octane TOYOTA YARIS 2004 1.G Owners Manual

982005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Break−in period
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break −in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of
your vehicle:

Avoid full throttle acceleration when
starting and driving.

Avoid racing the engine.

Try to avoid hard stops during the first
300 km (200 miles).

Do not drive slowly with the manual
transmission in a high gear.

Do not drive for a long time at any
single speed, either fast or slow.

Do not tow a trailer during the first 800
km (500 miles).
Fuel
FUEL TYPE
Your new vehicle must use only un-
leaded gasoline.
To help prevent gas station mix −ups, your
Toyota has a smaller fuel tank opening.
The special nozzle on pumps with un-
leaded fuel will fit it, but the larger stan-
dard nozzle on pumps with leaded gas will
not.
At a minimum, the gasoline you use
should meet specification of CGSB
3.5− M93 in Canada.
NOTICE
Do not use leaded gasoline. Use of
leaded gasoline will cause the three −
way catalytic converter to lose its ef-
fectiveness and the emission control
system to function improperly. Also,
this can increase maintenance costs.
OCTANE RATING
Select Octane Rating 87 (Research Oc-
tane Number 91) or higher.
Use of unleaded fuel with an octane num-
ber or rating lower than stated above will
cause persistent heavy knocking. If se-
vere, this will lead to engine damage. If your engine knocks...
If you detect heavy knocking even when
using the recommended fuel, or if you
hear steady knocking while holding a
steady speed on level roads, consult your
Toyota dealer.
However, occasionally, you may notice
light knocking for a short time while accel-
erating or driving up hills. This is normal
and there is no need for concern.
04 05.18

992005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
QUALITY GASOLINE
Automotive manufacturers in the U.S.,
Europe and Japan have developed a
specification for quality fuel named
World−Wide Fuel Charter (WWFC) that
is expected to be applied world wide.
The WWFC consists of three categories
that depend on required emission lev-
els. In Canada, category 3 has been
adopted. The WWFC improves air quali-
ty by providing for better emissions in
vehicle fleets, and customer satisfaction
through better vehicle performance.
CLEANER BURNING GASOLINE
Cleaner burning gasoline, including re-
formulated gasoline that contains oxy-
genates such as ethanol or MTBE is
available in many areas.
Toyota recommends the use of cleaner
burning gasoline and appropriately blended
reformulated gasoline. These types of gas-
oline provide excellent vehicle perfor-
mance, reduce vehicle emissions, and im-
prove air quality. OXYGENATES IN GASOLINE
Toyota allows the use of oxygenate
blended gasoline where the oxygenate
content is up to 10% ethanol or 15%
MTBE. If you use gasohol in your
Toyota, be sure that it has an octane
rating no lower than 87.
Toyota does not recommend the use of
gasoline containing methanol.
GASOLINE CONTAINING MMT
Some gasoline contain an octane en-
hancing additive called MMT (Methylcy-
cropentadienyl Manganese Tricarbonyl).
Toyota does not recommend the use of
gasoline that contains MMT. If fuel con-
taining MMT is used, your emission con-
trol system may be adversely affected.
The Malfunction Indicator Lamp on the in-
strument cluster may come on. If this hap-
pens, contact your Toyota dealer for ser-
vice.
GASOLINE QUALITY
In a very few cases, you may experience
drivability problems caused by the particu-
lar gasoline that you are using. If you
continue to have unacceptable drivability,
try changing gasoline brands. If this does
not rectify your problem, then consult your
Toyota dealer.
NOTICE


Do not use gasohol other than
stated above. It will cause fuel sys-
tem damage or vehicle performance
problems.

If drivability problems are encoun-
tered (poor hot starting, vaporizing,
engine knock, etc.), discontinue the
use.

Take care not to spill gasohol dur-
ing refueling. Gasohol may cause
paint damage.
FUEL TANK CAPACITY
45 L (11.9 gal., 9.9 lmp. gal.)
04 05.18

1002005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Operation in foreign countries
If you plan to drive your Toyota in
another country...
First, comply with the vehicle registration
laws.
Second, confirm the availability of the cor-
rect fuel (unleaded and minimum octane
number).
Three −way catalytic converter
SU21012a
The three −way catalytic converter is an
emission control device installed in the
exhaust system.
The purpose is to reduce pollutants in the
exhaust gas.
CAUTION

Keep people and combustible mate-
rials away from the exhaust pipe
while the engine is running. The
exhaust gas is very hot.

Do not drive, idle or park your ve-
hicle over anything that might burn
easily such as grass, leaves, paper
or rags.
04 05.18

2142005 ECHO HATCHBACK from Jul. ’04Prod. (OM52624U)
Dimensions and weights
Overall length mm (in.) 3735 (147.0)
Overall width mm (in.) 1660 (65.4)
Overall height mm (in.) 1500 (59.1)
Wheelbase mm (in.) 2370 (93.3)
Front tread mm (in.) 1445 (56.9)
Rear tread mm (in.) 1420 (55.9)
Vehicle capacity weight
(occupants + luggage)kg (lb.) 280 (617)
Towing capacity
(trailer + cargo weight) kg (lb.) 318 (700)
Engine
Model:1NZ− FE
Type: 4 cylinder in line, 4 cycle, gasoline
Bore and stroke, mm (in.): 75.0
84.7 (2.95
3.33)
Displacement, cm
3 (cu. in.):
1497 (91.3)
Fuel
Fuel type: Unleaded gasoline, Octane Rating 87(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., Imp. gal.): 45 (11.9, 9.9)
04 04.06

Publication No. OM52624U
Part No. 01999-52624
Printed in Japan 01−0407 −00
(U)
U 6
I
Quick index

If a service reminder indicator or warning buzzer comes on 69 . . . . . . . .

If your vehicle will not start 140 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.

If your engine stalls while driving 143 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If your vehicle overheats 143 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .

If you have a flat tire 144 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .

If your vehicle needs to be towed 156 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tips for driving during break-in period 98 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

How to start the engine 126 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .

General maintenance 173 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .

Complete index NO TAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher
See page 98 for detailed information.
Fuel tank capacity:
45 L (11.9 gal., 9.9 lmp.gal.)
Engine oil:
API grade SL “Energy −Conserving” or ILSAC
multigrade engine oil is recommended.
See page 186 for detailed information.
Tire information: See pages 191 through 198.
Tire inflation pressure: See page 217.
