BASIC FUNCTION

30
V573_E
z To see information about the icon
where the cursor is set

To display information about an icon, set
the cursor on it. POI INFORMATION
When the cursor is set on a POI icon, the
name and
“Info.” are displayed on the
top of the screen.
Touch “Info.”.

Information such as the name, address,
position and phone number are dis-
played.
If “Enter
” is touched, the position of
the cursor is set as a destination.

BASIC FUNCTION
31
V573_E

If there is already a set destination, “Add
to
” and “Replace ” are dis-
played.
“Add to
”: To add a destination.
“Replace
”: To delete the existing
destinations and set a new one.
To register this POI as a memory point,
touch “Mark” . (See “ — Registering
memory points” on page 97.)
If
is touched, the registered tele-
phone number can be called.

INFORMATION
The desired Point of Interest can be
displayed on the map screen. (See
“ — Display POI icons” on page 78.)

MEMORY POINT INFORMATION
When the cursor is set on a memory
point icon, the name and “Info.” are
displayed on the top of the screen.

Touch “Info.”.

Information such as the name, address,
position and phone number are dis-
played.
If “Enter
” is touched, the position of
the cursor is set as a destination.
If there is already a set destination, “Add
to
” and “Replace ” are dis-
played.
“Add to
”: To add a destination.
“Replace
”: To delete the existing
destinations and set a new one.
To edit a memory point, touch
“Edit” .
(See “ — Editing memory points” on
page 98.)
To delete a memory point, touch “De-
lete” .
If
is touched, the registered tele-
phone number can be called.

BASIC FUNCTION

32
V573_E
DESTINATION INFORMATION
When the cursor is set on a destination
icon, the name and “Info.” are displayed
on the top of the screen.

Touch “Info.”.

Information such as the name, address,
position and phone number are dis-
played.
To delete a destination, touch “Delete”.
If
is touched, the registered tele-
phone number can be called. Any one of the screen configurations can
be selected.

1. Touch this touch screen button to
display the following screen.

2. To select the desired screen con-
figuration, touch one of the following
touch screen buttons.


—Switching the screens

BASIC FUNCTION
33
V573_E

Depending on the conditions, certain
screen configuration buttons cannot be
selected.
: To display the single map screen. (See page 33.)
: To display the dual map screen.
(See page 34.)
: To display the compass mode screen. (See page 34.)
: To display the turn list screen. (See page 68.)
: To display the arrow screen. (See page 68.)
: To display the freeway informa-
tion screen. (See page 66.)
: To display the intersection guid- ance screen or the guidance
screen on the freeway. (See page
67.) z
Screen configurations
SINGLE MAP
This is a regular map screen.
While on a different screen, touching
will display the single map screen.

The screen shows the single map.

BASIC FUNCTION

34
V573_E
DUAL MAP
A map can be displayed split in two.
While on a different screen, touching
will display the dual map screen.

The screen shows the dual map. The
map on the left is the main map.
The right side map can be edited by
touching any specific point on the right
side map.

This screen can perform the following
procedures.
1. Changing the map scale
2. Displaying the POI icons
3. Show XM
® NavTraffic info. (See page
90.)
4. Changing the orientation of the map
Touch “OK” when you complete edit-
ing.
The screen returns to the dual map
screen. COMPASS MODE
Current vehicle position is indicated with
a compass, not with a map.
While on a different screen, touching
will display the compass mode
screen.

Information about the destination and
current position, as well as a compass, is
displayed on the screen.
The destination mark is displayed in the
direction of the destination. When driv-
ing refer to the longitude and latitude
coordinates, and the compass, to make
sure that your vehicle is headed in the
direction of the destination.

INFORMATION
When the vehicle travels out of the
coverage area, the guidance screen
changes to the compass mode
screen.

BASIC FUNCTION
35
V573_E


Touch or to change the
scale of the map display. The scale bar
and indicator at the bottom of the screen
indicates the map scale menu. The
scale range is 150 feet (50 m) to 250
miles (400 km).
Touch
or until the scale bar
changes normally. By continuing to
touch the touch screen button, the scale
bar changes smoothly.
The scale of the map display can be
changed by touching the scale bar di-
rectly. It is not available while driving.
The map scale is displayed under the
North-up symbol or Heading-up symbol
at the top left of the screen.

INFORMATION
When the map scale is at the maximum
range of 250 miles (400 km),
is
not shown.
When the map scale is at the minimum
range of 150 feet (50 m),
is not
shown.

► North-up screen

► Heading-up screen

► 2.5D map
Touching the orientation symbol at the
top left of the screen changes the orien-
tation from North-up to Heading-up ori-
entation, and the configuration from 2D
to 2.5D.


— Ma
p scale
— Changing map
orientation and configuration

BASIC FUNCTION

36
V573_E
North
−up symbol
Regardless of the direction of vehicle
travel, North is always up.
Heading
−up symbol
The direction of vehicle travel is always
up. A red arrow indicates North.
2.5D map symbol
The screen appears in 2.5D Heading up
orientation. Guidance to a destination occurs by
specifying the destination using the “POI
Name”.
1. Push the “DEST” button.

2. Touch “POI Name”.
INFORMATION
There are 13 different methods to
search destinations. (See “Destina-
tion search” on page 42.)
Example of navigation
system operation —
—Guiding the route

BASIC FUNCTION
37
V573_E


3. Enter the name of the destination.
Every touch on a letter key narrows the
selection.
Letters that cannot be selected in the
database are dimmed out.
When there are four or fewer database
items, these items are displayed in a list.
Even if the entered name is incomplete,
touching “List” displays the list.

4. Select the destination from the
displayed list.

5. Touch “Enter”.
The system starts route search and dis-
plays recommended routes.

6. Touch “Guide”.
Route guidance starts.
Guidance is done by both the screen and
voice. (See “Route guidance screen”
and “Typical voice guidance prompts” on
pages 66 and 69.)

INFORMATION
It is possible to change the route.
(See “Starting route guidance” on
page 61.)

BASIC FUNCTION

38
V573_E
The home touch screen button on the
“Destination” screen can be used if your
home has been registered. (See “ —
Destination search by Home” on page
44.)
1. Push the “NAVI” button.

2. Touch “My Places”.

3. Touch “Register”.

4. Touch “Address”.

5. Enter the street name.
Every touch on a letter key narrows the
selection.
Letters that cannot be selected in the
database are dimmed out.
When there are four or fewer database
items, these items are displayed in a list.
Even if the entered name is incomplete,
touching “List” displays the list.

6. Select the street name from the
displayed list.



— Re
gistering home

BASIC FUNCTION
39
V573_E


7. Enter the house number.
If the same street exists in more than
one city, the current screen changes to
the city list screen. Select the city
name.

8. Touch “Enter”.
Registration of home is complete and the
“Memory Point” screen is displayed.

Registered “Home” information will
be displayed.
The icon, quick access, name, location,
and phone number can be changed.
(See “ — Editing memory points” on
page 98.)
