CAUTION!
Push and pull the child restraint
system in different directions to be
sure it is secure. Follow all the
installation instructions provided
by its manufacturer.
4. To remove the infant seat, press the
buckle-release button and allow the
belt to retract completely. The belt will
move freely again and be ready towork for an adult or older child passen-
ger.(B) CONVERTIBLE SEAT INSTALLA- TION
A convertible seat is used in forward-
facing and rear-facing position de-
pending on the child's age and size.When installing, follow the manufac-
turer 's instruction about the applica-
ble child's age and size as well as di-
rection of a child restraint system.

49
Vehicles with a passenger airbag:
Never use a rear-facing child re-
straint system in the front seat be- cause the force of the rapid infla-
tion of the passenger airbag cancause severe injury to the child.
CAUTION!Only when it is unavoidable should a forward-facing child restraint sys-
tem be used on the front seat. Al- ways move the seat as far back as
possible because the force of de-
ploying airbag would cause seriousinjury to the child. Do not use a rear-facing child re-
straint system in the rear seat if it
interferes with the lock mecha-
nism of the front seats. This can cause severe injury to the child
and front passenger in case of
sudden braking or a collision.

50
1. Run the lap and shoulder belt throughor around the convertible seat follow-
ing the instructions provided by its
manufacturer and insert the tab into the buckle taking care not to twist the
belt. Keep the lap portion of the belt tight.
CAUTION!
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and buckle.
If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your To-
yota dealer immediately. Do not
use the seat until the seat belt is fixed.
2. Fully extend the shoulder belt to put it
in the lock mode. When the belt is then
retracted slightly, it cannot be ex- tended.
To hold the convertible seat securely,
make sure the belt is in the lock mode be-
fore letting the belt to retract.

51
3. While pressing the convertible seatfirmly against the seat cushion and
seatback, let the shoulder belt retract
as far as it will go to hold the convert-
ible seat securely.
CAUTION!
Push and pull the child restraint
system in different directions to be
sure it is secure. Follow all the
installation instructions provided
by its manufacturer.
4. To remove the convertible seat, press the buckle-release button and allow
the belt to retract completely. The belt will move freely again and be ready to work for an adult or older child passen-
ger.

52
(C) BOOSTER SEAT INSTALLATION A booster seat is used in forward-fac-
ing position only.
CAUTION!
Vehicles with a passenger airbag:
Only when it is unavoidable
should a forward-facing child re-
straint system be used on the front
seat. Always move the seat as far back as possible because the force of deploying airbag would cause serious injury to the child.
1. Sit the child on a booster seat. Run the
lap and shoulder belt through or
around the booster seat and child fol- lowing the instructions provided by its
manufacturer and insert the tab intothe buckle taking care not to twist the belt.
Make sure the shoulder belt is correctly
across the child's shoulder and that the
lap belt is positioned as low as possible on
child's hips. See Seat beltsº for details.

53
CAUTION!
Always make sure the shoulder
belt is positioned across the cen-
ter of child's shoulder. The belt
should be kept away from child's
neck, but not falling off child's
shoulder. Failure to do so could
reduce the amount of protection in
an accident and increase the
chance of injury.
High-positioned lap belts and
loose-fitting belts both could in-
crease the chance of injury due to
sliding under the lap belt during
an accident. Keep the lap belt as
low on your hip bone as possible.
For child's safety, do not place the
shoulder belt under child's arm.
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt is not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and buckle.If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your To-
yota dealer immediately. Do not
use the seat until the seat belt isfixed.
2. To remove the child restraint system,
press the buckle-release button and
allow the belt to retract.

54
If your child restraint system requires
the use of a top strap, latch the hook
onto the anchor bracket and tighten
the top strap.
See the following instructions to install the
anchor brackets.On the filler panel behind the rear seat
a. Using the illustration as a guide, run
your fingers across trim of the filler panel
itself to locate the position of the holes un-
derneath.
b. Make a hole in the covering directly
above the hole in the filler panel.
c. Insert a 10 mm (0.4 in.) spacer and tighten down the anchor bracket for your
child restraint system with a bolt. Torque the bolt to 16.5-24.7 N Vm (1.68-2.52 kgf-
V m, 12.2-18.2 ft Vlb.). To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox,
designed for use with any of the
3 anchor locations shown in the illustra-tion.
If your child restraint system does not pro-
vide any of the necessary parts, ask your
Toyota dealer. (See ÐChild restraint sys-
temº.)
ÐTop strap anchors and locations

55
Adjust the mirror so you can just see
the side of your vehicle in the mirror. Be careful when judging the size or dis- tance of any object seen in the outside
rear view mirror on the passenger's side.
It is a convex mirror with a curved surface.
Any object seen in a convex mirror will
look smaller and farther away than when
seen in a flat mirror.
CAUTION!
Do not adjust the mirror while the ve-
hicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting in
personal injuries.
To adjust the rear view mirror, simply
operate the control lever.
If ice should jam the mirror, do not operate the control or scrape the
mirror face. Use a spray de-icer to free the mirror.
NOTICE
To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror. Daylight drivingÐLever at position 1
The reflection in the mirror has greater claritgy at this position. Night drivingÐLever at position 2 Remember that by reducing glare you
also lose some rear view clarity.
ÐRear view mirror remote control
Outside rear view mirrorsÐ Anti-glare inside rear viewmirror

56

Part 1Headlights and turn signals
57
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-4
Lights, Wipers and Defogger
Headlights and turn signals
Emergency flashers
Instrument panel light control
Interior light
Windshield wipers and washer
Rear window defogger
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob. Position oneÐParking, tail, license plate,
side marker and instrument panel lights Position twoÐHeadlights and all of the above
If you remove the key with the headlights
left on, a buzzer reminds you to turn the
lights off
when you open the driver's door.
NOTICE
To prevent the battery from being discharged, do not leave the lights
on for a long period when theengine is not running.
Daytime running light system (Canada only)
The headlights turn on when the parking brake is released with the engine started,
even with the light switch in the OFFº
position. they will not go off until the igni-
tion switch is turned off.
To turn on the other exterior lights and in-
strument panel lights, twist the knob to the
position 1.
Under the daytime running light system,
the headlights turn on at reduced intensi-
ty. Twist the knob to the position 2 to turn
to full intensity for driving at night.
