AUX VAUXHALL ASTRA J GTC 2018.5 Infotainment system

Introduction811 RADIOActivate radio or change
waveband .............................. 92
2 CD
Start CD/MP3/WMA
playback .............................. 105
3 Search backwards
Radio: search backwards .....92
CD/MP3/WMA: skip track
backwards ........................... 102
4 Radio station buttons 1...6
Long press: save station .......93
Short press: select station ....93
5 m
Press: switch on/off
Infotainment system ..............85
Turn: adjust volume ..............85
6 Search forwards
Radio: search forwards .........92
CD/MP3/WMA: skip track
forwards .............................. 1027 AS 1/2
Automatic memory levels(preset radio stations) ...........93
Short press: select
autostore list .......................... 93
Long press: save stations
automatically ......................... 93
8 FAV 1/2/3
Lists of favourites (preset
radio stations) ....................... 93
9 TP
Activate or deactivate
radio traffic service ................97
If Infotainment system is
switched off: display time
and date ................................ 97
10 CD ejection ......................... 102
11 CONFIG
Open settings menu ..............9012 INFO
Radio: information on the
currently played station .........92
CD/MP3/WMA:
information on the
currently inserted CD ..........102
13 Multifunction knob
Turn: mark menu options
or set numeric values ...........86
Press: select/activate the
marked option; confirm set value; switch function on/off ..86
14 CD slot ................................ 102
15 BACK
Menu: one level back ............86
Input: delete last character or entire entry ........................ 86
16 TONE
Tone settings ........................ 88
17 PHONE
Activate mute ........................ 85
18 AUX
Change audio source ..........105

84Introduction20 AUXChange audio source ..........105Steering wheel audio controls
1qw
No function.
2 SRC (Source)
Press: select audio source ....85
With radio active: turn
upwards/downwards to
select next/previous
preset radio station ...............92
With CD player active: turn upwards/downwards to
select next/previous CD/
MP3/WMA track ..................102
3w
Increase volume .................... 85
4 ─
Reduce volume .....................85
5 xn
Press: activate/deactivate
mute ...................................... 85

Introduction85Usage
Control elements
The Infotainment system is operated
via function buttons, multifunctional
knobs and menus that are shown on
the display.
Inputs are made optionally via: ● the central control unit in the instrument panel 3 80
● controls on the steering wheel 3 80
Switching the Infotainment
system on or off
Press X briefly. After switching on,
the last selected Infotainment source
is active.
Automatic switch-off If the Infotainment system has been
switched on by pressing X when the
ignition was switched off, it will switch
off again automatically after
10 minutes.Setting the volume
Turn X. The current setting is shown
on the display.
When the Infotainment system is
switched on, the last selected volume
is set, provided that volume is lower
than the maximum start-up volume.
The following can be set separately: ● the maximum start-up volume 3 90
● the volume of the traffic announcements 3 90
Speed compensated volume
When speed compensated volume is
activated 3 90 the volume is
adapted automatically to make up for the road and wind noise as you drive.
Mute
Press PHONE to mute the audio
sources.
To cancel mute again: turn X or press
PHONE again.Volume limitation at high
temperatures
At very high temperatures inside the
vehicle the Infotainment system limits
the maximum adjustable volume. If
necessary the volume is decreased
automatically.
Modes of operation
Radio
Press RADIO to open the radio main
menu or to change between the
different wavebands.
Press the multifunction knob to open
a submenu with options for station
selection.
Detailed description of the radio
functions 3 92.
Audio players
Press CD or AUX to open the CD,
USB, iPod ®
or AUX menus or to
switch between these menus.
Press the multifunction knob to open
a submenu with options for track
selection.

86IntroductionDetailed description of:● CD player functions 3 102
● AUX input functions 3 105
● USB port functions 3 106
Basic operation
Multifunction knob The multifunction knob is the central
control element for the menus.
Turn the multifunction knob: ● CD 400: to mark a menu option
● CD 300: to display a menu option
● to set a numeric value
Press the multifunction knob: ● CD 400: to select or activate the marked option
● CD 300: to select or activate the option displayed
● to confirm a set value
● to switch a system function on/offBACK button
Press BACK briefly:
● to exit a menu
● to return from a submenu to the next higher menu level
● to delete the last character in a character sequence
Press and hold BACK for a few
seconds to delete the entire entry.
Examples of menu operation
CD 400Selecting an optionTurn the multifunction knob to move
the cursor (= coloured background) to the desired option.
Press the multifunction knob to select
the marked option.Submenus
An arrow on the right-hand edge of
the menu indicates that after
selection of the option a submenu
with further options will be opened.Activating a setting
Turn the multifunction knob to mark
the desired setting.
Press the multifunction knob to
activate the setting.

AUX input105AUX inputGeneral information...................105
Usage ........................................ 105General information
In the centre console there is an AUX
socket for the connection of external
audio sources.
It is possible, for example, to connect a portable CD player with a 3.5 mm
jack plug to the AUX input.
Notice
The socket must always be kept clean and dry.
Usage Press AUX once or several times to
activate the AUX mode.An audio source that is connected to
the AUX input can be operated only
via the control elements of the audio
source.

106USB portUSB portGeneral information...................106
Playing saved audio files ...........106General information
In the centre console there is a USB socket for the connection of external
audio data sources.
Devices connected to the USB port
are operated via the controls and
menus of the Infotainment system.
Notice
The socket must always be kept clean and dry.
Playing saved audio files
Press AUX once or several times to
activate the USB mode.
Playback of the audio data stored on
the USB device is started.
The operation of data sources
connected via USB is generally the same as for an audio MP3 CD 3 102.
On the following pages only the
aspects of operation that are
different/additional are described.
Operation and the screen displays
are described for USB drives only.
Operation of other devices is
generally the same.
Selecting tracks using the USB
menu

109RDS.............................................. 97
Regionalization ............................. 97
Retrieving stations ........................93
S Selecting the waveband ...............92
Setting the volume ........................85
Speed compensated volume ........85
Starting CD playback ..................102
Station search............................... 92
Storing stations ............................. 93
Switching the Infotainment system on or off......................... 85
Switching the radio on ..................92
T
Theft-deterrent feature ................. 79
Tone settings ................................ 88
Traffic announcements .................90
U
Updating station lists ....................94
Usage ..................... 85, 92, 102, 105
Using the AUX input ...................105
Using the CD player ...................102
Using the Infotainment system .....85
Using the radio ............................. 92
Using the USB port .....................106
V Volume settings ............................ 90W
Waveband menus......................... 94

Introduction................................ 112
Radio ......................................... 122
CD Player .................................. 131
AUX input ................................... 134
USB port .................................... 135
Bluetooth music ......................... 138
Phone ........................................ 140
Index .......................................... 148CD 400plus

116Introduction18 AUX..................................... 134
Change audio source ..........134Steering wheel audio controls
1qw
Short press: take phone call 140
or dial number in call list .....143
Long press: show call list ....143
2 SRC (Source) ...................... 117
Press: select audio source ..117
With radio active: turn
upwards/downwards to
select next/previous
preset radio station .............122
With CD player active: turn
upwards/downwards to
select next/previous CD/
MP3/WMA track ..................132
With Phone portal active:
turn upwards/downwards
to select next/previous
entry in call list ....................143
With Phone portal active
and calls waiting: turn
upwards/downwards to
switch between calls ...........143
3 w
Increase volume .................. 117
4 ─
Reduce volume ...................117
5 xn
Short press: end/decline
call ....................................... 143
or close call list .................... 143
or activate/deactivate mute . 117

Introduction117Usage
Control elements
The Infotainment system is operated
via function buttons, a multifunction
knob and menus that are shown on
the display.
Inputs are made optionally via: ● the control panel on the Infotainment system 3 114
● audio controls on the steering wheel 3 114
Switching the Infotainment
system on or off
Press X briefly. After switching on,
the last selected Infotainment source becomes active.
Press X again to turn the system off.
Automatic switch-off
If the Infotainment system is switched
on pressing X while the ignition is
turned off, it will switch off again automatically 10 minutes after the last user input.Setting the volume
Turn m. The current setting is shown
on the display.
When the Infotainment system is
switched on, the last selected volume is set, provided this setting is lower
than the maximum start-up volume
(see below).
The following inputs can be made
separately:
● the maximum start-up volume 3 121
● the volume of traffic announcements 3 121
Speed compensated volume
When speed compensated volume is
activated 3 121, the volume is
adapted automatically to make up for
the road and wind noises as you
drive.
Mute function
Press PHONE (if Phone portal
available: press for a few seconds) to mute the audio sources.To cancel the mute function: turn m or
press PHONE (if Phone portal
available: press for a few seconds).
Volume limitation at high
temperatures
At very high temperatures inside the
vehicle the Infotainment system limits
the maximum adjustable volume. If
necessary, the volume is decreased
automatically.
Modes of operation
Radio
Press RADIO to open the radio main
menu or to change between the
different wavebands.
Press the multifunction knob to open
the waveband menus with options for the station selection.
For a detailed description of the radio functions 3 122.
Audio players
Press CD or AUX once or several
times to open the USB, iPod ®
or AUX
main menu (if available) or to switch
between these menus.
