- ENGINE MECHANICALCYLINDER HEAD
EM-49
1996 TERCEL (RM440U)
8. SET NO.1 CYLINDER TO TDC/COMPRESSION
(a) Turn the crankshaft pulley, and align its groove with timing
mark º0º of the No.1 timing belt cover.
(b) Turn the camshaft, and align the hole of the camshaft tim-
ing pulley on the side with the 5E mark with the timing
mark of the bearing cap.
9. INSTALL TIMING BELT
(a) Starting from the right hand side of the pulley and instal-
ling the belt counterclockwise.
(b) Loosen the No.1 idler pulley mounting bolt until the pulley
is moved slightly by the spring tension.
(c) Turn the crankshaft pulley 2 revolutions from TDC to TDC.
NOTICE:
Always turn the crankshaft clockwise.

P20538
Timing Mark
Installation Mark
P20361
P20286
Seal Packing
P20406
EM-50
- ENGINE MECHANICALCYLINDER HEAD
1996 TERCEL (RM440U)
(d) Check that each pulley aligns with the timing marks as
shown in the illustration.
If the timing marks do not align, remove the timing belt and rein-
stall it.
(e) Tighten the mounting bolt of the No.1 idler pulley.
Torque: 18.5 N´m (185 kgf´cm, 13 ft´lbf)
10. INSTALL NO.3 TIMING BELT COVER
11. INSTALL GENERATOR DRIVE BELT (See page
CH-2)
12. INSTALL NO.2 TIMING BELT COVER
(a) Install the gasket to the belt cover.
(b) Install the belt cover with the 4 bolts.
13. INSTALL CHARCOAL CANISTER (See page EM-17)
14. INSTALL CYLINDER HEAD COVER
(a) Apply seal packing to the cylinder head as shown in the
illustration.
Seal packing:
Part No. 08826-00080 or equivalent
(b) Install the gasket to the cylinder head cover.
(c) Install the cylinder head cover with the 5 seal washers and
nuts.
Torque: 7.0 N´m (70 kgf´cm, 61 in.´lbf)
(d) Install the oil filler cap.
15. INSTALL INTAKE MANIFOLD
(a) Install air pipe a new gasket and the intake manifold with
the 2 bolts and 3 nuts.
Torque: 19.5 N´m (195 kgf´cm, 14 ft´lbf)

P20543
P20496
P20747
P20529
Seal PackingCORRECT WRONG
- ENGINE MECHANICALCYLINDER HEAD
EM-51
1996 TERCEL (RM440U)
(b) Install the manifold stay with the bolt and nut.
Torque: 20 N´m (200 kgf´cm, 15 ft´lbf)
(c) Connect the engine wire clamps to the intake manifold
stay.
16. CONNECT BRAKE BOOSTER AND MAP VACUUM
HOSES
17. INSTALL INJECTORS AND DELIVERY PIPE (See page
MF-22)
18. INSTALL EXHAUST MANIFOLD
(a) Install a new gasket and the exhaust manifold with the 6
nuts. Uniformly tighten the nuts in several passes.
Torque: 48 N´m (480 kgf´cm, 35 ft´lbf)
(b) Place the exhaust manifold stay snug against the cylinder
block and exhaust manifold.
(c) First, tighten the bolt (A) and then the 2 nuts.
Torque: 40 N´m (400 kgf´cm, 29 ft´lbf)
(d) Install the heat insulator with the 3 bolts.
Torque: 8.0 N´m (80 kgf´cm, 69 in.´lbf)
19. INSTALL WATER INLET AND OUTLET HOUSING
(a) Remove any old packing (FIPG) material and be careful
not to drop any oil on the contacting surfaces of the water
outlet housing and cylinder head.

Using a razor blade and gasket scraper, remove all
the packing (FIPG) material from the gasket sur-
faces.

Thoroughly clean all components to remove all the
loose material.

Clean both sealing surfaces with a non-residue sol-
vent.
(b) Apply seal packing to the water outlet housing as shown
in the illustration.
Seal packing:
Part No. 08826-00100, THREE BOND 1282B
or equivalent

Install a nozzle that has been cut to a 2 - 3 mm (0.08
- 0.12 in.) opening.

EM-52
- ENGINE MECHANICALCYLINDER HEAD
1996 TERCEL (RM440U)
HINT:
Avoid applying an excess amount to the surface. Be especially
careful near oil passages.

Parts must be assembled within 15 minutes of ap-
plication. Otherwise, the material must be removed
and reapplied.

Immediately remove nozzle from tube and reinstall
cap.

Do not pour in any coolant until at least 2 hours after
installation is completed.
(c) Install the water outlet housing with the bolt and 2 nuts.
Torque: 17.5 N´m (175 kgf´cm, 13 ft´lbf)
(d) Connect the 2 radiator hoses.
(e) Connect the water inlet hose.
(f) Connect the heater outlet hose.
(g) Connect the engine coolant temperature sensor connec-
tor.
(h) Connect the engine coolant temperature sender gauge
connector.
(i) Connect the fan engine coolant temperature switch con-
nector.
20. INSTALL CAMSHAFT POSITION SENSOR AND EGR
VSV
(a) Install a new O-ring to the position sensor.
(b) Install the position sensor with the bolt.
Torque: 8.0 N´m (80 kgf´cm, 69 in.´lbf)
(c) Install the EGR VSV with the bolt.
Torque: 17.5 N´m (175 kgf´cm, 13 in.´lbf)
(d) Connect the position sensor and EGR VSV connectors.
21. INSTALL EGR VALVE AND VACUUM MODULATOR
(a) Install a new gasket and the EGR valve with the 2 nuts.
Torque: 30 N´m (300 kgf´cm, 22 in.´lbf)
(b) Install the EGR vacuum modulator and bracket with the
bolt.

EG0023
P20290
- ENGINE MECHANICALCYLINDER HEAD
EM-53
1996 TERCEL (RM440U)
22. INSTALL EGR PIPE
Install a new gasket, sleeve ball and the EGR pipe with the
union nut and 2 nuts.
Torque:
Union nut
40 N´m (400 kgf´cm, 29 in.´lbf)
Nut
30 N´m (300 kgf´cm, 22 in.´lbf)
23. INSTALL THROTTLE BODY (See page MF-32)
24. CONNECT VACUUM HOSES
(a) Connect the vacuum hose from the EGR valve.
(b) Connect the 3 vacuum hoses from the throttle body.
(c) Connect the vacuum hose from TVV (to charcoal canis-
ter).
(d) Connect the vacuum hose from the TVV (to throttle body).
(e) Connect the vacuum hose from the EGR VSV.
25. INSTALL IGNITION COILS AND SPARK PLUGS
26. w/ A/C and w/o PS:
INSTALL IDLER PULLEY BRACKET
(a) Install the idler pulley bracket with the 3 bolts.
Torque:
12 mm head bolt
27 N´m (275 kgf´cm, 20 ft´lbf)
14 mm head bolt
37 N´m (375 kgf´cm, 27 ft´lbf)
(b) Install and adjust the drive belt (See page AC-18).
27. w/ PS:
INSTALL PS PUMP BRACKET AND PS PUMP
(a) Install the PS pump bracket with the 3 bolts.
Torque: 44 N´m (440 kgf´cm, 32 ft´lbf)
(b) Temporarily install the PS pump and drive belt with the 2
bolts (See page SR-33).
(c) Adjust the belt tension (See page SR-3).
28. CONNECT FUEL HOSE
Connect the fuel inlet hose with the union bolt and 2 new gas-
kets.
Torque: 29 N´m (300 kgf´cm, 22 ft´lbf)
29. INSTALL AIR CLEANER ASSEMBLY WITH AIR IN-
TAKE CONNECTOR
30. INSTALL ACCELERATOR CABLE, AND ADJUST IT
31. A/T:
CONNECT THROTTLE CABLE, AND ADJUST IT

P20160
EM-54
- ENGINE MECHANICALCYLINDER HEAD
1996 TERCEL (RM440U)
32. CONNECT FRONT EXHAUST PIPE
(a) Place a new gasket on the exhaust pipe.
(b) Connect the exhaust pipe to the exhaust manifold with
the 2 compression spring and 2 bolts.
Torque: 62 N´m (630 kgf´cm, 46 ft´lbf)
33. INSTALL RH ENGINE UNDER COVER
34. FILL WITH ENGINE COOLANT (See page CO-2)
35. START ENGINE AND CHECK FOR LEAKS
36. PERFORM ENGINE ADJUSTMENT
37. PERFORM ROAD TEST
Check for abnormal noise, shock, slippage, correct shift points
and smooth operation.
38. RECHECK ENGINE COOLANT AND ENGINE OIL LEV-
ELS

EM0JU-06
- ENGINE MECHANICALENGINE UNIT
EM-55
476 Author
: Date
:
1996 TERCEL (RM440U)
ENGINE UNIT
COMPONENTS

EM-56
- ENGINE MECHANICALENGINE UNIT
477 Author
: Date
:
1996 TERCEL (RM440U)

EM1OH-01
- ENGINE MECHANICALENGINE UNIT
EM-57
1996 TERCEL (RM440U)
REMOVAL
1. REMOVE BATTERY
2. REMOVE HOOD
3. REMOVE ENGINE UNDER COVERS
4. DRAIN ENGINE COOLANT
5. DRAIN TRANSAXLE OIL (FLUID)
6. REMOVE AIR CLEANER ASSEMBLY WITH AIR IN-
TAKE CONNECTOR
7. REMOVE RADIATOR (See page CO-16)
8. DISCONNECT ACCELERATOR CABLE
9. DISCONNECT FUEL HOSE
Remove the union bolt and gaskets, and disconnect the fuel in-
let hose.
NOTICE:
Catch leaking fuel in a container.
10. REMOVE CHARCOAL CANISTER
(a) Disconnect the canister hoses.
(b) Remove the charcoal canister.
11. DISCONNECT HOSES
(a) Disconnect the brake booster vacuum hose.
(b) Disconnect the MAP sensor hose.
(c) Disconnect the heater hoses.
12. DISCONNECT SPEEDOMETER CABLE FROM
TRANSAXLE
13. w/ PS:
DISCONNECT IDLE-UP AIR HOSES FROM AIR CON-
TROL VALVE
14. DISCONNECT ENGINE WIRE HARNESS
Disconnect these connectors and wires:

Main heated oxygen sensor connector

Oil pressure switch connector

P20565
M/T EM-58
- ENGINE MECHANICALENGINE UNIT
1996 TERCEL (RM440U)

Engine coolant temperature sender gauge connec-
tor

Engine coolant temperature sensor connector

Camshaft position sensor connector

EGR VSV

Fan engine coolant temperature switch connector

A/T only:
Lock-up solenoid connector

A/T only:
Park/Neutral position switch connector

M/T only:
Backup light switch connector

A/T only:
No.2 vehicle speed sensor connector

Ground strap

Throttle position sensor connector

IAC valve connector

Injector connectors

Crankshaft position sensor connector

Knock sensor connector

Starter connector and wire

Generator connector and wire
15. M/T only:
REMOVE CLUTCH RELEASE CYLINDER WITHOUT
DISCONNECTING TUBE
(a) Remove the 3 bolts, release cylinder and tube from the
transaxle.
(b) Disconnect the ground strap.
16. M/T:
DISCONNECT CONTROL CABLE(S) FROM TRANS-
AXLE
(a) Remove the clip and plate washer.
(b) Remove the retainer from the cable.
