207
When jacking up your vehicle with the
jack, position the jack correctly as
shown in the illustration.
CAUTION
When jacking, be sure to observe the
following to reduce the possibility of
personal injury:
Follow jacking instructions.
Do not put any part of your body
under the vehicle supported by a
jack. Personal injury may occur.
Do not start or run the engine while
your vehicle is supported by the
jack.
Stop the vehicle on a level firm
ground, firmly set the parking brake
and put the transmission in “P”
(automatic) or reverse (manual).
Block the wheel diagonally opposite
to the one being changed if neces-
sary.
Make sure to set the jack properly
in the jack point. Raising the ve-
hicle with jack improperly posi-
tioned will damage the vehicle or
may allow the vehicle to fall off the
jack and cause personal injury.
Never get under the vehicle when
the vehicle is supported by the jack
alone; use vehicle support stands.
Do not raise the vehicle with some-
one in the vehicle.
When raising the vehicle, do not
place any objects on top of or un-
derneath the jack.
NOTICE
Make sure to place the jack correctly,
or your vehicle may be damaged.

239
24. ALT 120 A: “HTR”, “ABS NO.1”, “ABS
NO.2”, “RDI”, “CDS”, “DEF”, “TAIL”,
“PANEL”, “DOOR”, “STOP”, “ACC
SOCKET”, “GAUGE”, “ECU–IG”, “FR
WIP”, “WSH”, “AM1”, “FR DOOR”, “FL
DOOR”, “S/ROOF”, “A/C” and “FR
FOG” fuses
25. SPARE 30 A: Spare fuse
26. SPARE 20 A: Spare fuse
27. SPARE 10 A: Spare fuse
28. DEF 30 A: Rear window defogger
29. TAIL 10 A: Tail lights, parking lights,
license plate lights, front side maker
lights
30. PANEL 7.5 A: Instrument cluster lights,
instrument panel lights, gauges and
meters, audio system, console box illu-
mination
31. A/C 10 A: Air conditioning system
32. FR DOOR 20 A: Power windows
33. S/ROOF 20 A: Panorama moonroof
34. CIG 15 A: Cigarette lighter
35. ACC 7.5 A: Shift lock control system,
power outlet, car audio system, power
rear view mirrors
36. RR DEF I/UP 7.5 A: Rear window de-
fogger 37. ACC SOCKET 15 A:
Power outlet
38. FL DOOR 20 A: Power windows
39. IG2 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, SRS airbag system, security
system
40. MET IG2 10 A: Gauges and meters
41. FR WIP 30 A: Windshield wipers
42. FR WSH 15 A: Windshield washer
43. ECU–IG 7.5 A: Multiport fuel injection
system/se quential multiport fuel injec-
tion system, shift lock control system,
electric cooling fan, panorama mooroof,
anti–lock brake system
44. GAUGE 10 A: Back–up lights, electric
cooling fan, air conditioning system,
emergency flasher, power windows,
power door lock system, gauges and
meters
45. STOP 10 A: Stop lights, high mounted
stoplight, shift lock control system,
multiport fuel injection system/sequen-
tial multiport fuel injection system, anti–
lock brake system
46. DOOR 20 A: Power door lock system
47. FR FOG 15 A: Fog lights
48. AM1 25 A: Starting system, “CIG” and
“ACC” fuses
