Basic Operation
Your audio system works when the
ignition switch is in the “ACC” or
“ON” position.
1POWER
Press to turn the unit on or off.
2VOLUME/LEVEL + -
When the Audio Control mode is
OFF, raises/lowers volume (total vol-
ume step is 62).
When the Audio Control mode is ON,
raises/lowers audio control levels.
3AUDIO CONTROL
Press and the Audio Control mode
cycles through the following order:
SRT (Sound Retouch) =BAS (Bass) =
TRE (Treble) =FAD (Fader) =BAL
(Balance) =ASL (Automatic Sound
Levelizer) =VOL (volume) =SRT
(Sound Retouch)
NOTICE
To prevent the battery from
being discharged, do not
leave the car audio on longer
than necessary when the
engine is not running.
2VOLUME
3AUDIO CONTROL
1POWER
5MUTE
4SSP
6
4SSP is an abbreviation of Scion Sound Processing.

29
2Editing the Text
After completing the shift to cus-
tomize mode, a flashing cursor
shows the letter that can be edited by
selecting a letter starting from “A”.
The letter selection method is
described below. The time allowed
for editing is limited to 60 sec.
1 Press the PRESET 3 or 4 buttons
to change the flashing letter by
displaying other letters one by
one. The letters will change con-
tinuously if you press and hold the
PRESET 3 or 4 button.
List of the letters and numbers
that can be selected.
•Upper case letters (A to Z)
•Lower case letters (a to z)
•Numbers 0 to 9, spaces, sym-
bols (!”# and so on)
2 With the character that you want
to select displayed, press the
PRESET 6 button to select it.
After selecting the character, the
cursor moves to the right so you
can edit the next character. After
you select the 16th character, the
entire line starts flashing.
To delete a selected character,
press the PRESET 5 button. After
you delete a character the cursor
shifts left so you can edit the pre-
vious character. If you delete all ofthe text, you can edit from the
first character.
3 After you are finished selecting
the text for the line, press and
hold down the PRESET 6 button.
The selected text string is regis-
tered as the Opening Screen. The
customize mode ends and the
registered text string is displayed
for 6 sec.
3New Message Display
The next time the ACC is switched
on, the text edited by the user will be
displayed.
NOTICE
To prevent the battery from
being discharged, do not
leave the car audio on longer
than necessary when the
engine is not running.
NOTICE
•If the unit leaves the cus-
tomize mode during editing,
repeat procedure
1from
Step 2.
•If the edit is registered with
no new text, the original
Opening Screen, “Scion” ,
will be restored.
