Service and maintenance275Service and
maintenanceGeneral information ...................275
Service information ..................275
Recommended fluids, lubricants and parts .................................... 276
Recommended fluids and lubricants ................................ 276General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 107.
European service intervals Maintenance of your vehicle is
required every 20,000 miles or after
one year, whichever occurs first, unless otherwise indicated in theservice display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania, San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display 3 107.
International service intervals Maintenance of your vehicle is
required every 10,000 miles or after
one year, whichever occurs first, unless otherwise indicated in the
service display.
Severe operating conditions exist if one or more of the following
circumstances occur frequently: Cold
starting, stop and go operation, trailer operation, mountain driving, driving
on poor and sandy road surfaces,
increased air pollution, presence of
airborne sand and high dust content,

276Service and maintenancedriving at high altitude and large
variations of temperature. Under
these severe operating conditions,
certain service work may be required more frequently than the regular
service interval.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 107.
Confirmations Confirmation of service is recorded inthe Service and warranty booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
warranty booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 107.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.

306Headlight range adjustment ......136
Headlights................................... 135
Headlights when driving abroad 137
Head restraint adjustment .............8
Head restraints ............................ 45
Heated mirrors ............................. 39
Heated rear window ..................... 42
Heated steering wheel .................91
Heating .................................. 53, 55
Heating and ventilation system . 146
High beam ......................... 113, 136
High beam assist ........................113
Hill start assist ........................... 178
Horn ....................................... 13, 91
I
Identification plate .....................279
Ignition switch positions .............157
Immobiliser .......................... 37, 113
Indicators .................................... 103
Info display ................................. 120
Information displays.................... 114
Instrument cluster ......................100
Instrument panel fuse box .........247
Instrument panel illumination .....244
Instrument panel illumination control .................................... 143
Instrument panel overview ........... 10
Interior care ............................... 273
Interior lighting ............................ 143Interior lights ...................... 143, 244
Interior mirrors .............................. 39
Interruption of power supply ......171
Introduction .................................... 3
J
Jump starting ............................. 268
K Key, memorised settings ..............23
Keys ............................................. 19
Keys, locks ................................... 19
L Lane keep assist ................111, 214
Lashing eyes ............................... 80
LED headlights ...................113, 137
Lighting features .........................144
Light switch ................................ 135
Load compartment ................29, 72
Load compartment cover .............78
Load compartment fuse box ......249
Loading information .....................87
Low fuel ..................................... 112
M
Malfunction indicator light ..........110
Manual anti-dazzle ......................39
Manual mode .....................170, 174
Manual seat adjustment ...............47
Manual transmission .................. 172Manual transmission automated 172
Manual windows ..........................40
Massage ....................................... 54
Maximum speed ......................... 253
Memorised settings ......................23
Midlevel display .......................... 114
Mirror adjustment ........................... 9
Misted light covers .....................142
N Natural gas ......................... 105, 218
New vehicle running-in ..............157
Number plate light .....................243
O Object detection systems ...........199
Odometer ................................... 104
Oil, engine .......................... 276, 281
OnStar ........................................ 130
Outside temperature ....................94
Overrun cut-off ........................... 162
P Parking ................................ 18, 165
Parking assist ............................ 199
Parking brake ............................ 176
Parking lights ............................. 142
Particulate filter ........................... 167
Performance .............................. 286
Performing work ........................228
Pollen filter ................................. 155

307Power button.............................. 158
Power connector........................... 97
Power outlets ............................... 96
Power seat adjustment ................49
Power windows ............................ 40
Preheating ................................. 112
Puncture ..................................... 263
Q Quickheat ................................... 154
R Radio Frequency Identification (RFID) ..................................... 302
Radio remote control ...................20
REACH ....................................... 298
Reading lights ............................ 143
Rear floor storage cover ..............80
Rear fog light .....................113, 142
Rear seats .................................... 54
Rear storage ................................. 78
Rear view camera ...................... 208
Rear window wiper/washer .......... 93
Recommended fluids and lubricants ........................ 276, 281
Refuelling ................................... 218 Registered trademarks ...............300
Retained power off .....................159
Reversing lights .........................142
Ride control systems ..................178
Roof .............................................. 43Roof load...................................... 87
Roof rack ..................................... 87
S Safety belts ................................... 55
Safety net .................................... 83
Seat adjustment ............................. 7 Seat belt ........................................ 8
Seat belt reminder .....................108
Seat belts ..................................... 55
Seat heating Seat heating, front .....................53
Seat heating, rear .....................55
Seat position ................................ 46
Selector lever ..................... 169, 173
Service ............................... 155, 275
Service display .......................... 107
Service information ....................275
Side airbag system ......................61
Side blind spot alert ....................206
Sidelights .................................... 135
Side turn signal lights ................243
Software acknowledgement .......298
Software update ......................... 300
Spare wheel ............................... 265
Speed limiter....................... 114, 183
Speedometer ............................. 103
Sport mode ................................ 181
Starting and operating ................157
Starting off ................................... 16Starting the engine ....................160
Steering ...................................... 157
Steering wheel adjustment ......9, 90
Steering wheel controls ...............90
Stop-start system........................ 162
Storage ......................................... 70
Storage compartments .................70
Sunroof ........................................ 43
Sunvisor lights ........................... 144
Sun visors .................................... 42
Symbols ......................................... 4
T
Tachometer ............................... 105
Tail lights ................................... 237
Three-point seat belt .................... 56
Tools .......................................... 251
Tow bar....................................... 221
Towing ................................ 221, 270
Towing another vehicle .............271
Towing equipment .....................222
Towing the vehicle .....................270
Traction Control system ............. 178
Traction Control system off......... 112
Traffic sign assistant ...........114, 210
Trailer coupling ........................... 221
Trailer stability assist .................225
Trailer towing ............................. 222
Transmission ............................... 15
Transmission display .........168, 173

308Tread depth ............................... 258
Trip odometer ............................ 104
Turn and lane-change signals ...141
Turn signal ................................. 108
Tyre chains ................................ 259
Tyre designations ......................253
Tyre pressure ............................ 253
Tyre pressure monitoring system ............................. 112, 254
Tyre pressures ........................... 292
Tyre repair kit ............................. 260
U
Ultrasonic parking assist............. 199
Upholstery .................................. 273
Uplevel display ........................... 114
Using this manual ..........................3
V Valet mode ................................. 120
Vehicle battery ........................... 232
Vehicle checks............................ 228
Vehicle data ................................ 281
Vehicle data recording and privacy ..................................... 301
Vehicle detected ahead ..............114
Vehicle dimensions .................... 290
Vehicle Identification Number ....279
Vehicle jack ................................ 251
Vehicle messages .....................122
Vehicle personalisation .............124Vehicle security ............................ 35
Vehicle specific data ......................3
Vehicle storage ........................... 227
Vehicle tools ............................... 251
Vehicle unlocking ........................... 6 Vehicle weight ........................... 288
Ventilating ..................................... 53
Ventilation ................................... 146
W
Warning chimes .........................123
Warning lights ............................. 103
Warning triangle .......................... 85
Washer and wiper systems .........13
Washer fluid ............................... 231
Wheel changing .........................263
Wheel covers ............................. 259
Wheels and tyres .......................253
Windows ....................................... 40
Windscreen................................... 40
Windscreen wiper/washer ...........91
Winter tyres ............................... 253
Wiper blade replacement ..........233
