TOYOTA TUNDRA 2021 Owners Manual (in English)

591
9
For owners
Secure loose items to prevent weight shifts that could affect the bal-
ance of your vehicle. When the truck camper is loaded, drive to a
scale and weigh on the front and on the rear wheels separately to
determine axle loads. Individual axle loads should not exceed e ither
of the Gross Axle Weight Ratings (GAWR). The total of the axle loads
should not exceed the Gross Vehicle Weight Rating (GVWR). These
ratings are given on the vehicle certification label which is located on
the door latch post on the le ft side of the vehicle. (P. 541) If weight
ratings are exceeded, move or remove items to bring all weights
below the ratings.
Gross axle weight rating
Front GAWR
Rear GAWR
Gross vehicle weight rating
Not exceed GVWR
WARNING
■ Overloading
Be careful — overloading can cause dangerous braking and handli ng prob-
lems, and can damage your vehicle and its tires.
Gross axle and vehicle weight ratings
1
2
1

592
■GAWR and GVWR
Double Cab models
*:The model code is indicated on the Certification Label. (P. 5 4 1)
CrewMax models
*:The model code is indicated on the Certification Label. (P. 5 4 1)
Model
code
*EngineDriving
systemBed
typeGAWRGVWRFrontRear
USK51L-
CRTSKA
3UR-FE2WD
Stan-
dard 3900 lb.
(1770 kg) 4100 lb.
(1860 kg) 6900 lb.
(3130 kg)
USK51L-
CRTLKA
USK52L-
CHTSKA Long
4150 lb.
(1880 kg)
7000 lb.
(3175 kg)
USK56L-
CRTSKA
4WDStan-
dard
4000 lb.
(1815 kg)
7100 lb.
(3220 kg)
USK56L-
CRTLKA
USK57L-
CHTSKA Long
7200 lb.
(3265 kg)
Model code
*EngineDriving
systemBed
typeGAWRGVWRFrontRear
USK51L-
PSTSKA
3UR-FE2WD
Short3900 lb.
(1770 kg)
4150 lb.
(1880 kg) 7000 lb.
(3175 kg)
USK51L-
PSTLKA
USK51L-
PSTZKA
USK56L-
PSTSKA
4WD
4000 lb.
(1815 kg)7200 lb.
(3265 kg)
USK56L-
PSTLKA
USK56L-
PSTZKA

593
Index
What to do if... (Troubleshooting) .................... 594
Alphabetical index ..................... 598
For details of equipment related to the audio/navigation system ,
refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

594What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine mechanical keys
can be made by your Toyota dealer. ( P. 123)
●If you lose your keys or electronic keys, the risk of vehicle t heft increases
significantly. Contact your Toyota dealer immediately. ( P. 126)
●Is the wireless key battery weak or depleted? (P. 451)
●Vehicles with a smart key system:
Is the engine switch in ON?
When locking the doors, turn the engine switch off. ( P. 220)
●Vehicles with a smart key system:
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of t he radio
wave. ( P. 123)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. ( P. 131)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

595What to do if... (Troubleshooting)
●Is the shift lever in P? (P. 217)
●Is the battery discharged? ( P. 525)
●Did you press the engine switch while firmly depressing the bra ke pedal?
( P. 219)
●Is the shift lever in P? ( P. 222)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 139)
●Is the steering wheel unlocked? (P. 222)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. ( P. 523)
●Is the battery discharged? (P. 525)
●Is the engine switch in ON?
If you cannot release the shift lever by depressing the brake p edal with the
engine switch in ON. ( P. 229)
If you think something is wrong
The engine does not start
(vehicles without a smart key system)
The engine does not start
(vehicles with a smart key system)
The shift lever cannot be shifted from P even if you depress
the brake pedal

596What to do if... (Troubleshooting)
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is removed from the
engine switch. ( P. 218)
●Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( P. 222)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 172)
●The auto power off function will be operated if the vehicle is left in ACC or
ON (the engine is not running) for a period of time. ( P. 221)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 486)
●The parking brake indicator is on
Is the parking brake released? ( P. 233)
Depending on the situation, other types of warning buzzer may also sound.
( P. 485, 493)
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
The engine switch is tur ned off automatically
(vehicles with a smart key system)
A warning buzzer sounds during driving

597What to do if... (Troubleshooting)
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. (P. 493)
●Did anyone inside the vehicle open a door during setting the al arm?
The sensor detects it and the alarm sounds. ( P. 95)
To stop the alarm, turn the engine switch to ACC or ON, or start the engine.
●When a warning light turns on or a warning message is displayed , refer to
P. 485, 493.
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
( P. 506)
●Try the procedure for when the vehicle becomes stuck in mud, di rt, or
snow. ( P. 532)
A warning buzzer sounds w hen leaving the vehicle
(vehicles with a smart key system)
An alarm is activated and the horn sounds
A warning light turns on or a warning message or indicator
is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

598Alphabetical index
Alphabetical index
A/C .................................... 340, 347Air conditioning filter ............. 448
Automatic air conditioning system ......... ....................... 347
Manual air conditioning system ......... ....................... 340
ABS (Anti-lock Brake
System) .................................. 320 Function ................................ 320
Warning light ......................... 486
Air conditioning filter .............. 448
Air conditioning system ............................ 340, 347
Air conditioning filter ............. 448
Automatic air conditioning system ......... ....................... 347
Manual air conditioning system ......... ....................... 340
Airbags ....................................... 40
Airbag operating conditions .... 49
Airbag precautions for your child ......................... 44
Airbag warning light .............. 485
Correct driving posture ........... 32
Curtain shield airbag operating conditions ............. 49
Curtain shield airbag precautions ........................... 45
Front passenger occupant classification syst em............. 53
General airbag precautions .... 44
Locations of airbags................ 40 Modification and disposal
of airbags ............................. 47
Side airbag operating
conditions ............................. 49
Side airbag precautions .......... 45
Side and curtain shield airbags operating
conditions ............................. 49
Side and curtain shield airbags precautions .............. 45
SRS airbags ........................... 40
Alarm Alarm ...................................... 95
Warning buzzer ............ 485, 493
Anchor brackets ........................ 63
Antennas (smart key system) ............... 138
Anti-lock Brake System (ABS) ...................................... 320
Function ................................ 320
Warning light......................... 486
Armrest..................................... 383
Assist grips .............................. 384
Audio input
*
Audio remote control switches*
AUX port*
AUTO LSD system................... 318
Automatic High Beam ............. 239
Automatic light control
system.................................... 234
Automatic transmission
Automatic transmission ........ 225
If the shift lever cannot be shifted from P ..................... 229
TOW/HAUL switch................ 228
AUX port
*
Auxiliary boxes ........................ 373
A

599Alphabetical index
Back windowBack window ......................... 175
Power back window .............. 176
Back-up lights
Replacing light bulbs............. 468
Wattage ................................ 550
Battery ...................................... 422
If the vehicle battery is discharged .......................... 525
Preparing and checking
before winter....................... 331
Warning light ......................... 485
Blind Spot Monitor (BSM) ....... 305
Bluetooth
®*
Bottle holders .......................... 372
Brake
Fluid ...................................... 420
Parking brake........................ 233
Warning buzzer..................... 485
Warning light ......................... 485
Brake assist ............................. 320
Brake Override System ........... 185
Break-in tips ............................. 186
Brightness control Instrument panel light
control................................. 107
BSM (Blind Spot Monitor) ....... 305 Blind Spot Monitor
function ............................... 309
Rear Cross Traffic Alert function ............................... 312 Camper information ................ 588
Card holder .............................. 364
Care .................................. 400, 403
Aluminum wheels ................. 400
Exterior ................................. 400
Interior .................................. 403
Seat belts.............................. 404
Cargo capacity......................... 195
Cargo lamp Light switch ........................... 359
Replacing light bulbs ............ 470
Wattage ................................ 550
CD player
*
Certification label ............ 200, 541
Chains ...................................... 332
Child restraint system............... 59
Booster seats, definition ......... 60
Booster seats, installation....... 69
Convertible seats, definition ... 60
Convertible seats, installation ............................ 68
Front passenger occupant
classification syst em ............ 53
Infant seats, definition............. 60
Infant seats, installation .......... 67
Installing CRS with LATCH anchors ............ 65
Installing CRS with seat
belts...................................... 67
Installing CRS with top tether strap........ 70, 73
BC
*: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER
’S MANUAL”.

600Alphabetical index
Child safety ................................ 58Airbag precautions .................. 44
Battery precautions ............... 527
Child restraint system ............. 59
How your child should wear the seat belt ................. 36
Installing child restraints ......... 63
Moon roof precautions .......... 182
Power back window precautions ......................... 178
Power window lock switch .... 172
Power window precautions ... 174
Rear door child-protector ...... 131
Removed wireless remote control battery
precautions ......................... 453
Seat belt extender precautions ........................... 39
Seat belt precautions .............. 62
Seat heater precautions........ 355
Child-protectors....................... 131
Cleaning ........................... 400, 403 Aluminum wheels.................. 400
Exterior ................................. 400
Interior................................... 403
Seat belts .............................. 404
Clock
*
Compass .................................. 394
Condenser ................................ 420
Console box ............................. 363
Coolant ..................................... 418 Capacity ................................ 545
Checking ............................... 418
Preparing and checking before winter....................... 331
Cooling system ........................ 418 Engine overheating ............... 529
CRS ............................................. 59 Cruise control
Cruise control ....................... 294
Dynamic radar cruise control ...................... 280
Cup holders ............................. 370
Curtain shield airbags............... 41
Customizable features ............ 564
Daytime running light system.................................... 237
Deck hooks .............................. 377
Defogger Back window................. 342, 349
Outside rear view mirrors ........................ 342, 349
Windshield .................... 342, 349
Differential................................ 546
Dimensions .............................. 536
Dinghy towing.......................... 216
Display Drive information .................. 111
Dynamic radar
cruise control ...................... 280
LDA
(Lane Departure Alert) ....... 272
Multi-information display ....... 110
Trip information..................... 110
Warning message................. 493
Do-it-yourself maintenance .... 412
Door lock .................................. 127 Doors .................................... 127
Key ....................................... 127
Smart key system ................. 128
Wireless remote control ........ 128
D
