USB TOYOTA TUNDRA 2012 2.G Navigation Manual

7
4 My Places
Navigation settings102
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Setting up the “Home” 103 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting up the “Preset Destinations” 105
. . . . . . . . . . . . . . . . . . . . . .
Setting up the “Address Book” 108
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting up the “Areas to Avoid” 114
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting previous destinations 119
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Telephone and Information
Telephone (Handsfree system for cellular phone) 122
. . . . . . . . .
Enter a Bluetooth  phone 127 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Call on the Bluetooth  phone 132 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Receive on the Bluetooth  phone 139 . . . . . . . . . . . . . . . . . . . . . . . .
Talk on the Bluetooth  phone 139 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Calendar 142 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
6 Audio/video system
Quick reference 144
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Using your audio/video system 145
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Some basics 145
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Radio operation 153
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
CD changer operation 164
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth  audio operation 176
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVD player operation 185
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
USB memory/iPod operation 211
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video remote controls 218
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints 220
. . . . . . . . . . . . . . . . . . . . . . . . .
7 Rear View Monitor System
Rear view monitor system 230
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SECTION 6
AUDIO/VIDEO SYSTEM
143
AUDIO/VIDEO SYSTEM
Audio/video system
Quick reference 144 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
 Using your audio/video system 145
. . . . . . . . . . . . . . . . . . . . . . .
Some basics 145 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Radio operation 153 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

CD changer operation 164 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bluetooth  audio operation 176 . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVD player operation 185 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
USB memory/iPod operation 211 . . . . . . . . . . . . . . . . . . . . . . . . .
 Audio/video remote controls 218 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Audio/video system operating hints 220 . . . . . . . . . . . . . . . . . . . . . .

AUDIO/VIDEO SYSTEM
144
Operations such as selecting a preset station and adjusting the sound balance are c\
ar-
ried out on the touch screen. To display the audio screen, push the “AUDIO” button.
U6001AHSTN
1Function menu display screen
To control the radio, CD changer,
DVD player
∗, Bluetooth audio
player, AUX or USB memory/iPod,
touch the touch− screen buttons. For
details, see page 148.
2Function menu tab
To control the radio, CD changer,
DVD player
∗, Bluetooth audio
player, AUX or USB memory/iPod,
touch the touch −screen tabs. For
details, see page 147.
3“TUNE·FILE” knob
Turn this knob to move the station
band and files up or down. For de-
tails, see pages 154, 159 and 172.
4“FM” button
Push this button to choose an FM sta-
tion. Each time this button is pushed,
the mode switches between FM1 and
FM2. For details, see pages 147 and
153.
∗: Vehicles with rear seat entertainment system
Quick reference

AUDIO/VIDEO SYSTEM
145
5“AM” button
Push this button to choose an AM sta-
tion. For details, see pages 147 and
153.
6“SAT” button
Push this button to choose an SAT
station. For details, see pages 147
and 159.
7“DISC/AUX” button
Push this button to turn the CD
changer, DVD player
∗, Bluetooth
audio player, AUX or USB
memory/iPod on. For details, see
pages 147, 153, 167, 182 and 187.
8“AUDIO” button
Push this button to display the audio
control screen. For details, see page
147.
9“LOAD/CLOSE” button
Push this button to display the
“Load·Eject” screen or close the dis-
play. For details, see page 164.
10“SEEK/TRACK” button
Push either side of this button to seek
up or down for a station, or to access
a desired track, file or chapter. For
details, see pages 155, 168, 172,
183, 188 and 191.
11“PWR·VOL” knob
Push this knob to turn the audio sys-
tem on and off, and turn it to adjust the
volume. For details, see page 147. This section describes some of the basic
features of your audio system. Some in-
formation may not
pertain to your system.
Your audio system works when the engine
switch is turned to the “ACC” or “ON” posi-
tion.
CAUTION
For vehicles sold in U.S.A. and Cana-
da:
Part 15 of the FCC Rules
FCC Warning:
Changes or modifications in
construction not expressly approved
by the party responsible for com-
pliance could void the user’s author-
ity to operate the equipment. Radio
frequency exposure. This device is
approved for Mobile Application only
and, to comply with applicable FCC
radio frequency exposure regula-
tions, must be used with a distance of
at least 7.9 in. (20 cm) between the an-
tenna and the body of any person at
all time during use.
∗: Vehicles with rear seat entertainment system
Using your audio/video
system —
— Some basics

AUDIO/VIDEO SYSTEM
147
(b) Turning the system on and off
U023AHNS
“AUDIO”: Push this button to display
touch−screen buttons for audio system
(audio control mode).
“PWR·VOL”: Push this knob to turn the
audio system on and off. Turn this knob to
adjust the volume. The system turns on in
the last mode used.
You can select the function that enables
automatic return to the previous screen
from the audio screen. See page 236 for
details. (c) Switching between functions
U033AHNS
Push the “AM”, “FM”, “SAT”or
“DISC/AUX” button to turn on the
desired mode.
U6080GS
Push
the “AUDIO” button and touch the
“AM”, “FM”, “SAT”, “CD”, “DVD∗”,
“BT”, “AUX”or “USB” tab to turn on the
desired mode.
∗: Vehicles with rear seat entertainment system

AUDIO/VIDEO SYSTEM
149
U6084GS
U6086GS
U6085GS
U6078GS
U6079GS
The touchscreen buttons for radio, CD
changer, DVD player∗, Bluetooth au-
dio player, AUX and USB memory/iPod
operation are displayed on the function
touchscreen button display screen
when the audio control mode is se-
lected. Touch them lightly and directly
on the screen.
Touch the tab to select the desired mode
when the audio control mode is selected.
The selected switch is highlighted.
INFORMATION
If the system does not respond to a
touch of a touchscreen button,
move your finger away from the
screen and then touch it again.
You cannot operate dimmed
touchscreen buttons.
Wipe off fingerprints using a glass
cleaning cloth. Do not use chemi-
cal cleaners to clean the touch
screen.
∗: Vehicles with rear seat entertainment system

AUDIO/VIDEO SYSTEM
153
(h) Your DVD player
(with rear seat entertainment system)
The sound of the rear seat entertainment
system can be enjoyed by pushing the
“DISC/AUX” button or touching the
“DVD” tab on AUDIO screen.
(i) AUX port
The sound of portable audio players
connected to the AUX port can be enjoyed.
Push the “DISC/AUX” button or push the
“AUDIO” button to display audio screen
and touch the “AUX” tab to switch to AUX
mode. When the portable audio player is
not connected to the AUX port, the tab will
tone down. For details, refer to the
“Owner’s Manual”.
(j) USB port
It is necessary to connect the USB
memory/iPod with the USB port. When the
USB memory/iPod is not connected to the
USB port, the tab will tone down. (a) Listening to the radio
U013AHNS
Push
the “AM” or “FM” buttons or push
the “AUDIO” button to display audio
screen and touch the “AM” or “FM”
tabs to choose either an AM or FM sta-
tion.
“AM”, “FM1” or “FM2” appears on the
screen.
If your vehicle is equipped with a satellite
radio broadcast system, when you push
the “SAT” button or touch the “SAT” tab
on AUDIO screen, “SAT1”, “SAT2”, “SAT3”
station appears on the display. For details
about satellite radio broadcast, see
“—Radio operation (XM  Satellite Radio
broadcast)” on page 158.
— Radio operation

AUDIO/VIDEO SYSTEM
211
Connecting a USB memory or iPod en-
ables you to enjoy music from the ve-
hicle speakers.
CAUTION
Do not operate the player’s controls
or connect the USB memory or iPod
while driving.
NOTICE
Do not leave your portable player in
the car. In particular, high tempera-
tures inside the vehicle may dam-
age the portable player.
Do not push down on or apply un-
necessary pressure to the portable
player while it is connected as this
may damage the portable player or
its terminal.
Do not insert foreign objects into
the port as this may damage the
portable player or its terminal.
(a) Connecting a USB memory or iPod
U024AHNS
Open the cover and connect a USB
memory or iPod using an iPod cable.
Turn on the power of the USB memory or
iPod if it is not turned on. (b) Playing a USB memory or iPod
Playing and pausing a file or track
U6078GS

USB memory
U6079GS
iPod
Touch “U SB” tab to display this screen
if the USB memory or iPod is already
connected.
Touch
and the music will start playing.
Touch
and the music will pause.
Touch
and the music will start playing
again.
— USB memory/
iPod operation

AUDIO/VIDEO SYSTEM
212
INFORMATION
When an iPod is connected and the
audio source is changed to iPod
mode, the iPod will resume play
from the same point in which it was
last used.
 When the USB memory is con-
nected and the audio source is
changed to USB memory mode,
the USB memory will start playing
the first file in the first folder. If the
same device is removed and rein-
serted (and the contents have not
been changed), the USB memory
will resume play from the same
point in which it was last used.
 Depending on the iPod or USB
memory that is connected to the
system, certain functions may not
be available.
Selecting a play mode (iPod only)
U6079GS
1. Touch “Menu”.
2. Select the desired play mode.

AUDIO/VIDEO SYSTEM
213

Selecting a desired folder (USB
memory only)
U6078GS
“Folder
\b”: Touch this button to go to the
next folder.
“Folder ”: Touch this button to go to the
previous folder.
“Select” for Folder: The desired folder
can be selected in a list. This function is
available only when the vehicle is not mov-
ing.
Touch “Select” . The folder list is dis-
played.
Touch the desired folder number. The play-
er will start playing the first file of the se-
lected folder.
: By touching this touch−screen but-
ton, the list moves up by 5 folder groups.
If this touch−screen button is touched
when the top page of the list is displayed,
the last page is displayed.
: By touching this touch−screen but-
ton, the list moves down by 5 folder
groups. If this touch−screen button is
touched when the last page of the list is
displayed, the top page is displayed.
