Vehicle care273● Do not lean over the vehiclebattery during jump starting.
● Do not allow the terminals of one
lead to touch those of the other
lead.
● The vehicles must not come into contact with each other during
the jump starting process.
● Apply the parking brake, transmission in neutral,
automatic transmission in P.
● Open the positive terminal protection cap of your vehicle in
the engine compartment and of
the booster vehicle battery.Lead connection order:
1. Connect the red lead to the positive terminal of the booster
vehicle battery.
2. Connect the other end of the red lead to the positive terminal of
your vehicle near the fuse box in
the engine compartment.
3. Connect the black lead to the negative terminal of the booster
vehicle battery.
4. Connect the other end of the black
lead to a vehicle grounding point
of your vehicle in the engine
compartment.
Route the leads so that they cannot
catch on rotating parts in the engine
compartment.
To start the engine: 1. Start the engine of the vehicle providing the jump.
2. After five minutes, start the other engine. Start attempts should be
made for no longer than
15 seconds at an interval of one
minute.3. Allow both engines to idle for approx. three minutes with the
leads connected.
4. Switch on electrical consumers (e.g. headlights, heated rear
window) of the vehicle receiving
the jump start.
5. Reverse above sequence exactly when removing leads.

311CNG.................................... 105, 222
Control indicators........................ 108
Control of the vehicle .................157
Controls ........................................ 90
Convex shape .............................. 38
Coolant and antifreeze ...............280
Cruise control ....................113, 184
Cupholders .................................. 70
Curtain airbag system .................. 62
Curve lighting.............................. 137
D
Danger, Warnings and Cautions ...4
Daytime running lights ...............137
Declaration of conformity ............298
DEF ............................................ 168
Diesel exhaust fluid ....................168
Diesel fuel system bleeding .......237
Diesel particle filter ....................167
Door open .................................. 114
Doors ............................................ 29
Driver assistance systems ..........184
Driver Information Centre ...........115
Driving characteristics and towing tips .............................. 225
Driving hints ................................ 157
E Electric adjustment ......................38
Electrical system......................... 248
Electric parking brake .........110, 179Electric parking brake fault .........110
Electronic climate control system 149
Electronic driving programmes . ........................................ 173, 178
Electronic key system ...................21
Electronic Stability Control.......... 182
Electronic Stability Control and Traction Control system ..........111
Electronic Stability Control off..... 111
End-of-life vehicle recovery .......231
Engine compartment fuse box ...249
Engine coolant ........................... 234
Engine coolant temperature gauge ..................................... 106
Engine data ............................... 288
Engine exhaust .......................... 167
Engine identification ...................284
Engine oil ................... 233, 280, 285
Engine oil pressure ....................112
Entry lighting .............................. 144
Event data recorders ..................305
Exit lighting ................................ 144
Exterior care .............................. 276
Exterior light ............................... 113
Exterior lighting ....................12, 135
Exterior mirrors ............................. 38
F
Fault ................................... 173, 178
First aid kit ................................... 86Fixed air vents ........................... 154
Fog light ..................................... 113
Fog lights ................................... 240
Folding mirrors ............................. 38
Following distance ......................111
Following distance indication ......198
Forward collision alert................. 195
Fragrance diffuser ........................98
Front airbag system .....................61
Front fog lights ........................... 141
Front seats.................................... 46
Front storage ................................ 71
Fuel............................................. 220
Fuel for diesel engines ..............221
Fuel for natural gas operation ...222
Fuel for petrol engines ...............220
Fuel gauge ................................. 105
Fuel selector .............................. 105
Fuses ......................................... 248
G
Gauges ....................................... 103
Gear shifting ............................... 111
General information ...................225
Glovebox ..................................... 70
H Halogen headlights ....................238
Hand brake ......................... 178, 179
Hazard warning flashers ............140
Headlight flash ........................... 136

312Headlight range adjustment ......136
Headlights................................... 135
Headlights when driving abroad 137
Head restraint adjustment .............8
Head restraints ............................ 45
Heated mirrors ............................. 39
Heated rear window ..................... 42
Heated steering wheel .................91
Heating .................................. 53, 55
Heating and ventilation system . 146
High beam ......................... 113, 136
High beam assist ........................113
Hill start assist ........................... 181
Horn ....................................... 13, 91
I
Identification plate .....................283
Ignition switch positions .............157
Immobiliser .......................... 37, 113
Indicators .................................... 103
Info Display ................................. 120
Information displays.................... 115
Instrument cluster ......................100
Instrument panel fuse box .........251
Instrument panel illumination .....248
Instrument panel illumination control .................................... 143
Instrument panel overview ........... 10
Interior care ............................... 277
Interior lighting ............................ 143Interior lights ...................... 143, 248
Interior mirrors .............................. 39
Interruption of power supply ......174
Introduction .................................... 3
J
Jump starting ............................. 272
K Key, memorised settings ..............23
Keys ............................................. 19
Keys, locks ................................... 19
L
Lane keep assist ................111, 217
Lashing eyes ............................... 80
LED headlights ...................113, 137
Lighting features .........................144
Light switch ................................ 135
Load compartment ................29, 72
Load compartment cover .............78
Load compartment fuse box ......253
Loading information .....................87
Low fuel ..................................... 113
M Malfunction indicator light ..........110
Manual anti-dazzle ......................39
Manual mode .....................173, 177
Manual seat adjustment ...............47
Manual transmission .................. 175Manual transmission automated 175
Manual windows ..........................40
Massage ....................................... 54
Maximum speed ......................... 257
Memorised settings ......................23
Midlevel display .......................... 115
Mirror adjustment ........................... 9
Misted light covers .....................142
N Natural gas ......................... 105, 222
New vehicle running-in ..............157
Number plate light .....................247
O
Object detection systems ...........202
Odometer ................................... 104
Oil, engine .......................... 280, 285
OnStar ........................................ 130
Outside temperature ....................94
Overrun cut-off ........................... 162
P Parking ................................ 18, 165
Parking assist ............................ 202
Parking brake ............................ 179
Parking lights ............................. 142
Particulate filter ........................... 167
Performance .............................. 290
Performing work ........................232
Pollen filter ................................. 155
