stop start VAUXHALL ASTRA J 2016.25 Owner's Guide

200Vehicle careVehicle battery
The vehicle battery is located in the
load compartment under a cover
behind the rear seats. There are
connecting points for jump starting in the engine compartment.
Jump starting 3 232.
The vehicle battery is maintenance-
free provided that the driving profile
allows sufficient charging of the
battery. Short-distance-driving and
frequent engine starts can discharge
the battery. Avoid the use of
unnecessary electrical consumers.
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
Laying up the vehicle for more than
four weeks can lead to battery
discharge. Disconnect the clamp from the negative terminal of the vehicle
battery.
Ensure the ignition is switched off
before connecting or disconnecting
the vehicle battery.
Vehicle battery discharge protection
3 127.
Replacing the vehicle battery Notice
Any deviation from the instructions
given in this section may lead to
temporary deactivation of the stop-
start system.
When the vehicle battery is being
replaced, please ensure that there
are no open ventilation holes in the
vicinity of the positive terminal. If a
ventilation hole is open in this area, it
must be closed off with a dummy cap, and the ventilation in the vicinity of the
negative terminal must be opened.
In vehicles with an AGM (Absorptive
Glass Mat) battery, make sure to
have the battery replaced with
another AGM battery.
An AGM battery can be identified by
the label on the battery. We
recommend the use of an original
Vauxhall vehicle battery.

Vehicle care201Notice
Using an AGM vehicle battery
different from the original Vauxhall
vehicle battery may result in a lower
performance.
We recommend that you have the
vehicle battery replaced by a
workshop.
Stop-start system 3 144.
Charging the vehicle battery9 Warning
On vehicles with stop-start
system, ensure that the charging potential does not exceed
14.6 volts when using a battery
charger. Otherwise the vehicle
battery might be damaged.
Jump starting 3 232.
Warning label
Meaning of symbols:
● No sparks, naked flames or smoking.
● Always shield eyes. Explosive gases can cause blindness or
injury.
● Keep the vehicle battery out of reach of children.
● The vehicle battery contains sulphuric acid which could cause
blindness or serious burn
injuries.
● See the Owner's Manual for further information.
● Explosive gas may be present in the vicinity of the vehicle battery.
Diesel fuel system bleeding If the tank has been run dry, the diesel
fuel system must be bled. Switch on
the ignition three times for
15 seconds at a time. Then crank the
engine for a maximum of 40 seconds. Repeat this process after
no less than five seconds. If the
engine fails to start, seek the
assistance of a workshop.

Vehicle care215No.Circuit32Transmission control module
(only on vehicles with stop-start
system)33Anti-theft alarm system/Alarm
horn34Parking assist/Side blind spot alert/Infotainment system/USB
socket35OnStar36Info display/Instrument cluster/
CD player37Infotainment system, radio
After having changed defective fuses,
close the fuse box cover and press
until it engages.
Vehicles with power connector: 1. Apply the cover on the right side.
2. Fold the left side of the cover forwards. Take care that the
securing clamp is guided as
shown in the illustration.
Load compartment fuse box
The fuse box is located on the left side
of the load compartment behind a
cover.Remove the cover.
Disengage the fuse box cover and
remove it.

222Vehicle carewheel and left side rear wheel. Theturn signal light at the current active
position is illuminated until sensor is
matched.
Consult a workshop for service or purchase a relearn tool. There are
two minutes to match the first wheel
position, and five minutes overall to
match all four wheel positions. If it
takes longer, the matching process
stops and must be restarted.
The tyre pressure sensor matching
process is:
1. Apply the parking brake.
2. Turn the ignition on.
3. On vehicles with automatic transmission: set the selector
lever to P.
On vehicles with manual
transmission: select neutral.
4. Midlevel display: Use MENU on the turn signal
lever to select the Vehicle
Information Menu ? in the
Driver Information Centre.
Uplevel display:Press p on the steering wheel to
open main menu page.
Select the Info page with Q or P.
Confirm with 9.
5. Select the tyre pressure menu. Midlevel display:
Uplevel display:
6. Midlevel display: Press SET/CLR to begin the
sensor matching process. A
message requesting acceptance
of the process should be
displayed.
Press SET/CLR again to confirm
the selection. The horn sounds
twice to indicate that the receiver
is in relearn mode.
Uplevel display:
Press 9 to begin the sensor
matching process. The horn
sounds twice to indicate that the receiver is in relearn mode.
7. Start with the left side front wheel.

Technical data247Engine dataSales designation1.01.41.41.41.6Engine identifier codeB10XFLB14XEB14XFLB14XFTB16SHTNumber of cylinders34444Piston displacement [cm3
]9991399139913991598Engine power [kW]777492110147at rpm550060004000-56005000-56004700-5500Torque [Nm]170130245/230 2)245/230 2)300at rpm1800-425044002000-35002000-40001700-4700Fuel typePetrolPetrolPetrolPetrolPetrolOctane rating RONrecommended9595959598possible9898989895possible9191919191Gas–––––Engine oil consumption [l/1000 km] 3)0.60.60.60.60.62)
With Stop-start system.
3) Maximum value.

Technical data249PerformanceEngineB10XFLB14XEB14XFLB14XFTB16SHTMaximum speed [mph]Manual transmission121–5)127 6)
/124134 6)
/130–5)Manual transmission automated123––––Automatic transmission–––––5)
Value was not available at time of printing.
6) With Stop-start system.EngineB16DTCB16DTEB16DTHB16DTRB16DTUMaximum speed [mph]Manual transmission112119129–5)–5)–––––Automatic transmission––123––5)
Value was not available at time of printing.
