2ABOUT THE AUDIO AND NAVIGATION SYSTEM
SCION V398
No.NameFunctionPage
1“MODE” button
Push this button to switch between the
audio (radio, CD, MP3/WMA, AUX,
iPod) and DVD modes, as well as to
turn off the audio system.
124
2“AUDIO” buttonPush this button to display the audio
operation screen.124
3“SOUND” buttonPush this button to adjust and set the
sound quality.127
4“MUTE” buttonPush this button to mute the audio sys-
tem.127
5“TRACK/TUNE”
buttonPush this button to select radio sys-
tem, CD music tracks, iPod music file,
and DVD chapters.134, 137, 142,144, 151, 164
6“ TILT” button
Push this button to open and close the
display, adjust the angle of the display,
and eject discs.
6, 9, 10
Overview of buttons

18BASIC FUNCTIONS
SCION V398
When starting the navigation system, the
current position is displayed first.
This screen displays the current vehicle
position and a map of the surrounding local
area.
The current vehicle position mark (1) ap-
pears in the center or bottom center of the
map screen.
A street name will appear on the bottom of
the screen, depending on the scale of the
map (
2).
You can return to this map screen that
shows your current position at any time
from any screen by pushing the “MAP/
VOICE” button.
While driving, the current vehicle position
mark is fixed on the screen and the map
moves.
The current position is automatically set as
the vehicle receives signals from the GPS
(Global Positioning System). If the current
position is not correct, it is automatically
corrected after the vehicle receives sig-
nals from the GPS.
INFORMATION
D After battery disconnection, or on
a new vehicle, the current position
may not be correct. As soon as the
system receives signals from the
GPS, the correct current position
is displayed.
D To correct the current position
manually, see page 104.
INFORMATION
DRSS− Gen Rules
D Operation is subject to the fol-
lowing two conditions: (1) this
device may not cause interfer-
ence, and (2) this device must
accept any interference, includ-
ing interference that may cause
undesired operation of the de-
vice.
D To reduce potential radio inter-
ference to other users, the an-
tenna type and its gain should
be so chosen that the equivalent
isotropically radiated power
(e.i.r.p.) is not more than that
permitted for successful com-
munication.
D L’utilisation de ce dispositif est
autorisée seulement aux deux
conditions suivantes : (1) il ne
doit pas produire de brouillage,
et (2) l’utilisateur du dispositif
doit être prêt à accepter tout
brouillage radioélectrique reçu,
même si ce brouillage est sus-
ceptible de compromettre le
fonctionnement du dispositif.
D Afin de réduire le risque d’inter-
férence aux autres utilisateurs,
il faut choisir le type d’antenne
et son gain de façon à ce que la
puissance isotrope rayonnée
équivalente (p.i.r.e.) ne soit pas
supérieure au niveau requis
pour l’obtention d’une commu-
nication satisfaisante.
Map screen operation —
— Current position display

SECTIONVII
121
SCION V398
AUDIO/VIDEO SYSTEM
AUDIO/VIDEO SYSTEM
DQuick reference 122 .......................................
D Using your audio/video system 123
........................
Some basics 123 ........................................
Adjusting the volume and the sound quality 126 ..............
Radio operation 134 .....................................
Radio operation (XM satellite radio broadcast) 135 ...........
CD player operation 141 ..................................
DVD player operation 147 ................................
iPod operation 161 ......................................
AUX operation 168 ......................................
D Audio/video remote controls 170
..........................
Steering switches 170 ....................................
D Audio/video system operating hints 171 ......................

122AUDIO/VIDEO SYSTEM
SCION V398
1“MODE” button
Push this button to switch between
the audio (radio, CD, MP3/WMA,
AUX, iPod) and DVD modes, as well
as to turn off the audio system. For
details, see page 124.
2“AUDIO” button
Push this button to display the audio
operation screen. For details, see
page 124.
3“SOUND” button
Push this button to adjust and set the
sound quality. For details, see page
127.
4“MUTE” button
Push this button to mute the audio
system. For details, see page 127.
5“TRACK/TUNE” button
Push this button to select the radio
system, CD music tracks, iPod music
file, and DVD chapters. For details,
see pages 134, 137, 142, 144, 151
and 164.
6“TILT” button
Push this button to open and close
the display, adjust the angle of the
display, and eject discs. For details,
see pages 6, 9 and 10.
7CD disc slot
Load audio CDs and MP3/WMA disc
here. For details, see pages 6
, 141and 143.
8DVD disc slot
Load map DVD −ROMs and DVD vid-
eos here. For details, see pages 6
and 148.
Quick reference

123
SCION V398
AUDIO/VIDEO SYSTEM
9“DISP” button
Push this button to display the “Dis-
play” screen. For details, see page
115.
10“VOL” button
Push this button to adjust the volume
of the audio system. For details, see
page 126.
11Function button display screen
Touch the buttons displayed on the
screen to control the radio, CD player,
DVD player or iPod. For details, see
page 124.This section describes some of the basic
features on SCION audio/video systems.
Your audio/video system works when the
engine switch is in “ACC” or “IG
−ON”
mode.
CAUTION
For vehicles sold in U.S.A. and
Canada:
DPart 15 of the FCC Rules
FCC Warning:
Any unauthorized changes or
modifications to this equipment
will void the user’s authority to op-
erate this device.
DLaser products
DDo not take this unit apart or at-
tempt to make any changes
yourself. This is an intricate unit
that uses a laser pickup to re-
trieve information from the sur-
face of compact discs. The laser
is carefully shielded so that its
rays remain inside the cabinet.
Therefore, never try to disas-
semble the player or alter any of
its parts since you may be ex-
posed to laser rays and danger-
ous voltages.
DThis product utilizes a laser. Use
of controls or adjustments or
performance of procedures oth-
er than those specified herein
may result in hazardous radi-
ation exposure.
NOTICE
To prevent the battery from being dis-
charged, do not leave the audio/video
system on longer than necessary
when the engine is not running.
Using your audio/video
system —
— Some basics

124AUDIO/VIDEO SYSTEM
SCION V398
DTurning on the power
1. Push the “MODE” button.
2. Turn on the power by touching any
one of the audio mode touch−screen
buttons.
When the priority screen is set to naviga-
tion, the operation screen will automatical-
ly be exited from if no operations are per-
formed for approximately 20 seconds or
more after displaying the screen. See “(a)
Automatic transition” on page 117 for de-
tails.
DTurning off the power
Push the “MODE” button and touch
“Audio Off” to turn off the power.
DSwitching between functions
1. Push the “MODE” button.
2. Touch any of the audio mode
switches.
It is not possible to change to AUX, iPod,
or Satellite Radio if they are not connected.
If the disc is not set, the CD player or DVD
player does not turn on.
The selected audio mode will display on
the screen.
The indicator for the currently selected au-
dio mode will illuminate.
Push the “AUDIO” button to display the
respective audio mode operation screen.
You can turn off the CD player or DVD play-
er by ejecting the disc. If the audio system
was previously off, then the entire audio
system will be turned off when you eject
the disc. If another function was previously
playing, it will come on again.

126AUDIO/VIDEO SYSTEM
SCION V398
The buttons for radio, CD player, DVD
player, iPod and AUX operation are dis-
played on the function button display
screen when the audio control mode is se-
lected.
Touch them lightly and directly on the
screen.
The selected button is highlighted.
INFORMATION
DIf the system does not respond to
a touch of a touch −screen button,
move your finger away from the
screen and then touch it again.
D You cannot operate dimmed
touch− screen buttons.
D Wipe off fingerprints on the sur-
face of the display using a glass
cleaning cloth.
DMain volume adjustment
1. Adjust with the “VOL” button.
The volume changes one step each time
the “Y ” or “B ” button of “VOL”is
pushed. Furthermore, the volume will con-
tinue to change if the switch is pushed con-
tinuously.
INFORMATION
D Adjust to an appropriate volume
that ensures accident −free, safe
driving.
D The volume may alter when the au-
dio mode is changed. Adjust the
volume to suit the audio mode
used.
—Adjusting the volume and
the sound quality

128AUDIO/VIDEO SYSTEM
SCION V398
2. Touch “Sound2” or “Sound1”.
Settings such as the following can be
made from the“Sound”screen.
“CSE”: Allows the compressed sound
range to be returned to its original sound,
and music to be played back with en-
hanced clarity. (See page 128.)
“BASS”: Allows low range sound qualities
(sound sharpness, build −up and fade −out)
that could not be set with the existing Tone
Control/EQ to be adjusted through CSE
settings. (See page 129.)
“DSP”: Allows the acoustic field (perfor-
mance venue) to be reproduced to match
the image conjured up by the music genre
or source. (See page 130.)
“FOCUS”: Allows the time taken for the
sound to reach the listener ’s ear from each
speaker to be adjusted. (See page 130.)
“AUTO VOL”: Detects the vehicle speed
and adjusts the volume accordingly. (See
page 131.)
“EQ”: Allows the previously set equalizer
curve to be adjusted and the preferred
equalizer curve to be created. (See page
131.)
“SSP”: The optimum acoustic environ-
ment can be created by setting vehicle in-
formation. (See page 132.)
“FAD BAL”: Allows the front, rear, left,
and right volume balance to be adjusted.
(See page 133.)
INFORMATION
D The sound quality can be set and
registered for each audio mode at
CSE and CSE·BASS.
D It is recommended that each sound
quality characteristic be set in the
following order to create the opti-
mum acoustic environment.
CSE
SSP
FAD BAL
FOCUS

AUTO VOL
DCSE (Clear Sound Effecter) settings
When recording from the original source to
other media, sound range inaudible to the
human ear are compressed. CSE returns
the compressed sound range as near as
possible to their original source, enabling
the listener to enjoy impressive high −quali-
ty sound inside the cabin. CSE also allows
the listener to enjoy real, high −clarity
sound in order to deliver clearer playback
of radio sound, etc.
SETTING CSE
1. Touch “CSE”.
The indicator will turn yellow.
Touch “CSE” again to cancel the settings.
Touch “OK”when settings are complete.
CHANGING THE CSE OFFSET
The CSE offset can be changed based on
the listener ’s preference.
1. Touch the CSE “Setting” switch to
display the “CSE Setting” screen.
2. Touch the preferred level switch.
Touch “OK”when settings are complete.
When “OFF” is touched, CSE is only can-
celled for the audio mode currently being
listened to.
Offset level 3 is not available for AM radio.
All audio mode CSE offset values can be
returned to their default values by touching
“Reset” .

134AUDIO/VIDEO SYSTEM
SCION V398
DListening to the radio
Push the “MODE” button and touch
“FM” to receive FM radio broadcasts,
and “AM” to receive AM radio broad-
casts.
Push the “AUDIO” button to display the
radio operation screen.
Your radio automatically changes to stereo
reception when a stereo broadcast is re-
ceived. “ST” appears on the screen. If the
signal becomes weak, the radio reduces
the amount of channel separation to pre-
vent the weak signal from creating noise.
If the signal becomes extremely weak, the
radio switches from stereo to mono recep-
tion. In this case, “ST” disappears from the
screen.
DPresetting a station
1. Select the broadcasting station to
be stored in the memory.
2. Touch the preset switch (1 — 8) to be
stored in the memory until a beep
sounds.
The broadcasting station (frequency) will
be stored in the memory.
Each radio mode can store up to 8 station-
s. Follow the same procedure to change
the preset station to a different one.
Touch
to display preset switches “5”to
“8” .
The preset station memory is cleared if the
power source is interrupted by a battery
disconnection or a blown fuse.
DSelecting a station
Tune in the desired station using one of the
following methods.
Normal station selection: Push the“Y ”
or “B ”button of “TRACK/TUNE” .
The displayed frequency moves UP/
DOWN one step each time one of the but-
tons is pushed. (1step is 10kHz for AM and
0.2MHz for FM.)
Auto station selection: Push the“Y ”or
“ B ” button of “TRACK/TUNE” until a
beep sounds.
The broadcasting station nearest to the
frequency displayed at the screen is auto-
matically selected and the search process
stops when the station is received. Push
again to cancel in the middle of a search.
Preset switch station selection: Sta-
tions can be selected by touching their pre-
set switches. Touch
to display preset
switches “5”to“8” .
INFORMATION
It may not be possible to perform auto
station selection in areas with weak
reception area.
To scan all the frequencies: Touch
“SCAN” . The system searches for a
broadcasting station and after receiving a
detected station for several seconds, then
searches for the next station. Touch
“SCAN” again when the desired station is
reached.
To scan the preset stations: Touch
“P.SCAN” . After receiving the preset
broadcasting station for several seconds,
the system moves on to the next preset
station. Touch “P.SCAN”again when the
desired station is reached.
— Radio operation

135
SCION V398
AUDIO/VIDEO SYSTEM
To listen to a satellite radio broadcast in
your vehicle, an additional genuine SCION
satellite receiver and antenna must be pur-
chased and installed, separately and the
subscription to the XM satellite radio is
also necessary.
DHow to subscribe to an XM satellite
radio
An XM satellite radio is a tuner designed
exclusively to receive broadcasts provided
under a separate subscription. Availability
is limited to the 48 contiguous states.
How to subscribe: You must enter into a
separate service agreement with the XM
radio in order to receive satellite broadcast
programming in the vehicle. Additional ac-
tivation and service subscription fees ap-
ply that are not included in the purchase
price of the vehicle and optional digital sat-
ellite tuner. For complete information on
subscription rates and terms, or to sub-
scribe to the XM radio, visit XM on the web
at www.xmradio.com
or call an XM’s Lis-
tener Care at (800) 967 −2346. The XM ra-
dio is solely responsible for the quality,
availability and content of the satellite ra-
dio services provided, which are subject to
the terms and conditions of the XM radio
customer service agreement.
Customers should have their radio ID
ready; the radio ID can be found by select-
ing “channel 000” on the radio. For details,
see the “Displaying the radio ID” that fol-
lows.
All fees and programming are the respon-
sibility of the XM satellite radio and are
subject to change.
Satellite tuner technology notice:
Toyota’s satellite radio tuners are awarded
Type Approval Certificates from XM
Satellite Radio Inc. as proof of
compatibility with the services offered by
the XM satellite radio.
DDisplaying the radio ID
Each XM tuner is identified with a unique
radio ID. You will need the radio ID when
activating XM service or when reporting a
problem.
If you select the “CH 000” using the
“TRACK/TUNE” button, the ID code of 8
alphanumeric characters appears. If you
select another channel, display of the ID
code is canceled. The channel (000) alter-
nates the display between the radio ID and
the specific radio ID code.
— Radio operation
(XM satellite radio
broadcast)
