2-5. Steering WheelSteering Wheel.................. 127
2-6. Mirrors Mirrors ............................... 129
2-7. Windows Power Windows ................ 132
2-8. Security System Modification and Add-On Equipment ......... 135
Immobilizer System ........... 136
Theft Deterrent System ..... 138
2-9. Driving Tips Break-In Period ................. 141
Saving Fuel and Protection of the
Environment .................... 142
Hazardous Driving............. 143
Floor Mat ........................... 144
Rocking the Vehicle .......... 145
Winter Driving.................... 146
Driving In Flooded Area ................................ 149
Overloading ....................... 150
Driving on Uneven Road ............................... 151
2-10. Towing Trailer Towing ................... 152
Recreational Towing ......... 153 3-1. Start/Stop Engine
Ignition Switch ................... 156
Starting the Engine ............ 158
Turning the Engine Off ...... 163
3-2. Combination Meter and Display
Meters and Gauges ........... 164
Warning/Indicator Lights ............................... 173
3-3. Transaxle Manual Transaxle Operation......................... 177
Automatic Transaxle Controls ........................... 181
3-4. Switches and Controls Lighting Control ................. 192
Fog Lights .......................... 198
Turn and Lane-Change Signals............................. 199
Windshield Wipers and Washer ..................... 201
Rear Window Wiper and Washer ............................ 206
Rear Window Defogger.......................... 207
Hazard Warning Flasher ............................ 208
3-5. Brake Brake System .................... 209
Hill Launch Assist (HLA) .... 213
3When Driving

207
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-4. Switches and Controls
3
When Driving
Rear Window Defogger
The ignition must be switched ON to use the defogger.
Press the switch to turn on the rear window defogger. The rear win-
dow defogger operates for about 15 minutes and then turns off a uto-
matically.
The indicator light illuminates when the defogger is operating.
To turn off the rear window defogger before the 15 minutes has
elapsed, press the switch again.
This defogger is not designed for melting snow. If there is an accumulation of
snow on the rear window, remove it before using the defogger.
To turn on the mirror defoggers, switch the ignition ON and pre ss the
rear window defogger switch ( P. 207).
The rear window defogger clears fog from the rear window.
Manual Climate ControlFully Automatic Climate Con-
trol
NOTICE
Do not use sharp instruments or window cleaners with abrasives to clean
the inside of the rear window surface. They may damage the defo gger grid
inside the window.
Mirror Defogger (if equipped)
Indicator lightIndicator light
