MPG TOYOTA TUNDRA 2007 2.G Owners Manual

1872007 TUNDRA from Jul. ’07 Prod. (OM34463U)
The following information is displayed
on the multiinformation display when
the ignition switch is turned to the
“ON” position.
Cruise information
Odometer and two trip meters
Warning messages
Feature customization
During ordinary driving, cruise information
is displayed. However, in case the vehicle
has a system malfunction or if there is
some information that the driver should be
informed of, a warning message appears
on the display. See “—Warning messages”
on page 193 for details.
If the electrical power source has been
disconnected from the cruise information
display, the display will automatically be
set to the initial mode.
When the instrument panel lights are
turned on, the brightness of the display
will be reduced.
At extremely low temperatures, the multi −
information display may respond slowly,
and the display changes may be delayed.
CAUTION
Do not adjust the display while the
vehicle is moving. Be sure to adjust
the display only when the vehicle is
stopped.
SELECTING UNIT
You can select the unit between En-
glish/U.S. customary system and metric
unit.
To select unit A (English/U.S. customary
system) or unit B (metric unit), push
“SELECT RESET” button to display
“UNITS” screen, and push “SETUP US/M”
button while the screen is displayed.
The unit variations are as follows;
Information
Unit AUnit B
Average fuel
consumption and
Instantaneous fuel
consumption
MPGL/100km
Driving rangeMILESkm
Average vehicle
speedMPHkm/h
Multiinformation display—

3992007 TUNDRA from Jul. ’07 Prod. (OM34463U)
Operate the accessory meter with the
ignition switch on.
When the ignition switch is turned to
“ON”, the last previously used mode dis-
played just before the ignition switch is
turned off will appear.
When the instrument panel lights are
turned on, the brightness of the display
will be reduced.
CAUTION
Do not adjust the display while the
vehicle is moving. Be sure to adjust
the display only when the vehicle is
stopped.
SELECTING UNIT
You can select the unit between En-
glish/U.S. customary system and metric
unit.
To select the unit A (English/U.S. custom-
ary system) or unit B (metric unit), push
“SETUP US/M” button.
The unit variations are as follows:Information
Unit AUnit B
Average fuel
consumption and
Instantaneous
fuel consumption
MPGL/100 km
Driving rangeMILESkm
Outside
temperatureFC
XS10003b
The displayed temperature ranges from
− 40 C ( −40 F) up to 50 C (122 F).
The ignition switch must be in the “ON”
position.
If an abnormality exists in the connection
of the outside air temperature sensor,
“ −−− C” (“ −−−F”) will appear on the dis-
play. If “ −−−C” (“ −−−F”) appears on the
display, contact your Toyota dealer.
There may be a case that “−−− C”
(“−−− F”) appears momentarily when the
ignition switch is quickly turned to “ON”.
It is normal if it goes out soon.
—Before using the accessory
meter —Outside temperature display
(without cruise information)

4002007 TUNDRA from Jul. ’07 Prod. (OM34463U)
XS10004e
The outside temperature display and
cruise information display indicates the
following information.
Every time you push the “INFO” button,
the display toggles through this infor-
mation.1. Outside temperature
2. Average fuel consumption
3. Instantaneous fuel consumption
4. Driving range
5. Display off
The displayed values in the cruise infor-
mation display indicate general driving
conditions. Accuracy varies with driving
habits and road conditions.
To set the unit, push the “SETUP US/M”
button until the desired unit display ap-
pears.
When the ignition switch is on, the last
previously used mode displayed just be-
fore the ignition switch is off will appear. 1. Outside temperature (“OUTSIDE
F”
or “OUTSIDE C”)
The outside temperature display indicates
the outside air temperature.
The displayed temperature ranges from
− 40 C ( −40 F) up to 50 C (122 F).
If an abnormality exists in the connection
of the outside air temperature sensor,
“ −−− C” (“ −−−F”) will appear on the dis-
play. If “ −−−C” (“ −−−F”) appears on the
display, contact your Toyota dealer.
There may be a case that “−−− C”
(“−−− F”) appears momentarily when the
ignition switch is quickly turned to the
“ON” position. It is normal if it goes out
soon.
2. Average fuel consumption (“AVG MPG” or “AVG L/100 km”)
Average fuel consumption is calculated
and displayed based on total driving
distance and total fuel consumption
with the engine running.
The displayed value is updated about ev-
ery 10 seconds.
To reset the calculation, push the
“SELECT RESET” button about 2 second.
—Outside temperature and
cruise information display

4012007 TUNDRA from Jul. ’07 Prod. (OM34463U)
3. Instantaneous fuel consumption(“INST MPG” or “INST L/100 km”)
The instantaneous fuel consumption is
calculated and displayed based on dis-
tance and fuel consumption at 20 revo-
lutions of the engine.
The displayed value is updated for a short
time.
An accurate figure may not be shown if
the vehicle is driving down a long slope,
and engine brake is applied. (The display
will indicate the extremely low fuel con-
sumption.)
When the vehicle is stopped with the en-
gine running, “ −−, −MPG” will be shown
on the display.
The calculation is reset when the ignition
switch is turned off. 4. Driving range (“RANGE MI” or
“RANGE km”)
The distance the vehicle can travel with
the remaining fuel is calculated and
displayed based on the quantity of re-
maining fuel and past fuel consumption.
The driving range display indicates the
approximate distance that you can drive
until the fuel gauge reaches “E”. It is
different from the actual distance traveled.
The displayed value is updated every time
the fuel equivalent for 1 mile or 1 km is
consumed.
Every time you refuel the vehicle, the cal-
culation is reset.
The actual driving range varies with driv-
ing habits and road conditions. If fuel con-
sumption is good, the driving range will be
longer than indicated. If fuel consumption
is poor, the driving range will be shorter
than indicated.
If the low fuel level warning light comes
on, refuel the vehicle even if the display
indicates that the vehicle can be driven
further.
—Clock
XS10002
Type A (with cruise information)
XS10074
Type B (without cruise information)
