technical data VAUXHALL ASTRA J 2015.75 Owner's Manual

Introduction.................................... 2
In brief ............................................ 6
Keys, doors and windows ............20
Seats, restraints ........................... 37
Storage ........................................ 59
Instruments and controls .............99
Lighting ...................................... 136
Climate control ........................... 149
Driving and operating .................159
Vehicle care ............................... 223
Service and maintenance ..........284
Technical data ........................... 287
Customer information ................325
Index .......................................... 330Contents

Introduction3Vehicle specific data
Please enter your vehicle's data on
the previous page to keep it easily
accessible. This information is
available in the sections "Service and maintenance" and "Technical data"
as well as on the identification plate.
Introduction
Your vehicle is a designed
combination of advanced technology, safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this Owner's Manual.When this Owner's Manual refers to aworkshop visit, we recommend your
Vauxhall Authorised Repairer. For
gas vehicles, we recommend a
Vauxhall Authorised Repairer
licensed to service gas vehicles.
All Vauxhall Authorised Repairers
provide first-class service at
reasonable prices. Experienced
mechanics trained by Vauxhall work
according to specific Vauxhall
instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this manual â–  This manual describes all options and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model variant,
country specifications, special
equipment or accessories.
â–  The "In brief" section will give you an initial overview.â–  The table of contents at thebeginning of this manual and withineach section shows where the
information is located.
â–  The index will enable you to search
for specific information.
â–  This Owner's Manual depicts left- hand drive vehicles. Operation is
similar for right-hand drive vehicles.
â–  The Owner's Manual uses the factory engine designations. The
corresponding sales designations
can be found in the section
"Technical data".
â–  Directional data, e.g. left or right, or
front or back, always relate to the
direction of travel.
â–  The vehicle display screens may not support your specific language.
â–  Display messages and interior labelling are written in bold letters.

Technical data287Technical dataVehicle identification..................287
Vehicle data ............................... 289Vehicle identification
Vehicle Identification
Number
The Vehicle Identification Number
may be stamped on the identification plate and on the floor pan, under thefloor covering, visible under a cover.
The Vehicle Identification Number
may be embossed on the instrument
panel, visible through the windscreen,
or in the engine compartment on the
right body panel.
Identification plate
The identification plate is located on
the front left or right door frame.

288Technical data
Information on identification label:1=manufacturer2=type approval number3=vehicle identification number4=permissible gross vehicle weight
rating in kg5=permissible gross train weight
in kg6=maximum permissible front axle
load in kg7=maximum permissible rear axle
load in kg8=vehicle-specific or country-
specific data
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight. For
example, if the front axle is bearing its
maximum permissible load, the rear
axle can only bear a load that is equal
to the gross vehicle weight minus the front axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identification The technical data tables show the
engine identifier code. Engine data
3 292.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided
with your vehicle or other national
registration documents.

Technical data289Vehicle dataRecommended fluids and lubricantsEuropean service scheduleRequired engine oil qualityAll European countries with European service interval 3 284Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos 1––dexos 2✔✔
In case dexos quality is unavailable you may use max. 1 litre engine oil quality ACEA C3 once between each oil change.
Engine oil viscosity grades
All European countries with European service interval 3 284Ambient temperaturePetrol and diesel enginesdown to -25 °CSAE 5W-30 or SAE 5W-40below -25 °CSAE 0W-30 or SAE 0W-40

290Technical data
International service scheduleRequired engine oil qualityAll countries with international service interval 3 284Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos 1 (if available)✔–dexos 2✔✔
In case dexos quality is unavailable you may use the oil qualities listed below:
All countries with international service interval 3 284Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesGM-LL-A-025✔–GM-LL-B-025–✔

Technical data291
All countries with international service interval 3 284Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesACEA A3/B3✔–ACEA A3/B4✔✔ACEA C3✔✔API SM✔–API SN resource conserving✔–
Engine oil viscosity grades
All countries with international service interval 3 284Ambient temperaturePetrol and diesel enginesdown to -25 °CSAE 5W-30 or SAE 5W-40below -25 °CSAE 0W-30 or SAE 0W-40down to -20 °CSAE 10W-30 1)
or SAE 10W-40 1)1)
Permitted, but usage of SAE 5W-30 or SAE 5W-40 with dexos quality is recommended.

292Technical dataEngine dataSales designation1.41.41.41.61.61.61.6
Engine identifier code
A14XER,
B14XERB14NELB14NET LPG,
B14NETB16XERA16XHTB16SHLB16SHTNumber of cylinders4444444Piston displacement [cm 3
]1398136413641598159815981598Engine power [kW]748810385125125147at rpm60004200-60004900-6000600060004750-60005500Torque [Nm]130200200155260260280at rpm40001850-42001850-490040001650-32001650-45001650-5000Fuel typePetrolPetrolPetrol/LPGPetrolPetrolPetrolPetrolOctane rating RONrecommended95959595989898possible98989898959595possible91919191919191Gas––LPG––––Engine oil consumption [l/1000 km] 2)0.60.60.60.60.60.60.62)
Maximum value.

Technical data293
Sales designation1.82.0 VXR1.31.61.61.71.7Engine identifier codeA18XERB20NFTA13DTEB16DTHB16DTLA17DTNA17DTCNumber of cylinders4444444Piston displacement [cm3
]1796199812481598159816861686Engine power [kW]10320670100817481at rpm6300530040003500-4000350040004000Torque [Nm]175400190320300260280at rpm38002400-48001750-325020001750-20001750-25001750-2500Fuel typePetrolPetrolDieselDieselDieselDieselDieselOctane rating RONrecommended9598possible9895possible9191Engine oil consumption [l/1000 km] 3)0.60.60.60.60.60.60.63)
Maximum value.

294Technical data
Sales designation1.72.0 Turbo2.0 Turbo2.0 Turbo
Engine identifier code
A17DTSA20DTH
121 kWA20DTH
96 kWA20DTRNumber of cylinders4444Piston displacement [cm 3
]1686195619561956Engine power [kW]96121/117 4)96143at rpm4000400040004000Torque [Nm]300350300400at rpm2000-25001750-25001750-25001750-2500Fuel typeDieselDieselDieselDieselEngine oil consumption [l/1000 km] 2)0.60.60.60.62)
Maximum value.
4) Detuned version.
