oil filter TOYOTA YARIS SEDAN 2008 Owners Manual

231
4-3. Do-it-yourself maintenance
4
Maintenance and care
CAUTION
n
Used engine oil
lUsed engine oil contains potentially harmful contaminants which may
cause skin disorders such as inflammation or skin cancer, so care should
be taken to avoid prolonged and repeated contact. To remove used engine
oil from your skin, wash thoroughly with soap and water.
l Dispose of used oil and filters only in a safe and acceptable manner. Do
not dispose of used oil and filters in household trash, in sewers or onto the
ground. Call your Toyota dealer, service station or auto parts store for
information concerning recycling or disposal.
l Do not leave used engine oil within the reach of children.
NOTICE
nTo prevent serious engine damage
Check the oil level on regular basis.
n When replacing the engine oil
lBe careful not to spill engine oil on the vehicle components.
l Avoid overfilling, as the engine could be damaged.
l Check the oil level on the dipstick every time you refill the vehicle.
l Be sure the engine oil filler cap is properly tightened.

329
6-1. Specifications
6
Vehicle specifications
Lubrication system
*: 5W-30 is an oil that provides optimal levels of fuel efficiency.
Oil viscosity
l The 5W portion of the oil viscosity rating indicates the characteristic
of the oil which allows cold startab ility. Oils with a lower value before
the W allow for easier starting of the engine in cold weather.
l The 30 in 5W-30 indicates the oil viscosity when the oil is at its oper-
ating temperature. An oil with a higher viscosity may be better suited
if the vehicle is operated at high speeds, or under extreme load con-
dition.
Oil capacity
Drain and refill
(Reference) With filter
Without filter 3.9 qt. (3.7 L, 3.3 Imp.qt.)
3.6 qt. (3.4 L, 3.0 Imp.qt.)
Oil grade
ILSAC multigrade engine oil
Recommended oil
viscosity Use Toyota approved “Toyota Genuine Motor
Oil” or equivalent to satisfy the grade and vis-
cosity shown below.
Outside temperature

372
GAS STATION INFORMATION
Auxiliary catch leverP. 223Fuel filler doorP. 5 5Hood lock release lever P. 223
Fuel filler door openerP. 5 5Tire inflation pressure
P. 333
Trunk openerP. 3 2
Fuel tank capacity 11.1 gal. (42.0 L, 9.2 lmp.gal.)
Fuel type Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Cold tire inflation
pressure P. 3 3 3
Engine oil capacity
(Drain and refill)qt. (L, Imp.qt.)
With filter 3.9 (3.7, 3.3)
Without filter 3.6 (3.4, 3.0)
Engine oil type Toyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil. P. 329
Recommended oil viscosity: SAE 5W-30

TABLE OF CONTENTSIndex
4
4-2. Maintenance ..................... 213Maintenance requirements .................... 213
General maintenance ......... 215
Emission inspection and maintenance (I/M)
programs .......................... 218
4-3. Do-it-yourself maintenance ................... 219
Do-it-yourself service precautions ...................... 219
Hood................................... 223
Positioning a floor jack ....... 224
Engine compartment .......... 226
Tires ................................... 240
Tire inflation pressure......... 246
Wheels ............................... 250
Air conditioning filter ........... 252
Key battery ......................... 255
Checking and replacing fuses ................................ 257
Light bulbs .......................... 269
5-1. Essential information....... 282 If your vehicle needs to be towed ............................... 282
If you think something is wrong ............................... 288
Fuel pump shut off system .............................. 289
Event data recorder............ 290 5-2. Steps to take in an
emergency ...................... 292
If a warning light turns on or a warning buzzer
sounds... ........................... 292
If you have a flat tire ........... 302
If the engine will not start .... 313
If the shift lever cannot be shifted from P ................... 315
If you lose your keys ........... 316
If the vehicle battery is discharged ........................ 317
If your vehicle overheats..... 320
If the vehicle becomes stuck ................................. 323
6-1. Specifications ................... 326 Maintenance data (fuel, oil level, etc.) ........... 326
Fuel information .................. 335
Tire information................... 338
6-2. Customization ................... 351 Customizable features ........ 351
Items to initialize ................. 353
Reporting safety defects for U.S. owners ...................... 356
Seat belt instructions for Canadian owners
(in French) ......................... 357
5When trouble arises
6Vehicle specifications
7For owners
