TOYOTA TUNDRA 2014 2.G Owners Manual

551
10
For owners
When the truck is used to carry a slide-in camper, the total cargo load
of the truck consists of the manufacturer’s camper weight figure, the
weight of installed additional camper equipment not included in the
manufacturer’s camper weight figure, the weight of camper cargo, and
the weight of passengers in the camper.
The total cargo load should not exceed the truck’s cargo weight rating
and the camper’s center of gravity should fall within the truck’s recom-
mended center of gravity zone when installed.
Camper center of gravity
Recommended center of grav-
ity location zone
Regular Cab models
42.6 in. (1082mm)37.6 in. (955 mm)Double Cab models
CrewMax models
CAUTION
■Loading precaution
If a load is too far back, it can cause dangerous handling. If it is too far for-
ward, the front axle may be overloaded.
Cargo weight rating and proper matching
1
2

552
■Cargo weight ratingCWR: Cargo Weight Rating
EngineDriveCabBedGradePassenger numberC.W.R
(lbs)(kg)
1GR-FE2WD
RegularLongSR5
31180535
3UR-FE31445655
3UR-FE &
3UR-FBE
4WD31385628
1GR-FE2WD
Double
StandardSR56440200
1UR-FE2WDStandardSR56510231
4WDSR56420191
3UR-FE2WDStandardSR56620281
LT D5740336
LongSR56590268
3UR-FE &
3UR-FBE
4WDStandardSR56530240
LT D5670304
LongSR56510231
1UR-FE2WD
Crew MaxShort
SR56425193
4WDSR56325147
3UR-FE2WD
SR56510231
LT D5645293
Plati-num5645293
3UR-FE &
3UR-FBE
4WD
SR56430195
LT D5555252
Plati- num5555252

553
10
For owners
Secure loose items to prevent weight shifts that could affect the bal-
ance of your vehicle. When the truck camper is loaded, drive to a
scale and weigh on the front and on the rear wheels separately to
determine axle loads. Individual axle loads should not exceed either
of the Gross Axle Weight Ratings (GAWR). The total of the axle loads
should not exceed the Gross Vehicl e Weight Rating (GVWR). These
ratings are given on the vehicle certification label wh ich is located on
the door latch post on the left side of the vehicle. ( P. 506) If weight
ratings are exceeded, move or remove items to bring all weights
below the ratings.
Gross axle weight rating
Front GAWR
Rear GAWR
Gross vehicle weight rating
Not exceed GVWR
CAUTION
■ Overloading
Be careful — overloading can cause dangerous braking and handling prob-
lems, and can damage your vehicle and its tires.
Gross axle and vehicle weight ratings
1
2
1

554
■GAWR and GVWR
Regular Cab models
*:The model code is indicated on the Certification Label. (P. 5 0 6)
Model
code
*EngineDriving
systemBed
typeGAWRGVWRFrontRear
GSK51L-
THASKA 1GR-FE 2WD
Long3900 lb.
(1765 kg) 3800 lb.
(1720 kg) 6400 lb.
(2900 kg)
USK51L-
THTSKA 3UR-FE2WD
3900 lb.
(1765 kg)4150 lb.
(1880 kg)7000 lb.
(3175 kg)
USK56L-
THTSKA 4WD
4000 lb.
(1810 kg)4150 lb.
(1880 kg)7200 lb.
(3265 kg)
USK56L-
THTSGA 3UR-FBE 4WD
4000 lb.
(1810 kg)4150 lb.
(1880 kg)7200 lb.
(3265 kg)

555
10
For owners
Double Cab models
*:The model code is indicated on the Certification Label. (P. 5 0 6)
Model
code
*EngineDriving
systemBed
typeGAWRGVWRFrontRear
GSK51L-
CRASKA 1GR-FE 2WD Stan-
dard 3900 lb.
(1765 kg) 3800 lb.
(1720 kg) 6400 lb.
(2900 kg)
UPK51L-
CRTSKA 1UR-FE2WD
Stan-
dard 3900 lb.
(1765 kg) 4000 lb.
(1810 kg) 6700 lb.
(3035 kg)
UPK56L-
CRTSKA 4WD
4000 lb.
(1810 kg)4100 lb.
(1855 kg)6900 lb.
(3125 kg)
USK51L-
CRTSKA
3UR-FE2WD
Stan-
dard
3900 lb.
(1765 kg)
4100 lb.
(1855 kg)6900 lb.
(3125 kg)
USK51L-
CRTLKA
USK52L-
CHTSKA Long
4150 lb.
(1880 kg)7000 lb.
(3175 kg)
USK56L-
CRTSKA
4WDStan-
dard
4000 lb.
(1810 kg)4150 lb.
(1880 kg)
7100 lb.
(3220 kg)
USK56L-
CRTLKA
USK57L-
CHTSKA Long
7200 lb.
(3265 kg)
USK56L-
CRTSGA
3UR-FBE 4WD Stan-
dard
4000 lb.
(1810 kg)4150 lb.
(1880 kg)
7100 lb.
(3220 kg)
USK56L-
CRTLGA
USK57L-
CHTSGA Long
7200 lb.
(3265 kg)

556
CrewMax models
*:The model code is indicated on the Certification Label. (P. 5 0 6)
Model
code
*EngineDriving
systemBed
typeGAWRGVWRFrontRear
UPK51L-
PSTSKA 1UR-FE2WD
Short3900 lb.
(1765 kg) 4050 lb.
(1835 kg) 6800 lb.
(3080 kg)
UPK56L-
PSTSKA 4WD
4000 lb.
(1810 kg)4150 lb.
(1880 kg)7000 lb.
(3175 kg)
USK51L-
PSTSKA
3UR-FE2WD
3900 lb.
(1765 kg)
4150 lb.
(1880 kg)
7000 lb.
(3175 kg)
USK51L-
PSTLKA
USK51L-
PSTZKA
USK56L-
PSTSKA
4WD
4000 lb.
(1810 kg)7200 lb.
(3265 kg)
USK56L-
PSTLKA
USK56L-
PSTZKA
USK56L-
PSTSGA
3UR-FBE 4WD
4000 lb.
(1810 kg)4150 lb.
(1880 kg)7200 lb.
(3265 kg)
USK56L-
PSTLGA
USK56L-
PSTZGA

557
Index
What to do if... (Troubleshooting) .................... 558
Alphabetical index ..................... 561
For vehicles with Entune Audio Plus or Entune Premium Audio,
refer to the “NAVIGATION SYSTEM OWNER’S MANUAL” for
information regarding the multimedia system.
Multimedia system types: P. 250

558What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys, new genuine keys can be made by your Toyota
dealer. (P. 100)
●Is the wireless key battery weak or depleted? ( P. 434)
●The function may not operate properly due to the condition of the radio
wave. (P. 104)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (P. 106)
●Is the shift lever in P? ( P. 179)
●Is the battery discharged? ( P. 493)
●Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in the “ON” position. ( P. 491)
If you have a problem, check th e following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened
If you think something is wrong The engine does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal

559What to do if... (Troubleshooting)
●It is locked to prevent theft of the vehicle if the key is removed from the
engine switch. (P. 180)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 136)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( P. 466)
●The parking brake indicator is on
Is the parking brake released? (P. 187)
Depending on the situation, other types of warning buzzer may also sound.
( P. 464, 472)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 80)
To stop the alarm, turn the engine switch to the “ACC” or “ON” position, or
start the engine.
●When a warning light turns on or a warning message is displayed, refer to
P. 464, 472.
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning light turns on or a warning message is displayed

560What to do if... (Troubleshooting)
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
