36 1-2. Opening, closing and locking the doors
VENZA_OM_OM73023U_(U)
■Switching the door unlock function
It is possible to set which doors the entry function unlocks.
Turn the “ENGINE START STOP” switch OFF.
When the indicator on the key surface is turned off, press and hold or for approximately 5 seconds while pressing on
the key.
The setting changes each time an operation is performed, as shown below.
(When changing the setting continuously, release the buttons, wait for at least
5 seconds, and repeat .)
For vehicles equipped with an alarm:
To prevent unintended triggering of the alarm, unlock the doors
using the wireless remote control and open and close a door once
after the settings have been changed. (If a door is not opened
within 60 second after is pressed, the doors will be locked
again and the alarm will automatically be set.)
In case that the alarm is triggered, immediately stop the alarm.
(P. 112)
STEP1
STEP2
STEP2
Multi-information
display
(TFT type only)
Unlocking functionBeep
Hold the driver’s door han-
dle to unlock only the
driver’s door. Exterior: Beeps three
times
Interior: Pings once
Hold the front passenger’s
door handle to unlock all
doors.
Hold either front door han-
dle to unlock all doors. Exterior: Beeps twice
Interior: Pings once
STEP3

39
1-2. Opening, closing and locking the doors
1
Before driving
VENZA_OM_OM73023U_(U)
●
Even if the electronic key is not inside the vehicle, it may be possible to
start the engine if the electronic key is near the window.
● The doors may unlock or lock if a large amount of water splashes on the
door handle, such as in the rain or in a car wash when the electronic key
is within the effective range. (The doors will automatically be locked after
approximately 60 seconds if the doors are not opened and closed.)
● If the key is kept near the vehicle while it is being washed, water applied
to a door handle may cause the door to lock and unlock repeatedly. In
this event, place the key in a location 6 ft. (2 m) or more from the vehicle,
taking care not to lose the key.
● If the key is inside the vehicle while it is being washed, water applied to a
door handle may cause a buzzer to sound. In this event, locking all doors
will cause the buzzer to stop sounding.
● It may not be possible to lock the doors if the sensor area is covered by
mud, ice, snow etc. In this event, try locking again after cleaning the
area, or lock by touching the sensor area on the underside of the door
handle.
● Gripping the door handle when wearing a glove may not unlock or lock
the door.
● If the wireless remote control is used to lock the doors when the elec-
tronic key is near the vehicle, there is a possibility that the door may not
be unlocked by the smart key system. (Use the wireless remote control to
unlock the doors.)
● A sudden approach to the effective range or door handle operation may
prevent the doors from being unlocked. In this case, return the door han-
dle to the original position and check that the doors unlock before pulling
the door handle.

48 1-2. Opening, closing and locking the doors
VENZA_OM_OM73023U_(U)
■Conditions affecting operation
Vehicles with smart key system
P. 3 5
Vehicles without smart key systemThe wireless remote control function may not operate normally in the fol-
lowing situations.
●Near a TV tower, radio station, el ectric power plant, airport or other
facility that generates strong radio waves
●When carrying a portable radio, cellular phone or other wireless com- munication device
●When multiple wireless keys are in the vicinity
●When the wireless key has come into contact with, or is covered by a metallic object
●When a wireless key (that emits radio waves) is being used nearby
●When the wireless key has been left near an electrical appliance such as a personal computer
■ Customization
Settings (e.g. 2-step unlocking function) can be changed.
(Customizable features P. 645)
■ Reversing the operation of the power back door (if equipped)
Pressing the wireless remote control switch again while the power back door
is operating will cause the operation to reverse. However, the reverse opera-
tion cannot be performed for the first second after automatic operation starts,
even if the wireless remote control switch is pressed again.

113
1-6. Theft deterrent system
1
Before driving
VENZA_OM_OM73023U_(U)
■
System maintenance
The vehicle has a maintenance-free type alarm system.
■ Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure
of the following.
●Nobody is in the vehicle.
● The windows and moon roof are closed before the alarm is set.
● No valuables or other personal items are left in the vehicle.
■ Deactivating or stopping the alarm
Do one of the following to deactivate or stop the alarm.
●Unlock the doors using the entry function (vehicles with smart
key system) or the wire less remote control.
● Start the engine. (The alarm will be deactivated or stopped
after a few seconds.)

461
3-5. Other interior features
3
Interior features
VENZA_OM_OM73023U_(U)
■
Programming an entry gate (f or U.S.A. owners)/Programming
all devices in the Canadian market
Place your transmitter 1 to 3 in. (25 to 75 mm) away from the
surface of the HomeLink
.
Keep the HomeLink indicator light in view while programming.
Press and hold the selected HomeLink button.
Repeatedly press and releas e (cycle) the device’s remote
control button for two seconds each until step 4 is completed.
When the indicator light on the HomeLink
 compatible trans-
ceiver starts to flash rapidly, release the buttons.
Test the operation of the HomeLink
 by pressing the newly
programmed button. Check to see if the gate/device operates
correctly.
Repeat the steps above to program another device for each of
the remaining HomeLink
 buttons.
■ Programming other devices
To program other devices such as home security systems, home
door locks or lighting, contact your authorized Toyota dealer for
assistance.
■ Reprogramming a button
The individual HomeLink
 buttons cannot be erased but can be
reprogrammed. To reprogram a bu tton, follow the “Programming”
instructions.
STEP1
STEP2
STEP3
STEP4
STEP5
STEP6

5
When trouble arises
595
5-2. Steps to take in an emergency
VENZA_OM_OM73023U_(U)
If the electronic key does not operate properly (vehicles with smar t key system)
Locking and unlocking the door s and key linked functions
Using the mechanical key
( P. 29) in order to perform
the following operations.
Locks all doors
Unlocks all doors
Turning the key rearward unlocks
the driver’s door. Turning the key
once again within 3 seconds
unlocks the other doors.
If communication between the electronic key and vehicle is inter-
rupted ( P. 30) or the electronic key cannot be used because the
battery is depleted, the smart key system and wireless remote con-
trol cannot be used. In such cases, the doors can be opened or the
engine can be started by following the procedure below.

678 Alphabetical index
VENZA_OM_OM73023U_(U)
Daytime running light system .................................... 214
Defogger
Rear window ......................... 316
Dimension................................. 612
Dinghy towing .......................... 302
Display Fuel consumption information .......................... 210
Shift position and shift range................................... 182
Trip information ............. 194, 206
Warning messages ............... 578
Do-it-yourself main tenance..... 483
Door courtesy lights
Door courtesy lights .............. 430
Wattage ................................. 624
Door lock
Back door ................................56
Side door .................................50
Wireless remote control key ....45
Doors
Back door ................................56
Side door .................................50
Side mirrors .............................92
Driver’s seat belt reminder light ......................................... 567
Driving
Break-in tips .......................... 164
Correct posture ..................... 117
Procedures ............................ 162
Utility vehicle precautions...... 264
Winter driving tips.................. 276
Driving position memory...........73
Electric power steering ........... 256
Electronic key
If your electronic key battery is discharged... 523, 595 Emergency, in case of
If a warning message is displayed ............................ 578
If the electronic key does not operate properly ........... 595
If the engine will not start ...... 590
If the shift lever cannot be
shifted from “P” ................... 593
If the vehicle has discharged
battery ................................ 598
If the warning buzzer sounds ................................ 564
If the warning light turns on ... 564
If you have a flat tire ............. 579
If you lose your keys ............. 594
If you think something is wrong .................................. 561
If your vehicle becomes
stuck ................................... 606
If your vehicle has to be stopped in an emergency ... 608
If your vehicle needs to be
towed .................................. 555
If your vehicle overheats ....... 603
Emergency flashers................. 554
Engine
Compartment ........................ 491
Engine switch ................ 173, 177
Hood ..................................... 487
How to start the engine ......................... 173, 177
Identification number............. 613
If the engine will not start ...... 590
Ignition switch ............... 173, 177
Overheating .......................... 603
Engine coolant Capacity ................................ 618
Checking ............................... 497
Preparing and checking before winter ....................... 276D
E
