Page 330 of 492

330 4-3. Do-it-yourself maintenance
tC_OM_OM21054U_(U)
■When replacing wheels (U.S.A. only)
The wheels of your vehicle are equipped with tire pressure warning
valves and transmitters that allow the tire pressure warning system to
provide advance warning in the event of a loss in tire inflation pressure.
Whenever wheels are replaced, tire pressure warning valves and trans-
mitters must be installed. (P. 315)
CAUTION
■When replacing wheels
●Do not use wheels that are a different size from those recommended in
the Owner’s Manual, as this may resu lt in a loss of handling control.
●Never use an inner tube in a leaking wheel which is designed for a
tubeless tire. Doing so may result in an accident, causing death or seri-
ous injury.
■When installing the wheel nuts
●Never use oil or grease on the wheel bolts or wheel nuts.
Oil and grease may cause the wheel nuts to be excessively tightened,
leading to bolt or disc wheel damage. In addition, the oil or grease can
cause the wheel nuts to loosen and the wheel may fall off, causing an
accident and resulting in death or serious injury. Remove any oil or
grease from the wheel bolts or wheel nuts.
●Be sure to install the wheel nuts with
the tapered ends facing inward.
Installing the nuts with the tapered
ends facing outward can cause the
wheel to break and eventually cause
the wheel to come off while driving,
which could lead to an accident
resulting in death or serious injury.Tapered
portion
Page 375 of 492

5
When trouble arises
375
5-2. Steps to take in an emergency
tC_OM_OM21054U_(U)
Stop the vehicle immediately.
The following warning indicates the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your Scion dealer.
Warning lightWarning light/Details
Charging system warning light Indicates a malfunction in the vehicle’s charging system.
Low engine oil pressure warning light Indicates that the engine oil pressure is too low.
Page 485 of 492

485
Alphabetical index
tC_OM_OM21054U_(U)
Tachometer .............................. 190
Tail lights
Replacing light bulbs ............ 349
Switch ................................... 199
Wattage ................................ 438
Theft deterrent system
Engine immobilizer system... 102
Theft prevention labels ........... 105
Tire inflation pressure ............ 325
Tire information Glossary ............................... 450
Size ...................................... 446
Tire identification number ..... 445
Uniform Tire Quality Grading .............................. 447
Tires Chains .................................. 226
Checking .............................. 314
If you have a flat tire ............. 392
Inflation pressure .......... 325, 437
Inflation pressure sensor ...... 315
Information ........................... 443
Replacing ............................. 392
Rotating tires ........................ 314
Size ...................................... 437
Snow tires............................. 226
Spare tire .............................. 392
Tire pressure warning system................................ 314
Tools......................................... 392
Total load capacity .................. 225
Towing Dinghy towing ............... 233, 234
Emergency towing ................ 367
Trailer towing ........................ 232
TRAC ........................................ 215
Traction control ....................... 215
Trailer towing........................... 232
Trip meter................................. 190
Turn signal lights Replacing light bulbs ............ 349
Switch ................................... 187
Wattage ................................ 438 Vanity mirrors...........................259
Vehicle data recordings ............20
Vehicle identification
number ...................................429
Vehicle stability control...........215
VSC............................................215
Warning buzzers Brake system ........................374
Open door .............................378
Seat belt reminder .................378
Warning lights Anti-lock brake system ..........376
Automatic transmission fluid temperature ........................377
Brake assist system ..............376
Brake system ........................374
Charging system .... ...............375
Electric power steering system warning light........................377
Electronic engine control
system ................................376
High coolant temperature ......378
Low engine oil pressure ........375
Low fuel level ........................378
Low tire pressure...................380
Low washer fluid ...................378
Malfunction indicator lamp ....376
Open door .............................378
Pretensioners ........................376
Seat belt reminder light .........378
Smart key system... ...............382
SRS airbags ..........................376
Tire pressure warning light ....380
Washer Checking ...............................312
Preparing and checking
before winter .......................226
Switch....................................204
Washing and waxing ...............274TV
W
Page 488 of 492

488 What to do if...
tC_OM_OM21054U_(U)
A warning light or indicator light
comes onP. 374If a warning light turns on
■Warning lights
orP. 378
P. 3 7 4
P. 377
P. 3 7 5
P. 378
P. 3 7 5
P. 378
or
P. 378
P. 3 7 6
P. 3 7 6P. 378
Brake system warning
light
Charging system
warning light
Open door warning light
Low fuel level warning
light
Malfunction indicator
lamp
SRS warning light
Low engine oil
pressure warning light
High engine coolant
temperature
warning light Low windshield
washer fluid
warning light
Electric power
steering system
warning lightDriver’s and/or front
passenger’s seat belts
reminder light
