DI4M4-01
Vehicle Brought to Workshop
Customer Problem Analysis
Warning Light Check
DTC Check and Recording
Malfunction Code Clearance DI-148
DI-151
Circuit Inspection
Remains on
Malfunction Code
Symptom Simulation
DTC Check
DI-155
Identification of Problem
Normal Code
Confirmation Test
Does Not Light Up
END
1
2
3
4
7
Repair 856
Step
:Diagnostic steps permitting the use
of the TOYOTA hand-held tester.
DI-147
DI-148
DI-148
DI-148
DI-148
Malfunction Code
DTC Chart
DI-151
DTC Check and Recording
129
DI-148 Malfunction Code Clearance
10
11
Normal Code
Normal
Code
Malfunction CodeNormal
Code
,, , , , , 345101112
Malfunction Code
DI-146
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
320 Author: Date:
1996 TERCEL (RM440U)
SUPPLEMENTAL RESTRAINT SYSTEM
HOW TO PROCEED WITH TROUBLESHOOTING
Perform troubleshooting in accordance with the procedure on the following pages.
Page 322 of 1202
DI4M5-01
Supplemental Restraint System Check Sheet
Date Problem Dist Occurred
Customer 's Name
Registration No.
Registration Year
Frame No.
Odometer Reading
Weather
Temperature
Vehicle Operation
Road Conditions
Details Of Problem
Vehicle Inspection, Repair History
Prior to Occurrence of Malfunction
(Including Supplemental Restraint
System)
Diagnosis System Inspection
SRS Warning Light
Inspection
DTC Inspection1st Time
2nd Time
1st Time
2nd TimeInspector 's
Name
Fine Cloudy Rainy Snowy Other
Approx.
Starting Idling
Driving [ Constant speed Acceleration Deceleration
Other ]
Remains ON Sometimes Light Up Does Not Light Up
Remains ON Sometimes Light Up
Does Not Light Up
Normal Code Malfunction Code
Normal Code Malfunction Code[ Code. ]
[ Code. ]km
Miles //
//
// Date Vehicle Brought In
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-147
1996 TERCEL (RM440U)
CUSTOMER PROBLEM ANALYSIS CHECK
Page 323 of 1202
N12151
DI95N-01
R13006
E1
Tc
AT0716
Normal Code
ON
OFF0.25
0.25
DI-148
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TERCEL (RM440U)
PRE-CHECK
1. SRS WARNING LIGHT CHECK
(a) Turn the ignition switch to ACC or ON and check that the
SRS warning light lights up.
(b) Check that the SRS warning light goes out after approx.
6 seconds.
HINT:
When the ignition switch is at ACC or ON and the SRS
warning light remains on or flashes, the airbag sensor as-
sembly has detected a malfunction code.
If, after approx. 6 seconds have elapsed, the SRS warn-
ing light sometimes lights up or the SRS warning light
lights up even when the ignition switch is OFF, a short in
the SRS warning light circuit can be considered likely.
Proceed to ºSRS warning light system malfunctionº on
page DI-180, DI-182.
2. DTC CHECK (Using diagnosis check wire)
(a) Output the DTC.
(1) Turn the ignition switch to the ACC or ON position
and wait approx. 20 seconds.
(2) Using SST, connect terminals Tc and E1 of the
DLC1.
SST 09843-18020
NOTICE:
Never make a mistake with the terminal connection posi-
tion as this will cause a malfunction.
(b) Read the DTC.
Read the 2-digit DTC as indicated by the number of times
the SRS warning light blinks. As an example, the blinking
patterns, normal, 11 and 31 are as shown on the illustra-
tion.
Normal code indication.
The light will blink 2 times per second.
Malfunction code indication.
The first blinking output indicates the first digit
of a 2-digit DTC. After a 1.5 second pause,
the second blinking output will indicate the
second digit.
Page 324 of 1202
AB0056
Code 11 and 31
ON
OFF
0.5 2.54.0
1.5 0.5
Code 11Code 31Repeat
N12278
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-149
1996 TERCEL (RM440U)
If there are 2 or more codes, there will be a 2.5 second pause
between each code. After all the codes have been output, there
will be a 4.0 second pause and they will all be repeated.
HINT:
In the event of a number of trouble codes, indication will
start from the smallest numbered code.
If it does not output a DTC or outputs a DTC without termi-
nal connection, proceed to the Tc terminal circuit inspec-
tion on page DI-185.
3. DTC CHECK (Using TOYOTA hand-held tester)
(a) Hook up the TOYOTA hand-held tester to the DLC1.
(b) Read the DTCs by following the prompts on the tester
screen.
HINT:
Please refer to the TOYOTA hand-held tester operator's manu-
al, for further details.
Page 325 of 1202
H01461H04911
H05581
ABTerminal
Tc
ABOFF
Body
Ground
OFF
ON
OFF
Several
Seconds50 m sec.
50 m sec.
1 second
(± 0.5 sec.)
Tc
Body
Ground
1 second
(± 0.5 sec.)
1
23
45
N12278
DI-150
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TERCEL (RM440U)
4. DTC CLEARANCE (Using diagnosis check wire)
(a) Connect the 2 service wires to terminals Tc and AB of
DLC1.
(b) Turn the ignition switch to ACC or ON and wait approx. 6
seconds.
(c) Starting with the Tc terminal, apply body ground alternate-
ly to terminal Tc and terminal AB twice each in cycles of
1.0 seconds. Confirm that body ground is absolute. Final-
ly, keep applying body ground to terminal Tc.
HINT:
When alternately grounding terminals Tc and AB, release
ground from one terminal and immediately apply it to the other
terminal within an interval of 0.2 seconds. If DTCs do not clear,
repeat the above procedure until the codes are cleared.
(d) Several seconds after doing the clearing procedure, the
SRS warning light will blink in a 50 m sec. cycle to indicate
the codes have been cleared.
5. DTC CLEARANCE (Using TOYOTA hand-held tester)
(a) Hook up the TOYOTA hand-held tester to the DLC1.
(b) Clear the DTCs by following the prompts on the tester
screen.
HINT:
Please refer to the TOYOTA hand-held tester operator's manu-
al for further details.
Page 326 of 1202
DI4M7-02
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-151
1996 TERCEL (RM440U)
DIAGNOSTIC TROUBLE CODE CHART
If a malfunction code is displayed during the DTC check, check the circuit listed for that code in the table
below (Proceed to the page given for that circuit.).
DTC No.
(See Page)Detection ItemTrouble AreaSRS
Warning Light
NlSystem normal-OFFNormal
(DI-177)Source Voltage dropBattery
Airbag sensor assemblyON
11
(DI-155)
Short in squib circuit (to ground)Steering wheel pad (D squib)
Front passenger airbag assembly (P squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
12
(DI-162)
Short in squib circuit (to B+)Steering wheel pad (D squib)
Front passenger airbag assembly (P squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
14
(DI-168)
Open in D squib circuitSteering wheel pad (D squib)
Spiral cable
Airbag sensor assembly
Wire harness
ON
31
(DI-172)Airbag sensor assembly malfunctionAirbag sensor assemblyON
54
(DI-174)Open in P squib circuitFront passenger airbag assembly (P squib)
Airbag sensor assembly
Wire harness
ON
HINT:
When the SRS warning light remains lit up and the DTC is the normal code, this means a source voltage
drops.
This malfunction is not stored in memory by the airbag sensor assembly and if the power source volt-
age returns to normal, the SRS warning light will automatically go out.
When 2 or more codes are indicated, the codes will be displayed in numeral order starting from the
lowest numbered code.
If a code not listed on the chart is displayed, the airbag sensor assembly is faulty.
Page 327 of 1202
DI4M8-01
N12263
Front Passenger
Airbag Assembly Steering Wheel Pad
(With Airbag)
Spiral Cable
Airbag Sensor Assembly
Instrument Panel
Junction BlockSRS Warning Light
DI-152
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TERCEL (RM440U)
PARTS LOCATION
Page 328 of 1202
DI95O-01
H09395h-10-2-D
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-153
1996 TERCEL (RM440U)
TERMINALS OF ECM
No.SymbolTerminal Name
A-Electrical Connection Check Mechanism
B-Electrical Connection Check Mechanism
1P-Squib (Passenger)
2P+Squib (Passenger)
3D-Squib (Driver)
4D+Squib (Driver)
5E1Ground
6E2Ground
7TcDiagnosis
8LASRS Warning Light
9IG2Power Source (IGN Fuse)
10ACCPower Source (CIG Fuse)
Page 329 of 1202
DI4MA-01
DI-154
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1996 TERCEL (RM440U)
PROBLEM SYMPTOMS TABLE
Proceed with troubleshooting of each circuit in the table below.
SymptomSuspect AreaSee page
With the ignition switch at ACC or ON, the SRS warning light
sometimes lights up after approx. 6 seconds have elapsed.
SRS warning light is always lit up even when ignition switch is in
the LOCK position.
SRS warning light system malfunction
(Always lit up when ignition switch is in LOCK position.)DI-180
With the ignition switch at ACC or ON, the SRS warning light
does not light up.SRS warning light system malfunction
(Does not light up, when ignition switch is turned to ACC
or ON.)
DI-182
DTC not displayed.
SRS warning light is always lit up a DTC check procedure.
DTC displayed without Tc and E1 terminal connection.
Tc terminal circuitDI-185
Page 330 of 1202
DI4MB-02
R15075
D squib (w/o Front Passenger Airbag)
1
Spiral
2
D
-
D+
Airbag Sensor Assembly
Cable
B
4
3 (w/ Front Passenger Airbag)
D squib
Spiral
Cable
1
2W
P squib1
22
1 D
-
D+2
1
P
-
P+
B
B W
W
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-155
1996 TERCEL (RM440U)
CIRCUIT INSPECTION
DTC 11 Short in Squib Circuit (to Ground)
CIRCUIT DESCRIPTION
The squib circuit consists of the airbag sensor assembly, spiral cable, steering wheel pad and front passen-
ger airbag assembly. If causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see FUNCTION OF COMPONENTS on page RS-2.
DTC 11 is recorded when ground short is detected in the squib circuit.
DTC No.DTC Detection ConditionTrouble Area
11
Short circuit in squib wire harness (to ground)
Squib malfunction
Spiral cable malfunction
Airbag sensor assembly malfunctionSteering wheel pad (D squib)
Front passenger airbag assembly (P squib)
Spiral cable
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
