16In briefTransmission
Manual transmission
Reverse: with the vehicle stationary,
depress clutch pedal and press the release button on the selector lever
and engage the gear.
If the gear does not engage, set the
lever to neutral, release the clutch
pedal and depress again; then repeat
gear selection.
Manual transmission 3 132.
Manual transmission automatedN:neutral positionD/M:switch between automatic (D)
and manual (M) shift mode. D
or M is indicated in the
transmission display<:upshifting in manual mode]:downshifting in manual modeR:reverse, engage only when
vehicle is stationary
Manual transmission automated
3 132.
Starting off
Check before starting off ● tyre pressure and condition 3 187, 3 226
● engine oil level and fluid levels 3 166
● all windows, mirrors, exterior lighting and number plates are
free from dirt, snow and ice and
are operational
● proper position of mirrors, seats, and seat belts 3 27, 3 33,
3 38
● brake function at low speed, particularly if the brakes are wet

104Instruments and controlsTo connect a mobile device with the
Wi-Fi hotspot:
1. Press j and then select Wi-Fi
settings on the Info-Display. The settings displayed include the Wi-
Fi hotspot name (SSID),
password and connection type.
2. Start a Wi-Fi network search on your mobile device.
3. Select your vehicle hotspot (SSID) when listed.
4. When prompted, enter the password on your mobile device.
Notice
To change the SSID or password,
press Z and talk to an advisor or log
in to your account.
To switch off the Wi-Fi hotspot
functionality, press Z to call an
advisor.
Smartphone app
With the My Vauxhall smartphone
app, some vehicle functions can be
operated remotely.The following functions are available:
● Lock or unlock vehicle.
● Honk horn or flash lights.
● Check fuel level, engine oil life and tyre pressure (only with tyre
pressure monitoring system).
● Send navigation destination to the vehicle, if equipped with a
built-in navigation system.
● Locate vehicle on a map.
● Manage Wi-Fi settings.
To operate these functions, download the app from App Store ®
or
Google Play™ Store.
Remote control
If desired, use any phone to call an
advisor, who can remotely operate
specific vehicle functions. Find the
respective OnStar phone number on
our country-specific website.
The following functions are available: ● Lock or unlock vehicle.
● Provide information on the vehicle location.
● Honk horn or flash lights.Stolen vehicle assistance
If the vehicle is stolen, report the theft
to the authorities and request OnStar
stolen vehicle assistance. Use any
phone to call an advisor. Find the
respective OnStar phone number on
our country-specific website.
OnStar can provide support in
locating and recovering the vehicle.Theft alert
When the anti-theft alarm system is
triggered, a notification is sent to
OnStar. You are then informed about
this event by text message or email.Restart prevention
By sending remote signals, OnStar can prevent the vehicle from
restarting once it has been turned off.
On-demand diagnostics
At any time e.g. if the vehicle displays a vehicle message, press Z to
contact an advisor and ask to
complete a real-time diagnostic check
to directly determine the issue.
Depending on the results, the advisor
will provide further support.

Vehicle care163Vehicle careGeneral Information...................163
Accessories and vehicle modifications .......................... 163
Vehicle storage ........................164
End-of-life vehicle recovery .....164
Vehicle checks ........................... 165
Performing work ......................165
Bonnet ..................................... 165
Engine oil ................................. 166
Engine coolant ......................... 167
Washer fluid ............................ 167
Brakes ..................................... 168
Brake fluid ............................... 168
Vehicle battery ......................... 168
Wiper blade replacement ........170
Bulb replacement .......................171
Halogen headlights ..................171
Front turn signal lights .............173
Tail lights ................................. 175
Side turn signal lights ..............178
Number plate light ...................178
Interior lights ............................ 179
Instrument panel illumination ...179
Electrical system ........................180
Fuses ....................................... 180Engine compartment fuse box . 181
Instrument panel fuse box .......183
Vehicle tools .............................. 185
Tools ........................................ 185
Wheels and tyres .......................186
Winter tyres ............................. 186
Tyre designations ....................186
Tyre pressure .......................... 187
Tyre pressure monitoring system .................................... 188
Tread depth ............................. 191
Changing tyre and wheel size . 192
Wheel covers ........................... 192
Tyre chains .............................. 192
Tyre repair kit .......................... 193
Wheel changing .......................197
Spare wheel ............................ 199
Jump starting ............................. 204
Towing ....................................... 205
Towing the vehicle ...................205
Towing another vehicle ...........207
Appearance care .......................208
Exterior care ............................ 208
Interior care ............................. 210General Information
Accessories and vehicle modifications
We recommend the use of genuine
parts and accessories and factory approved parts specific for your
vehicle type. We cannot assess or guarantee reliability of other products
- even if they have a regulatory or
otherwise granted approval.
Any modification, conversion or other changes made to standard vehicle
specifications (including, without
limitation, software modifications,
modifications of the electronic control
units) may invalidate the warranty
offered by Vauxhall. Furthermore,
such changes may affect driver
assistance systems, may impact fuel
consumption, CO 2 emissions and
other emissions of the vehicle and
cause the vehicle to no longer
conform to the type approval,
impacting the validity of your vehicle
registration.

Vehicle care171Bulb replacement
Switch off the ignition and switch off
the relevant switch or close the doors.
Only hold a new bulb at the base! Do
not touch the bulb glass with bare
hands.
Use only the same bulb type for
replacement.
Replace headlight bulbs from within
the engine compartment.
Bulb check After a bulb replacement switch on
the ignition, operate and check the
lights.
Halogen headlights Halogen headlights with separate
bulbs for low beam and high beam.
Low beam outer bulb (1).
High beam inner bulb (2).
Low beam (1) 1. Rotate the cap anticlockwise and remove it.2. Press the clip to disengage bulbholder. Withdraw the bulb holder
from the reflector.
3. Detach the bulb from the bulb holder and replace the bulb.

237SSafety belts ................................... 37
Seat adjustment ....................... 7, 34 Seat belt ........................................ 8
Seat belt reminder .......................84
Seat belts ..................................... 37
Seat folding .................................. 35
Seat heating ................................. 36
Seat position ................................ 33
Selector lever ............................. 133
Service ....................................... 124
Service display ............................ 81
Service information ....................212
Service vehicle soon .................... 86
Side airbag system ......................43
Side blind spot alert ....................154
Sidelights .................................... 107
Side turn signal lights ................178
Software acknowledgement .......230
Spare wheel ............................... 199
Speed limiter............................... 143
Speedometer ............................... 78
Starting and operating ................126
Starting off ................................... 16
Starting the engine ............127, 133
Steering ...................................... 126
Steering wheel adjustment ......9, 71
Steering wheel controls ...............71
Stop-start system........................ 128
Storage ......................................... 51Storage compartments.................51
Sunroof ........................................ 31
Sun visors .................................... 30
Symbols ......................................... 4
T
Tachometer ................................. 79
Tail lights ................................... 175
Three-point seat belt .................... 38
Tools .......................................... 185
Top-tether fastening eyes ............50
Towing ........................................ 205
Towing another vehicle .............207
Towing the vehicle .....................205
Traction Control system ............. 138
Transmission ............................... 16
Transmission display .................133
Tread depth ............................... 191
Trip odometer .............................. 79
Turn and lane-change signals ...110
Turn signal ................................... 84
Tyre chains ................................ 192
Tyre designations ......................186
Tyre pressure ............................ 187
Tyre pressure monitoring system ............................... 88, 188
Tyre pressures ........................... 226
Tyre repair kit ............................. 193U
Ultrasonic parking assist ...... 87, 145
Upholstery .................................. 210
Uplevel-Display............................. 89
Upshift .......................................... 87
Using this manual ..........................3
V Vehicle battery ........................... 168
Vehicle checks............................ 165
Vehicle data ................................ 217
Vehicle data recording and privacy ..................................... 232
Vehicle dimensions .................... 224
Vehicle Identification Number ....215
Vehicle jack ................................ 185
Vehicle messages .......................96
Vehicle personalisation ...............99
Vehicle security ............................ 25
Vehicle specific data ......................3
Vehicle storage ........................... 164
Vehicle tools ............................... 185
Vehicle unlocking ........................... 6
Vehicle weight ........................... 223
Ventilation ................................... 115
W
Warning chimes ........................... 98
Warning lights ............................... 78
Warning triangle .......................... 66
Washer and wiper systems .........14
