TOYOTA TACOMA 2001 Owners Manual (in English)

’01 Tacoma U (L/O 0009)
2952001 TACOMA (OM35766U)
Xtra−cab models with full options’
weight of 85 kg (195 lb.)With 2 occupants in the front
seats and no occupants in the
rear seats 365 kg (815 lb.)
With 3 occupants in the front
seats and no occupants in the
rear seats 350 kg (770 lb.)
With 3 occupants in the front
seats and 2 occupants in the rear
seats 250 kg (550 lb.)
Four−wheel drive models
and Pre Runner Regular cab models with full options’
weight of 120 kg (265 lb.)
With 2 occupants 500 kg (1100 lb.)
With 3 occupants 465 kg (1025 lb.) Xtra−cab models with full options’
weight of 125 kg (280 lb.)
Vehicles with off road package
With 2 occupants in the front
seats and no occupants in the
rear seats 340 kg (750 lb.)
With 2 occupants in the front
seats and 2 occupants in the rear
seats 135 kg (300 lb.)
Vehicles without off road package With 2 occupants in the front
seats and no occupants in the
rear seats 440 kg (975 lb.)
With 3 occupants in the front
seats and no occupants in the
rear seats 370 kg (825 lb.)
With 3 occupants in the front
seats and 2 occupants in the rear
seats 235 kg (525 lb.) When the truck is used to carry a slide−in
camper, the total cargo load of the truck
consists of the manufacturer ’s camper
weight figure, the weight of installed addi-
tional camper equipment not included in
the manufacturer ’s camper weight figure,
the weight of camper cargo, and the
weight of passengers in the camper.
The total cargo load should not exceed
the truck’s cargo weight rating and the
camper ’s center of gravity should fall with-
in the truck’s recommended center of
gravity zone when installed.
CAUTION
Be carefuloverloading can cause
dangerous braking and handling prob-
lems, and can damage your vehicle
and its tires.

’01 Tacoma U (L/O 0009)
2962001 TACOMA (OM35766U)
Gross axle weight ratingFront GAWR Rear GAWR
Secure loose items to prevent weight
shifts that could affect the balance of your
vehicle. When the truck camper is loaded,
drive to a scale and weigh on the front
and on the rear wheels separately to de-
termine axle loads. Individual axle loads
should not exceed either of the Gross
Axle Weight Ratings (GAWR). The total of
the axle loads should not exceed the
Gross Vehicle Weight Rating (GVWR).
These ratings are given on the vehicle
Certification Label which is located on the
door latch post on the left side of the
vehicle. See Your Toyota’s identification"
in Section 2 for the Certification Label
location. If weight ratings are exceeded,
move or remove items to bring all weights
below the ratings.
Gross vehicle weight rating
Not exceed GVWR
GAWR
Two−wheel drive models
except Pre RunnerFront 1000 kg (2200 lb.)
Rear 1135 kg (2500 lb.)
Four−wheel drive models
and Pre Runner Front 1200 kg (2650 lb.)
Rear 1270 kg (2800 lb.) GVWR
Two−wheel drive models
except Pre Runner
Regular cab models 1920 kg (4250 lb.)
Xtra−cab models
2040 kg (4500 lb.)
Four−wheel drive models
and Pre Runner 2315 kg (5100 lb.)
If weight ratings are exceeded, move or
remove items to bring all weights below
the ratings.
Gross axle and vehicle
weight ratings

’01 Tacoma U (L/O 0009)
2001 TACOMA (OM35766U)
Publication No. OM35766U
Part No. 01999-35766
Printed in Japan 01−0009−00
(U)
Quick index
If a service reminder indicator or warning buzzer comes on 116 . . . . . . . . .
 If your vehicle will not start 218 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
 If your engine stalls while driving 221 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 If your vehicle overheats 221 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
 If you have a flat tire 222 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
 If your vehicle needs to be towed 232 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Tips for driving during break−in period 189 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 How to start the engine 204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
 General maintenance 247 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
 Complete index NO TAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher
See page 189 for detailed information.
Fuel tank capacity: Two−wheel drive models except Pre Runner
60 L (16.0 gal., 13.3 lmp. gal.)
Four−wheel drive models and Pre Runner 70 L (18.5 gal., 15.4 lmp. gal.)
Engine oil:
API grade SJ, Energy−Conserving or ILSAC multigrade engine oil
is recommended.
See page 260 for detailed information.
Tire information: See pages 264 through 268.
Tire pressure: See page 287.
fU −7
I

’01 Tacoma U (L/O 0009)
2001 TACOMA (OM35766U)
You should know as much about the quality and
importance of proper main tenance of your new
vehicle as the people who built it.
The Toyota authorized Repair Manual
tells you how to maint ain your vehicle and
enables you to correct ly perform your own
maintenance.
The best way to keep your new vehicle in top
running order is to maintain it properly from
the moment you drive it off the showroom
floor.
The Toyota authorized Repair Manual is
packed with literally everything you need to
know to perform your own maintenance in
virtually every area of your new vehicle.

’01 Tacoma U (L/O 0009)
2001 TACOMA (OM35766U)
Where to obtain the Repair Manual
The repair manual for TOYOTA Tacoma, writ-
ten in English, may be purchased as applicable
fr o m an y Toy o ta dea l er.
P ub . Na m e: 20 0 1 TO Y O TA Tac o m a R ep a i r Manual
Pub. No.: RM835U1 (Maintenance, Preparation, Service specifications
and Diagnostics)
RM835U2 (Engine, Chassis and
Body)
Maintenance procedures for the engine,
chassis, body, electric al system, and more,
are clearly explained and illustrated.
Periodic maintenance and tuneup
Periodic maintenance and tuneup helps to pre-
vent small problems from growing into larger ones lat-
er on. The repair manual outlines exactly what main-
tenance is required and clearly explains how to do the
work yourself stepbystep.
Areas covered include such things as spark plug re-
placement, valve clearance adjustment and engine oil
and filter replacement.

’01 Tacoma U (L/O 0009)
2001 TACOMA (OM35766U)
WE REALLY CARE ABOUT YOU  PLEASE BUCKLE UP
Toyota has made a special effort to encourage use of seat belts.
Toyota belts are:
Comfortable
Easy to use
Convenient
We encourage you to use your belts every time you drive.
U
