’00 Tacoma(U)
254
TiresFuses
Engine compartment (without daytime run-
ning light system)
Fuses (type A)
1. PWR OUTLET 15 A: Power outlet
2. DRL 7.5 A: Daytime running light
system
3. HEAD (HI RH) 10 A: Right−hand head-
light (high beam), high beam indicator
light
4. HEAD (HI LH) 10 A: Left−hand head-
light (high beam)
5. HEAD (LO RH) 10 A: Right−hand
headlight (low beam)
Wheel nut torque, N·m (kgf·m, ft·lbf):
110(11.5,83) Tire size
Tire pressure
kPa (kgf/cm
2 or bar, psi) Wheel size
Front Rear
P195/75R14 200(2.0,29) 240(2.4,35) 14 5J
P215/70R14 200(2.0,29) 200(2.0,29) 14
6J
14 6JJ
P225/75R15 180(1.8,26) 200(2.0,29)15
6J
15 7J
15 7JJ
31x10.5R15LT 180(1.8,26) 200(2.0,29) 15
7J
15 7JJ
P265/75R15
180(1.8,26) 180(1.8,26) 15
7J
15 7JJ

’00 Tacoma(U)
255
Engine compartment (with daytime run-
ning light system)
6. HEAD (LO LH) 10 A: Left−hand head-
light (low beam)
7. TAIL 10 A: Tail lights, licence plate
lights
8. PANEL 10 A: Emergency flashers,
heater control system, air conditioning
system, g auges and meters, clock, car
audio system, overdrive indicator light,
glove box light, cigarette lighter, instru-
ment panel lights, rear differential lock
system, Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, electronically controlled automatic
transmission system
Instrument panel
9. A.C 10 A: Air conditioning system
10. STOP 15 A: Stop lights, high mounted
stoplight, cruise control system
11. ALT−S 7.5 A: Charging system
12. DOME 15 A: Car audio system, power
antenna, interior light, clock, ignition
switch light, personal lights, door cour-
tesy lights
13. OBD 10 A: On−board diagnosis system
14. HORN 15 A: Emergency flashers,
horns 15. EFI 20 A:
Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
16. HEAD (RH) 10 A: Right−hand headlight
17. HEAD (LH) 10 A: Left−hand headlight
18. STA 7.5 A: Clutch start cancel system,
starting system, gauges and meters
19. 4WD 20 A: A.D.D. control system,
four−wheel drive control system, rear
differential lock system
20. GAUGE 10 A: Gauges and meters,
back−up lights, cruise control system,
power antenna, power door lock control
system, electronically controlled auto-
matic transmission system, starting
system, charging system, air c ondition-
ing system
21. TURN 10 A: Turn signal lights, emer-
gency flashers
22. ECU−IG 15 A: Cruise control system,
anti−lock brake system, automatic
transmission shift lock system
23. WIPER 20 A: Windshield wipers and
washer
24. IGN 7.5 A: Discharge warning light,
SRS airbag system, seat belt preten-
sioners, multiport fuel injection system/
sequential multiport fuel injection sys-
tem

’00 Tacoma(U)
256
25. RADIO 7.5 A: Car audio system, pow-
er antenna
26. CIG 15 A: Cigarette lighter, clock, pow-
er rear view mirrors, back−up lights,
automatic transmission shift lock sys-
tem, SRS airbag system, seat belt pre-
tensioners
27. ECU−B 15 A: SRS warning light, day-
time running light system, cruise con-
trol system, SRS airbag system, seat
belt pretensioners
Fuses (type B)
28. POWER 30 A: Power windows
29. AM1 40 A: Starting system
30. AM2 30 A: Ignition system
Fuses (type C)
31. ABS 60 A: Anti−lock brake system
32. HEATER 40 A: A.C" fuse
33. ALT 120 A: ABS", AM1", HEATER",
A.C", TAIL", PANEL", STOP" and
ALT−S", PWR OUTLET" fuses

’00 Tacoma(U)
257
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS, UNIFORM TIRE QUALITY
GRADING AND CAMPER INFORMATION
Reporting safety defects for U.S. owners258
. . . . . . . . . . . . . . . . . . . . . .
Uniform tire quality grading 258
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Camper information 259
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
SECTION 9

’00 Tacoma(U)
258
If you believe that your vehicle
has a defect which could cause a
crash or could cause injury or
death, you should immediately in-
form the National Highway Traffic
Safety Administration (NHTSA) in
addition to notifying Toyota Motor
Sales, U.S.A., Inc. (Toll−free:
1−800−331−4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety
defect exists in a group of ve-
hicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved
in individual problems between
you, your dealer, or Toyota Motor
Sales, U.S.A., Inc.To contact NHTSA, you may ei-
ther call the Auto Safety Hotline
toll−free at 1−800−424−9393 (or
366−0123 in Washington,D.C.
area) or write to: NHTSA. U.S.De-
partment of Transportation. Wash-
ington,D.C. 20590. You can also
obtain other information about mo-
tor vehicle safety from the Hotline.This information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality gradesAll passenger ve-
hicle tires must conform to Federal
Safety Requirements in addition to
these grades. These quality grades are
molded on the sidewall.
Treadwear
The treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (1−1/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate.
Reporting safety defects for
U.S. owners Uniform tire quality grading
(except vehicles with 31

10.5R15LT tires)

’00 Tacoma(U)
259
Traction AA, A, B, CThe traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire’s
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction.
Temperature A, B, C The temperature
grades are A (the highest), B, and C,
representing the tire’s resistance to the
generation of heat and its ability to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No.109. Grades B
and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law. Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure.
Camper information
This information has been prepared in ac-
cordance with regulation issued by the Na-
tional Highway Traffic Safety Administra-
tion of the U.S. Department of
Transportation. It provides the purchasers
and/or prospective purchasers of Toyota
vehicles with information on truck−camper
loading. Your Toyota dealer will help an-
swer any questions you may have as you
read this information.

’00 Tacoma(U)
260
Center of gravity location
B
A
Rear end of truck bed
Recommended location
for cargo center of
gravity for cargo
weight rating
Two−wheel drive models
except Pre Runner mm (in.)
AB
Normal cab models1397
(55.0)838
(33.0)
Xtra−cab models
2RZ−FE engine
5VZ−FE engine
1397
(55.0)
1193
(47.0)1016
(40.0)
1066
(42.0)
Four−wheel drive models
and Pre Runner mm (in.)
A
B
1397
(55.0)838
(33.0)
The figures given in the illustration indi-
cate the recommended center of gravity
zone.
CAUTION
If a load is too far back, it can cause
dangerous handling. If it is too far
forward, the front axle may be over-
loaded.
Camper center of gravity
Recommended center of
gravity location zone
Cargo weight rating
Two−wheel drive models
except Pre Runner Normal cab modelsWith 2 occupants 499 kg(1100 lb.)
With 3 occupants
431 kg(950 lb.)
Cargo weight rating and
proper matching

’00 Tacoma(U)
261
Xtra−cab modelsWith 2 occupants in the front
seats and no occupants in the
rear seats 499 kg(1100 lb.)
With 3 occupants in the front
seats and no occupants in the
rear seats 431 kg(950 lb.)
With 3 occupants in the front
seats and 2 occupants in the rear
seats 295 kg(650 lb.)
Four−wheel drive models
and Pre Runner Normal cab models With 2 or 3 occupants 499 kg(1100 lb.) Xtra−cab models
Vehicles with off road packageWith 2 occupants in the front
seats and no occupants in the
rear seats 340 kg(750 lb.)
With 3 occupants in the front
seats and no occupants in the
rear seats 272 kg(600 lb.)
With 3 occupants in the front
seats and 2 occupants in the rear
seats 136 kg300 lb.)
Vehicles without off road package With 2 or 3 occupants in the front
seats and no occupants in the
rear seats
499 kg(1100 lb.)
With 3 occupants in the front
seats and 2 occupants in the rear
seats 318 kg(700 lb.) When the truck is used to carry a slide−in
camper, the total cargo load of the truck
consists of the manufacturer ’s camper
weight figure, the weight of installed addi-
tional camper equipment not included in
the manufacturer ’s camper weight figure,
the weight of camper cargo, and the
weight of passengers in the camper.
The total cargo load should not exceed
the truck’s cargo weight rating and the
camper ’s center of gravity should fall with-
in the truck’s recommended center of
gravity zone when installed.
CAUTION
Be carefuloverloading can cause
dangerous braking and handling prob-
lems, and can damage your vehicle
and its tires.

’00 Tacoma(U)
262
Gross axle weight ratingFront GAWR Rear GAWR
Secure loose items to prevent weight
shifts that could affect the balance of your
vehicle. When the truck camper is loaded,
drive to a scale and weigh on the front
and on the rear wheels separately to de-
termine axle loads. Individual axle loads
should not exceed either of the Gross
Axle Weight Ratings (GAWR). The total of
the axle loads should not exceed the
Gross Vehicle Weight Rating (GVWR).
These raitings are given on the vehicle
Certification Label which is located on the
door latch post on the left side of the
vehicle. See Your Toyota’s identification"
in Section 2 for the Certification Label
location. If weight raitings are exceeded,
move or remove items to bring all weights
below the raitings.
Gross vehicle weight rating
Not exceed GVWR
GAWR
Two−wheel drive models
except Pre RunnerFront 1000 kg(2200 lb.)
Rear 1135 kg(2500 lb.)
Four−wheel drive models
and Pre Runner Front 1200 kg(2650 lb.)
Rear 1270 kg(2800 lb.) GVWR
Two−wheel drive models
except Pre Runner
Normal cab models 1920 kg(4250 lb.)
Xtra−cab models
2040 kg(4500 lb.)
Four−wheel drive models
and Pre Runner 2315 kg(5100 lb.)
If weight ratings are exceeded, move or
remove items to bring all weights below
the ratings.
Gross axle and vehicle
weight ratings

’00 Tacoma(U)
Publication No. OM35751U
Part No. 01999-35751
Printed in Japan 01−9908−00
(U)
Quick index
If a service reminder indicator or warning buzzer comes on 78 . . . . . . . . . .
 If your vehicle will not start 184 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
 If your engine stalls while driving 187 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 If your vehicle overheats 187 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
 If you have a flat tire 188 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
 If your vehicle needs to be towed 198 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Tips for driving during break−in period 155 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 How to start the engine 170 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
 General maintenance 215 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
 Complete index NO TAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher
See page 155 for detailed information.
Fuel tank capacity: Two−wheel drive models except Pre Runner
57 L (15.1 gal., 12.5 lmp. gal.)
Four−wheel drive models and Pre Runner 68 L (18.0 gal., 15.0 lmp. gal.)
Engine oil:
API grade SJ, Energy−Conserving or ILSAC multigrade engine oil
is recommended.
See page 228 for detailed information.
Tire information: See pages 232 through 236.
Tire pressure: See page 254.
fU − 6
I
