navigation TOYOTA TUNDRA 2007 2.G Navigation Manual

142
5U5268G
1. Select the telephone you want to dis-
play the information about.
5U5269G
2. When you complete confirming it,
touch
.
Speech command system
The speech command system enables
you to operate the navigation system and
audio system by giving a command.
XS00118
1. Push the speech command switch.
A beep sounds and on screen message is
displayed with an indicator at the top left.
5U5287G
2. Give a command while an indicator is
shown in the display. If you want to check
the command list, touch “Help” to display
the Help screen. (See “Help screen” on
page 144.) When you touch “Cancel”, the
previous screen returns.
If the navigation system does not respond or
the confirmation screen does not disappear,
please push the speech command switch
and try again.
If no command is given, a beep sounds and
the indicator disappears 6 seconds later.
If the system does not recognize your
speech, the system will respond with this
message (“System does not recognize this
command, please rephrase your
command.”). Start the operation from the
beginning.

147
(a) Automatic transition
You can select a function that enables au-
tomatic return to the navigation screen
from the audio screen.
RS02019
Select “ON” or “OFF” and then touch
“OK”.
“ON”:The navigation screen automatically
returns from the audio screen 20
seconds after the end of audio op-
eration.
“OFF”:The audio screen remains on.
(b) Switch color
You can select a color of touchscreen
buttons.
RS02019
Select “Green” or “Orange” and then
touch “OK”.
(c) Rear system lock
(with rear seat entertainment
system)
If the vehicle is equipped with the rear seat
entertainment system, the rear seat enter-
tainment system can be locked to prevent
rear passengers from operating the enter-
tainment system.
RS02019
Select “ON” or “OFF” and then touch
“OK”.
“ON”: The rear passengers cannot operate
the rear seat entertainment system. Only
front passengers can operate the system.
“OFF”: Both the front and rear passengers
can operate the rear seat entertainment sys-
tem.

148
Delete personal data
The following personal data can be de-
leted or returned to their default settings:
Information
Maintenance conditions
Maintenance information “off” setting
Navigation system
Memory points
Areas to avoid
Previous points
Route trace
User selection settings
Handsfree system
Phone book data
Dialed numbers and received calls
Speed dial
Bluetooth phone data
Security code
This function is available only when the
vehicle is not moving.
RS02019
1. Touch “Delete personal data”. The
“Delete personal data” screen appears.
5U5113G
2. Touch “Delete”. The “Confirmation to
delete all personal data” screen appears.
5U5114G
3. Touch “Yes”.

149
Beep setting
You can set a beep sound off.
1. Push the “INFO” button.
5U5112G
2. Touch “Beep Off”.
“Beep Off” is highlighted.
To set the beep sound on, touch “Beep Off”
again.
Select language
The language of the touchscreen but-
tons, popup messages and the voice
guidance can be changed.
1. Push the “INFO” button.
5U5112G
2. Touch “Language”.
5U5080G
3. Touch “English”, “Français” or
“Español” to select a language.
If a screen other than for the navigation sys-
tem is displayed, the current screen would
change to the “CAUTION” screen by pushing
the “MAP/VOICE”, “DEST” or “MENU” but-
ton.
4. Touch “I Agree”.
The language is changed and the screen re-
turns to the map display.

206
Rear view monitor system
The rear view monitor system assists the
driver by displaying an image of the view
behind the vehicle while backing up. The
left and right displayed on the screen are
the same as those of the inside rear view
mirror.
To display the rear view image on the
screen, place the selector lever in the “R”
position when the ignition key is in the
“ON” position.
If you move the selector lever out of the “R”
position, the screen returns to the previous
screen. Operating another function of the
navigation system will display another
screen.
The rear view monitor system is a supple-
ment device intended to assist back up.
When backing up, be sure to check behind
and all around the vehicle visually.CAUTION
Never depend on the rear view
monitor system entirely when
backing up. Always make sure your
intended path is clear.
Use caution just as you would when
backing up any vehicle.
Never back up while looking only at
the screen. The image on the screen
is different from actual conditions.
Depicted distances between objects
and flat surfaces will differ from
actual distances. If you back up while
looking only at the screen, you may
hit a vehicle, a person or an object.
When backing up, be sure to check
behind and all around the vehicle
visually and with mirrors before
proceeding.
Do not use the system when the tail
gate is not completely closed.
If the back of the vehicle is hit, the
position and mounting angle of the
camera may change. Be sure to have
the camera’s position and mounting
angle checked at your Toyota dealer.
As the camera has a water proof
construction, do not detach,
disassemble or modify it. This may
cause incorrect operation.
If the temperature changes rapidly,
such as when hot water is poured on
the vehicle in cold weather, the
system may not operate normally.
If the camera lens becomes dirty, it
cannot transmit a clear image. If
water droplets, snow, or mud adhere
to the lens, rinse with water and wipe
with a soft cloth. If the lens is
extremely dirty, wash it with a mild
cleanser and rinse.
Do not allow organic solvent, car
wax, window cleaner or glass coat to
adhere to the camera. If this happens,
wipe it off as soon as possible.
Use your own eyes to confirm the
vehicle’s surroundings, as the
displayed image may become faint or
dark, and moving images will be
distorted, or not entirely visible when
the outside temperature is low. When
backing up, be sure to check behind
and all around the vehicle visually
and with mirror before proceeding.
When replacing the tires, please consult
your Toyota dealer. If you replace the tires,
the area displayed on the screen may
change.

209
APPENDIX
Appendix
Limitations of the navigation system210 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map database information and updates212 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION VIII

210
Limitations of the navigation
system
This navigation system calculates the cur-
rent vehicle position using satellite sig-
nals, various vehicle signals, map data,
etc. However, the accurate position may
not be shown depending on the satellite
condition, road configuration, vehicle
condition or other circumstances.
The Global Positioning System (GPS) devel-
oped and operated by the U.S. Department of
Defense provides an accurate current vehicle
position, normally using 4 or more satellites,
and in some cases 3 satellites. The GPS sys-
tem has a certain level of inaccuracy. While
the navigation system will compensate for
this most of the time, occasional positioning
errors of up to 300 feet (100 m) can and
should be expected. Generally, position er-
rors will be corrected within a few seconds.
7U5027
When your vehicle is receiving signals from
the satellites, the “GPS” mark appears at the
top left of the screen.
The GPS signal may be physically ob-
structed, leading to inaccurate vehicle posi-
tion on the map display. Tunnels, tall build-
ings, trucks, or even the placement of objects
on the instrument panel may obstruct the
GPS signals.
The GPS satellites may not send signals due
to repairs or improvements being made to
them.
Even when the navigation system is receiving
clear GPS signals, the vehicle position may
not be shown accurately or inappropriate
route guidance may occur in some cases.
NOTICE
The installation of window tinting may
obstruct the GPS signals. Most window
tinting contains some metallic content
that will interfere with GPS signal recep-
tion of the antenna in the instrument
panel. We advise against the use of win-
dow tinting on vehicles equipped with
navigation systems.

212
Your destination point might be shown on
the opposite side of the street.
When a portion of the route has regula-
tions prohibiting the entry of the vehicle
that vary by time or season or other rea-
sons.
The road and map data stored in your nav-
igation system may not be complete or
may not be the latest version.
After replacing the tire, implement the
operation described in the “ Current
position/tire change calibration”. (See
page 87.)
This navigation system uses tire turning data
and is designed to work with factory−speci-
fied tires for your vehicle. Installing tires that
are larger or smaller than the originally
equipped diameter may cause inaccurate
display of the vehicle’s position. The tire pres-
sure also affects the diameter of the tires so
please make sure the tire pressure of all four
tires is correct.
Map database information and
updates
This system uses the maps of DENSO.
© 2006 DENSO CORPORATION
© 2005 NAVTEQ. All rights reserved.
© 2005 Tele Atlas North America, Inc. All
rights reserved. This material is propri-
etary and the subject of copyright protec-
tion and other intellectual property rights
owned by or licensed to Tele Atlas North
America, Inc. The use of this material is
subject to the terms of a license agree-
ment. You will be held liable for any unau-
thorized copying or disclosure of this ma-
terial.
Data by infoUSA Copyright © 2005, All
Rights Reserved.
©2005 VISA Corporation
National Research Bureau ©2005
The Bullseye Design is a registered
trademark of Target Brands, Inc.
END USER TERMS
The data (“Data”) is provided for your
personal, internal use only and not for re-
sale. It is protected by copyright, and is
subject to the following terms and condi-
tions which are agreed to by you, on the
one hand, and DENSO CORPORATION
(“[CLIENT]”) and its licensors (including
their licensors and suppliers) on the other
hand.
© 2005 NAVTEQ. All rights reserved.
The Data for areas of Canada includes
information taken with permission from
Canadian authorities, including: © Her
Majesty the Queen in Right of Canada, ©
Queen’s Printer for Ontario, © Canada
Post Corporation, GeoBase.
NAVTEQ holds a non−exclusive license
from the United States Postal Service
to publish and sell ZIP+4 information.
©United States Postal Service 2005.
Prices are not established, controlled or
approved by the United States Postal
Service. The following trademarks and
registrations are owned by the USPS:
United States Postal Service, USPS, and
ZIP+4.

213 TERMS AND CONDITIONS
Personal Use Only. You agree to use this
Data together with the navigation system
for the solely personal, non−commercial
purposes for which you were licensed,
and not for service bureau, time−sharing
or other similar purposes. Accordingly,
but subject to the restrictions set forth in
the following paragraphs, you may copy
this Data only as necessary for your per-
sonal use to (i) view it, and (ii) save it, pro-
vided that you do not remove any copy-
right notices that appear and do not
modify the Data in any way. You agree
not to otherwise reproduce, copy, modify,
decompile, disassemble or reverse engi-
neer any portion of this Data, and may not
transfer or distribute it in any form, for any
purpose, except to the extent permitted
by mandatory laws. Multi−disc sets may
only be transferred or sold as a complete
set as provided by [CLIENT] and not as
a subset thereof.
Restrictions. Except where you have
been specifically licensed to do so by
[CLIENT], and without limiting the pre-
ceding paragraph, you may not (a) use
this Data with any products, systems, or
applications installed or otherwise con-
nected to or in communication with ve-
hicles, capable of vehicle navigation,
positioning, dispatch, real time route
guidance, fleet management or similar
applications; or (b) with or in communica-
tion with any positioning devices or any
mobile or wireless−connected electronic
or computer devices, including without
limitation cellular phones, palmtop and
handheld computers, pagers, and per-
sonal digital assistants or PDAs.
Warning.
The Data may contain inaccu-
rate or incomplete information due to the
passage of time, changing circum-
stances, sources used and the nature of
collecting comprehensive geographic
data, any of which may lead to incorrect
results.
No Warranty. This Data is provided to you
”as is,” and you agree to use it at your
own risk. [CLIENT] and its licensors (and
their licensors and suppliers) make no
guarantees, representations or warran-
ties of any kind, express or implied, aris-
ing by law or otherwise, including but not
limited to, content, quality, accuracy,
completeness, effectiveness, reliability,
fitness for a particular purpose, useful-
ness, use or results to be obtained from
this Data, or that the Data or server will be
uninterrupted or error−free.
Disclaimer of Warranty:
[CLIENT] AND
ITS LICENSORS (INCLUDING THEIR
LICENSORS AND SUPPLIERS)
DISCLAIM ANY WARRANTIES,
EXPRESS OR IMPLIED, OF QUALITY,
PERFORMANCE,
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE OR
NON−INFRINGEMENT. Some States,
Territories and Countries do not allow
certain warranty exclusions, so to that
extent the above exclusion may not apply
to you.

215 NOTICE OF USE
CONTRACTOR (MANUFACTURER/
SUPPLIER) NAME: NAVTEQ
CONTRACTOR (MANUFACTURER/
SUPPLIER) ADDRESS:
222 Merchandise Mart Plaza, Suite
900, Chicago, Illinois 60654
This Data is a commercial item as de-
fined in FAR 2.101 and is subject to the
End User Terms under which this Data
was provided.
© 2005 NAVTEQ − All rights reserved.
If the Contracting Officer, federal gov-
ernment agency, or any federal official
refuses to use the legend provided
herein, the Contracting Officer, federal
government agency, or any federal offi-
cial must notify NAVTEQ prior to seek-
ing additional or alternative rights in the
Data.
END USER LICENSE AGREEMENT
PLEASE READ THIS AGREEMENT
CAREFULLY BEFORE USING THE
NAVIGATION SYSTEM
THIS IS A LICENSE AGREEMENT FOR
YOUR COPY OF THE SPATIAL MAP
DATABASE, INCLUDING LOCATION
CODES AND RELATED PRODUCTS
(COLLECTIVELY, THE ”DATABASE”),
USED IN THE NAVIGATION SYSTEM.
BY USING THE NAVIGATION SYSTEM
AND THE DATABASE, YOU ACCEPT
AND AGREE TO BE BOUND BY ALL
TERMS AND CONDITIONS SET
FORTH BELOW.
LICENSE GRANT
Denso Corporation (“Denso”), as a
licensed distributor of the DATABASE,
grants to you a non−exclusive,
non−perpetual license to use your copy
of the DATABASE for your personal use
or for your use in your business’ internal
operations and not for any other purpose.
This license does not include the right to
grant sub−licenses.OWNERSHIP
The DATABASE and the copyrights and
intellectual property and neighboring
rights therein are owned by Tele Atlas
North America, Inc. (“TANA”) and its
licensors. This Agreement does not
transfer any title or interest in the
DATABASE, except for the license to use
the DATABASE according and subject to
the terms and conditions of this
Agreement. You shall not alter, obscure
or remove any copyright notices,
trademark notices or other restrictive
legends relating to the DATABASE.
The DATABASE comprises confidential
and proprietary information and materi-
als of TANA. Accordingly, you shall hold
the DATABASE in confidence and trust.
You shall take reasonable steps to pro-
tect the DATABASE from misappropri-
ation or misuse. You shall not extract
stand−alone data from or publish any
part of the DATABASE without the prior
written consent of TANA and its licen-
sors.
