Page 218 of 492

218 2-4. Using other driving systems
tC_OM_OM21054U_(U)
CAUTION
■The ABS does not operate effectively when
●The limits of tire gripping performance have been exceeded (such as
excessively worn tires on a snow covered road).
● The vehicle hydroplanes while driving at high speed on wet or slick roads.
■ Stopping distance when the ABS is operating may exceed that of nor-
mal conditions
The ABS is not designed to shorten the vehicle’s stopping distance. Always
maintain a safe distance from the vehicle in front of you, especially in the fol-
lowing situations:
● When driving on dirt, gravel or snow-covered roads
● When driving with tire chains
● When driving over bumps in the road
● When driving over roads with potholes or uneven surfaces
■ TRAC may not operate effectively when
Directional control and power may not be achievable while driving on slip-
pery road surfaces, even if the TRAC system is operating.
Drive the vehicle carefully in conditions where stability and power may be
lost.
■ When the VSC is activated
The slip indicator light flashes. Always drive carefully. Reckless driving may
cause an accident. Exercise particular care when the indicator light flashes.
■ When the TRAC/VSC syst ems are turned off
Be especially careful and drive at a speed appropriate to the road condi-
tions. As these are systems to help ensure vehicle stability and driving force,
do not turn the TRAC/VSC systems off unless necessary.
Page 226 of 492

226
2-5. Driving information
tC_OM_OM21054U_(U)
Winter driving tips
Carry out the necessary preparations and inspections before driving
the vehicle in winter. Always drive the vehicle in a manner appropri-
ate to the prevailing weather conditions.
■ Pre-winter preparations
●Use fluids that are appropriate to the prevailing outside tem-
peratures.
• Engine oil
• Engine coolant
• Washer fluid
● Have a service technician inspec t the condition of the battery.
● Have the vehicle fitted with four snow tires or purchase a set
of tire chains for the front tires.
Ensure that all tires are the same size and brand, and that chains
match the size of the tires.
Page 230 of 492

230 2-5. Driving information
tC_OM_OM21054U_(U)
CAUTION
■Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in a loss of vehicle control and cause death or
serious injury.
●Use tires of the specified size.
● Maintain the recommended level of air pressure.
● Do not drive in excess of 75 mph (120 km/h), regardless of the type of
snow tires being used.
● Use snow tires on all, not just some wheels.
■ Driving with tire chains
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in the vehicle being unable to be driven safely,
and may cause death or serious injury.
●Do not drive in excess of the speed limit specified for the tire chains being
used, or 30 mph (50 km/h), whichever is lower.
● Avoid driving on bumpy road surfaces or over potholes.
● Avoid sudden acceleration, abrupt steering, sudden braking and shifting
operations that cause sudden engine braking.
● Slow down sufficiently before entering a curve to ensure that vehicle con-
trol is maintained.
Page 231 of 492

231
2-5. Driving information
2
When driving
tC_OM_OM21054U_(U)
NOTICE
■
Repairing or replacing snow tires (U.S.A. only)
Request repairs or replacement of snow tires from Scion dealers or legiti-
mate tire retailers.
This is because the removal and attachment of snow tires affects the opera-
tion of the tire pressure warning valves and transmitters.
■ Fitting tire chains (U.S.A. only)
The tire pressure warning valves and transmitters may not function correctly
when tire chains are fitted.
Page 318 of 492

318 4-3. Do-it-yourself maintenance
tC_OM_OM21054U_(U)
■When to replace your vehicle’s tires
Tires should be replaced if:
●You have tire damage such as cuts, splits, cracks deep enough to
expose the fabric, and bulges indicating internal damage
●A tire goes flat repeatedly or cannot be properly repaired due to the
size or location of a cut or other damage
If you are not sure, consul t with your Scion dealer.
■Replacing tires and wheels (U.S.A. only)
If the ID code of the tire pressure warning valve and transmitter is not
registered, the tire pressure warning system will not work properly. After
driving for about 20 minutes, the tire pressure warning light blinks for
1 minute and stays on to indicate a system malfunction.
■Tire life
Any tire over 6 years old must be checked by a qualified technician even
if it has seldom or never been used or damage is not obvious.
■Routine tire inflation pressure checks (U.S.A. only)
The tire pressure warning system doe s not replace routine tire inflation
pressure checks. Make sure to check tire inflation pressure as part of
your routine of daily vehicle checks.
■Low profile tires
Generally, low profile tire s will wear more rapidly and tire grip perfor-
mance will be reduced on snowy and/or icy roads when compared to
standard tires. Be sure to use snow tires or tire chains on snowy and/or
icy roads and drive carefully at a speed appropriate for road and weather
conditions.
Page 387 of 492

5
When trouble arises
387
5-2. Steps to take in an emergency
tC_OM_OM21054U_(U)
■If the tire pressure warning system is not functioning (U.S.A. only)
The system will be disabled in the following conditions:
(When the condition be
comes normal, the system will work properly.)
●If tires not equipped with tire pressure warning valves and transmit-
ters are used.
●If the ID code on the tire pressure warning valves and transmitters is
not registered in the tire pressure warning computer.
●If the tire inflation pressure is 73 psi (500 kPa, 5.1 kgf/cm2 or bar) or
higher.
The tire pressure warning system may be disabled in the following condi-
tions:
(When the condition be comes normal, the system will work properly.)
●If electronic devices or facilities using similar radio wave frequencies
are nearby.
●If a radio set at a similar frequency is in use in the vehicle.
●If a window tint that affects the radio wave signals is installed.
●If there is a lot of snow or ice on the vehicle, particularly around the
wheels or wheel housings.
●If non-genuine Scion wheels are used. (Even if you use Scion
wheels, the tire pressure warning system may not work properly with
some types of tires.)
●If tire chains are used.
Page 401 of 492

5
When trouble arises
401
5-2. Steps to take in an emergency
tC_OM_OM21054U_(U)
■The compact spare tire
●The compact spare tire is identifi
ed by the label “TEMPORARY USE
ONLY” on the tire sidewall.
Use the compact spare tire temporarily, and only in an emergency.
●Make sure to check the tire inflation pressure of the compact spare
tire. ( P. 437)
■After completing the tire change (U.S.A. only)
The tire pressure warning system must be reset. (P. 315)
■When using the compact spare tire (U.S.A. only)
As the compact spare tire is not equipped with a tire pressure warning
valve and transmitter, low inflation pressure of the spare tire will not be
indicated by the tire pressure warning system. Also, if you replace the
compact spare tire after the tire pressure warning light comes on, the
light remains on.
■If you have a flat front tire on a road covered with snow or ice
Install the compact spare tire on one of the rear wheels of the vehicle.
Perform the following steps and fit tire chains to the front tires:
Replace a rear tire with the compact spare tire.
Replace the flat front tire with the tire removed from the rear of
the vehicle.
Fit tire chains to the front tires.
STEP 1
STEP 2
STEP 3
Page 485 of 492

485
Alphabetical index
tC_OM_OM21054U_(U)
Tachometer .............................. 190
Tail lights
Replacing light bulbs ............ 349
Switch ................................... 199
Wattage ................................ 438
Theft deterrent system
Engine immobilizer system... 102
Theft prevention labels ........... 105
Tire inflation pressure ............ 325
Tire information Glossary ............................... 450
Size ...................................... 446
Tire identification number ..... 445
Uniform Tire Quality Grading .............................. 447
Tires Chains .................................. 226
Checking .............................. 314
If you have a flat tire ............. 392
Inflation pressure .......... 325, 437
Inflation pressure sensor ...... 315
Information ........................... 443
Replacing ............................. 392
Rotating tires ........................ 314
Size ...................................... 437
Snow tires............................. 226
Spare tire .............................. 392
Tire pressure warning system................................ 314
Tools......................................... 392
Total load capacity .................. 225
Towing Dinghy towing ............... 233, 234
Emergency towing ................ 367
Trailer towing ........................ 232
TRAC ........................................ 215
Traction control ....................... 215
Trailer towing........................... 232
Trip meter................................. 190
Turn signal lights Replacing light bulbs ............ 349
Switch ................................... 187
Wattage ................................ 438 Vanity mirrors...........................259
Vehicle data recordings ............20
Vehicle identification
number ...................................429
Vehicle stability control...........215
VSC............................................215
Warning buzzers Brake system ........................374
Open door .............................378
Seat belt reminder .................378
Warning lights Anti-lock brake system ..........376
Automatic transmission fluid temperature ........................377
Brake assist system ..............376
Brake system ........................374
Charging system .... ...............375
Electric power steering system warning light........................377
Electronic engine control
system ................................376
High coolant temperature ......378
Low engine oil pressure ........375
Low fuel level ........................378
Low tire pressure...................380
Low washer fluid ...................378
Malfunction indicator lamp ....376
Open door .............................378
Pretensioners ........................376
Seat belt reminder light .........378
Smart key system... ...............382
SRS airbags ..........................376
Tire pressure warning light ....380
Washer Checking ...............................312
Preparing and checking
before winter .......................226
Switch....................................204
Washing and waxing ...............274TV
