Page 6 SCION — REMOTE ENGINE STARTER
OPERATION
REMOTE ENGINE STOP
There are two methods by which to shut off the vehicle engine remotely: Either press
the UNLOCK button once OR press and hold the LOCK button for two or more seconds.











Using Method 1, your vehicle will remain unlocked for 30 seconds. Then it automatically
relocks if no doors are opened. If your vehicle will not be in plain vie\
w for that time, or you
have other security concerns, you may wish to use Method 2 (below), wh\
ich does not
unlock the vehicle.











NOTE: All doors will remain locked after the engine is shut off.
NOTE: For vehicles equipped with Piezo, the buzzer will chirp the same number\
of
times that the light flashes.



AUTOMATIC ENGINE SHUTDOWN
The engine will stop automatically after 10 minutes.
10
METHOD 2: Press and hold the LOCK button on the remote for two or more seconds. The
engine stops and the hazard lights flash once.
A) Press and
hold the
LOCK button
for two
seconds or
more. B) The
engine
stops.
C) The hazard
lights flash
once.
UNLOCK
METHOD 1: Press the UNLOCK button on the remote. The engine stops and the hazard
lights flash twice.
A) Press the
UNLOCK
button. B) The
engine
stops.
C) The hazard
lights flash twice.
UNLOCK

SCION — REMOTE ENGINE STARTER Page 7
OPERATION
AUTOMATIC ENGINE SHUTDOWN
The Remote Engine Starter will automatically shut down or will not start\
the vehicle’s
engine under the following conditions:
If any door is manually unlocked or via Smart
Key.
If any door is opened.
If the shift lever is moved to any
position other than “P.”
If the hood is opened.
ENGINESTART
STOP
(Without Push Start)
The key is inserted in the key cylinder.
(With Push Start)
If push button is pressed.
The brake pedal is depressed.
If the security alarm is triggered.
NOTE: The engine will continue to run if the
panic alarm is triggered.
