'99 TERCEL (U)
4
1. Engine coolant temperature gauge
2. Fuel gauge
3. Service reminder indicators and indicator lights 4. Odometer
5. Speedometer
6. Tachometer
7. Trip meter reset knob
8. Trip meter
Instrument cluster overview
With tachometer

'99 TERCEL (U)5
1. Fuel gauge
2. Service reminder indicators and indicator lights
3. Odometer 4. Speedometer
5. Engine coolant temperature gauge
6. Theft deterrent system indicator light
7. Trip meter reset knob
8. Trip meter

Without tachometer

'99 TERCEL (U)71
Odometer and trip meter
With tachometer
Without tachometer
These meters shows the running dis-
tance.
1. OdometerÐIt shows the total distance the vehicle has been driven.
2. Trip meterÐIt shows the distance driv- en since the last time it was set to
zero.
The black digits on white indicate tenth
of kilometers or miles.
3. Trip meter reset knobÐIt resets the trip meter to zero.
To reset the trip meter, push the knob.
(a) If parking brake
is off, stop and
check.
(b) Fasten seat belt.
If the indicator or Do this.
buzzer comes on...
(d) Stop and check.
(f) Take vehicle to
Toyota dealer.
(type A)
(type B)
(indicator and buzzer)
(e) Stop and check.
(c) Fasten front passenger 's seat
belt.
Service reminder indicators
and warning buzzers
