oxygen sensor output to switch
from lean to rich
Idling after warming up: 0 − 1,000 msec.
O2 RL B1, S1
Oxygen Sensor Rich Lean Bank 1, Sensor 1 Re-
sponse time for oxygen sensor output to switch
from rich to lean
Idling after warming up: 0 − 1,000 msec.
*: If no conditions are specifically stated for ”ldling”, it means the shift lever is at N or P position, the A/C switch
is OFF and all accessory switches are OFF.

Downloaded from www.Manualslib.com manuals search engine DI0T8−03
− DIAGNOSTICSENGINE (3RZ−FE)
DI−13
1996 TOYOTA T100 (RM449U)
DIAGNOSTIC TROUBLE CODE CHART
SAE CONTROLLED
HINT:
Parameters listed in the chart may not be exactly the same as your reading due to the type of instrument
or other factors.
If a malfunction code is displayed during the DTC check in check mode, check the circuit for that code listed
in the table below. For details of each code, turn to the page referred to under the ’’See Page ’’ for the respec-
tive ’’DTC No.’’ in the DTC chart.
DTC No.
(See Page)Detection ItemTrouble AreaMIL*Memory
P0100
(DI−22)Mass Air Flow Circuit
MalfunctionOpen or short in mass air flow meter circuit
Mass air flow meter
ECM

P0101
(DI−26)Mass Air Flow Circuit
Range/Performance
Problem
Mass air flow meter
P0110
(DI−27)Intake Air Temp. Circuit
MalfunctionOpen or short in intake air temp. sensor circuit
Intake air temp. sensor
ECM

P0115
(DI−33)Engine Coolant Temp. Circuit
MalfunctionOpen or short in engine coolant temp. sensor circuit
Engine coolant temp. sensor
ECM

P0116
(DI−38)Engine Coolant Temp. Circuit
Range/Performance ProblemEngine coolant temp. sensor
Cooling system
P0120
(DI−39)Throttle/Pedal Position
Sensor/Switch ”A” Circuit
MalfunctionOpen or short in throttle position sensor circuit
Throttle position sensor
ECM

P0121
(DI−43)Throttle/Pedal Position
Sensor/Switch ”A” Circuit
Range/Performance Problem
Throttle position sensor
P0125
(DI−44)Insufficient Coolant Temp. for
Closed Loop Fuel ControlOpen or short in heated oxygen sensor (bank 1 sensor 1)
circuit
Heated oxygen sensor (bank 1 sensor 1)

P0130
(DI−47)Heated Oxygen Sensor Circuit
Malfunction (Bank 1 Sensor 1)Heated oxygen sensor
Fuel trim malfunction
P0133
(DI−50)Heated Oxygen Sensor Circuit
Slow Response
(Bank 1 Sensor 1)
Heated oxygen sensor
P0135
(DI−51)Heated Oxygen Sensor Heater
Circuit Malfunction
(Bank 1 Sensor 1)Open or short in heater circuit of heated oxygen sensor
Heated oxygen sensor heater
 ECM

P0136
(DI−53)Heated Oxygen Sensor Circuit
Malfunction
(Bank 1 Sensor 2)
Heated oxygen sensor
P0141
(DI−51)Heated Oxygen Sensor Heater
Circuit Malfunction
(Bank 1 Sensor 2)
Same as DTC No. P0135
*:  MIL lights up

Downloaded from www.Manualslib.com manuals search engine DI−14
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U) DTC No.
(See Page)
Detection ItemTrouble AreaMIL*Memory
P0171
(DI−55)System too Lean
(Fuel Trim)
Air intake (hose loose)
Fuel line pressure
Injector blockage
Heated oxygen sensor (bank 1 sensor 1) malfunction
Mass air flow meter
Engine coolant temp. sensor

P0172
(DI−55)System too Rich
(Fuel Trim)
Fuel line pressure
Injector leak, blockage
Heated oxygen sensor (bank 1 sensor 1) malfunction
Mass air flow meter
Engine coolant temp. sensor

P0300
(DI−58)Random/Multiple Cylinder
Misfire DetectedIgnition system
Injector
Fuel line pressure
EGR
Compression pressure
Valve clearance not to specification
Valve timing
Mass air flow meter
Engine coolant temp. sensor
P0301
P0302
P0303
P0304
(DI−58)Misfire Detected
− Cylinder 1
− Cylinder 2
− Cylinder 3
− Cylinder 4
P0325
(DI−63)Knock Sensor 1 Circuit
MalfunctionOpen or short in knock sensor 1 circuit
Knock sensor 1 (looseness)
ECM

P0335
(DI−66)Crankshaft Position Sensor
”A” Circuit Malfunction
Open or short in crankshaft position sensor circuit
Crankshaft position sensor
Starter
ECM

P0336
(DI−69)Crankshaft Position Sensor
”A” Circuit
Range/PerformanceValve timing
Distributor installation
ECM

P0340
(DI−70)Camshaft Position Sensor
Circuit Malfunction
Open or short in camshaft position sensor circuit
Camshaft position sensor
Distoributor
Starter
ECM

P0401
(DI−72)Exhaust Gas Recirculation
Flow Insufficient Detected
EGR valve stuck closed
Short in VSV circuit for EGR
Open in EGR gas temp. sensor circuit
EGR hose disconnected
ECM

P0402
(DI−82)Exhaust Gas Recirculation
Flow Excessive Detected
EGR valve stuck open
VSV for EGR open malfunction
Open in VSV circuit for EGR
Short in EGR gas temp. sensor circuit
ECM

P0420
(DI−86)Catalyst System Efficiency
Below ThresholdThree−way catalytic convertor
Open or short in heated oxygen sensor circuit
Heated oxygen sensor

*:  MIL lights up

Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSENGINE (3RZ−FE)
DI−15
1996 TOYOTA T100 (RM449U) DTC No.
(See Page)
Detection ItemTrouble AreaMIL*Memory
P0441
(DI−88)Evaporative Emission Control
System Incorrect Purge Flow
Open or short in VSV circuit for EVAP
VSV for EVAP
ECM
Vacuum hose damaged, blocked or disconnected
Charcoal canister

P0500
(DI−92)Vehicle Speed Sensor
Malfunction
Open or short in No.1 vehicle speed sensor circuit
No.1 vehicle speed sensor
ECM
Speedometer cable

P0505
(DI−94)Idle Control System
MalfunctionIAC valve is stuck or closed
Open or short in IAC valve circuit
Air intake (hose loose)

P0510
(DI−97)Closed Throttle Position
Switch MalfunctionOpen in closed throttle position switch circuit
Closed throttle position switch
ECM

*:  MIL lights up
MANUFACTURER CONTROLLED
DTC No.
(See Page)Detection ItemTrouble AreaMIL*Memory
P1300
(DI−103)Igniter Circuit Malfunction
Open or short in IGF or IGT circuit from igniter to ECM
Igniter
ECM

P1335
(DI−109)Crankshaft Position Sensor
Circuit Malfunction
(during engine running)Open or short in crankshaft position sensor circuit
Crankshaft position sensor
ECM
−
P1500
(DI−11 0)Starter Signal Malfunction
Open or short in starter signal
Open or short in ignition switch or starter relay circuit
ECM
−
P1600
(DI−11 2)ECM BATT MalfunctionOpen in back up power source circuit
ECM
P1780
(DI−11 4)Park/Neutral Position Switch
MalfunctionShort in park/neutral position switch circuit
Park/neutral position switch
ECM

*: −  MIL does not light up,  MIL lights up

Downloaded from www.Manualslib.com manuals search engine DI0T9−02
P24451
Camshaft Position
Sensor
(Built into Distributor) DI−16
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U)
PARTS LOCATION
