Page 311 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3118-1. Specifications
8
Vehicle specifications
Oil viscosity (5W-30 is explained here as an example): • The 5W in 5W-30 indicates the  characteristic of the oil which
allows cold startability. Oils

Page 312 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3128-1. Specifications
*: The fluid capacity is the reference quantity. If replacement is necessary,contact your Toyota dealer.
Ignition system
Spark plug
MakeDENSO SK16R11
NGK IFR5A11
Gap0.043 in. (1

Page 313 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3138-1. Specifications
8
Vehicle specifications
Manual transmission
Gear oil capacity
(Reference)2.0 qt. (1.9 L, 1.7 Imp.qt.)
Gear oil type
Use either of the following:
• “TOYOTA Genuine Manual T

Page 314 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3148-1. Specifications
*1: Minimum pedal clearance when depressed with a force of 67 lbf (300 N,31 kgf) while the engine is running
*2: Parking brake lever travel when pulled up with a force of 45 lbf

Page 315 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3158-1. Specifications
8
Vehicle specifications
15-inch tires
16-inch tires
Compact spare tires
Tires and wheels
Tire sizeP175/65R15 84H
Tire inflation pressure
(Recommended cold
tire inflat

Page 316 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3168-1. Specifications
A: HB2 halogen bulbs B: HIR2 halogen bulbs
C: H16 halogen bulbs  D: Wedge base bulbs (clear)
E: Wedge base bulbs (amber)  F: Single end bulbs (clear)
G: Double end bulbs
Ligh

Page 317 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3178-1. Specifications
8
Vehicle specifications
Fuel information
■Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your vehicle has a fuel tank opening that
only accommodat

Page 318 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3188-1. Specifications
■Recommendation of the use of cleaner burning gasoline
Cleaner burning gasoline, including reformulated gasoline that contains oxy-
genates such as ethanol or MTBE (Methyl Ter

Page 319 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3198-1. Specifications
8
Vehicle specifications
■If your engine knocks
●Consult your Toyota dealer.
● You may occasionally notice light knocking for a short time while accelerat-
ing or driving

Page 320 of 364

TOYOTA YARIS 2015 3.G Owners Manual 3208-1. Specifications
Tire information
Full-size tire
Compact spare tire
Typical tire symbols
