256Vehicle care9Warning
If the pressure is too low, this can
result in considerable tyre warm-
up and internal damage, leading to tread separation and even to tyre
blow-out at high speeds.
9 Warning
For specific tyres the
recommended tyre pressure as
shown in the tyre pressure table may exceed the maximum tyre
pressure as indicated on the tyre.
Never exceed the maximum tyre
pressure as indicated on the tyre.
If the tyre pressure must be reduced
or increased on a vehicle with tyre
pressure monitoring system, switch
off ignition.
Temperature dependency
The tyre pressure depends on the
temperature of the tyre. During
driving, tyre temperature and
pressure increase. Tyre pressure
values provided on the tyre
information label and tyre pressure
chart are valid for cold tyres, which means at 20 °C.
The pressure increases by nearly
1.5 psi for a 10 °C temperature
increase. This must be considered
when warm tyres are checked.
The tyre pressure value displayed in
the Driver Information Centre shows
the real tyre pressure. A cooled down tyre will show a decreased value,
which does not indicate an air leak.
Tyre pressure monitoringsystem
The tyre pressure monitoring system
checks the pressure of all four tyres
once a minute when vehicle speed
exceeds a certain limit.Caution
Tyre pressure monitoring system
warns only about low tyre pressure condition and does not replace
regular tyre maintenance by the
driver.
All wheels must be equipped with pressure sensors and the tyres must
have the prescribed pressure.
Notice
In countries where the tyre pressure
monitoring system is legally
required, the use of wheels without
pressure sensors will invalidate the
vehicle operating permit.
The current tyre pressures can be
shown in the Driver Information
Centre.
Midlevel display:
Select the Tyre pressure page under
the Vehicle Information Menu ? in
the Driver Information Centre 3 114.

Vehicle care257Uplevel display:
Select the Tyre pressure page under
the Info Menu in the Driver
Information Centre 3 114.
System status and pressure warnings
are displayed by a message
indicating the corresponding tyre in
the Driver Information Centre.
The system considers the tyre
temperature for the warnings.
Temperature dependency 3 255.
A detected low tyre pressure
condition is indicated by the control
indicator w 3 111.
If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 294.
If w flashes for 60-90 seconds then
illuminates continuously, there is a
fault in the system. Consult a
workshop.
After inflating, some driving may be
required to update the tyre pressure
values in the Driver Information
Centre. During this time w may
illuminate.
If w illuminates at lower temperatures
and extinguishes after driving, this
could be an indicator for approaching
a low tyre pressure condition. Check
tyre pressure.
Vehicle messages 3 122.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w
illuminates continuously.
A spare wheel or temporary spare
wheel is not equipped with pressure
sensors. The tyre pressure
monitoring system is not operational
for these tyres. Control indicator w
illuminates. For the further three
tyres, the system remains
operational.
The use of commercially-available liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
Operating electronic devices or being close to facilities using similar wave
frequencies could disrupt the tyre
pressure monitoring system.
Each time the tyres are replaced, tyre
pressure monitoring system sensors
must be dismounted and serviced.
For the screwed sensor, replace
valve core and sealing ring. For the
clipped sensor, replace complete
valve stem.

258Vehicle careVehicle loading status
Adjust tyre pressure to load condition according to the tyre information labelor tyre pressure chart 3 294, and
select the appropriate setting in the menu Tyre Load in the Driver
Information Centre, Vehicle
Information Menu 3 114. This setting
is the reference for the tyre pressure
warnings.
The Tyre load menu only appears
when the vehicle is at a standstill and
the parking brake is applied. On
vehicles with automatic transmission
the selector lever must be in P.
Midlevel display:Select the Tyre load page under the
Vehicle Information Menu ? in the
Driver Information Centre 3 114.
Select ● Light for comfort pressure up to
three people.
● Eco for Eco pressure up to three
people.
● Max for full loading.
Uplevel display:
Select the Tyre load page under the
Options Menu in the Driver
Information Centre 3 114.
Select
● Light for comfort pressure up to
three people.
● Eco for Eco pressure up to
three people.
● Max for full loading.
Tyre pressure sensor matching
process
Each tyre pressure sensor has a
unique identification code. The
identification code must be matched
to a new wheel position after rotating the wheels or exchanging the
complete wheel set and if one or more tyre pressure sensors were replaced.
The tyre pressure sensor matching
process should also be performed
after replacing a spare wheel with a
road wheel containing the tyre
pressure sensor.
The malfunction light w and the
warning message or code should go
off at the next ignition cycle. The
sensors are matched to the wheel
positions, using a relearn tool, in the following order: left side front wheel,
right side front wheel, right side rear

Vehicle care259wheel and left side rear wheel. The
turn signal light at the current active position is illuminated until sensor ismatched.
Consult a workshop for service. There
are two minutes to match the first
wheel position, and five minutes
overall to match all four wheel
positions. If it takes longer, the
matching process stops and must be
restarted.
The tyre pressure sensor matching
process is:
1. Apply the parking brake.
2. Turn the ignition on.
3. On vehicles with automatic transmission: set the selector
lever to P.
On vehicles with manual
transmission: select neutral.
4. Midlevel display: Use MENU on the turn signal
lever to select the Vehicle
Information Menu ? in the
Driver Information Centre.
Uplevel display:Press p on the steering wheel to
open main menu page.
Select the Info page with Q or P.
Confirm with 9.
5. Select the tyre pressure menu. Midlevel display:
Uplevel display:
6. Midlevel display:Press SET/CLR to begin the
sensor matching process. A
message requesting acceptance
of the process should be
displayed.
Press SET/CLR again to confirm
the selection. The horn sounds
twice to indicate that the receiver
is in relearn mode.
Uplevel display:
Press 9 to begin the sensor
matching process. The horn
sounds twice to indicate that the receiver is in relearn mode.
7. Start with the left side front wheel.

276Vehicle careClean the leather upholstery with
clear water and a soft cloth. In case of heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

Service and maintenance277Service and
maintenanceGeneral information ...................277
Service information ..................277
Recommended fluids, lubricants and parts .................................... 278
Recommended fluids and lubricants ................................ 278General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 106.
European service intervals Maintenance of your vehicle except
CNG (natural gas) is required every
20,000 miles or after one year,
whichever occurs first. Maintenance
of your vehicle with CNG is required
every 10,000 miles or after one year,
whichever occurs first. Additional
engine oil and filter change is
indicated by the engine oil life system, when required earlier than
maintenance.A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:
Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display 3 106.
International service intervals Maintenance of your vehicle is
required every 10,000 miles or after
one year, whichever occurs first.
Additional engine oil and filter change
is indicated by the engine oil life
system, when required earlier than
maintenance.

278Service and maintenanceSevere operating conditions exist if
one or more of the following
circumstances occur frequently: Cold
starting, stop and go operation, trailer operation, mountain driving, driving
on poor and sandy road surfaces,
increased air pollution, presence of
airborne sand and high dust content,
driving at high altitude and large
variations of temperature. Under
these severe operating conditions, certain service work may be requiredmore frequently than the regular
service interval.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 106.
Confirmations
Confirmation of service is recorded in the Service and warranty booklet.
The date and mileage is completed
with the stamp and signature of the servicing workshop.
Make sure that the Service and
warranty booklet is completed
correctly as continuous proof ofservice is essential if any warranty or
goodwill claims are to be met, and is
also a benefit when selling the
vehicle.Recommended fluids,
lubricants and parts
Recommended fluids and lubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.

Customer information305Operating data in the vehicleControl units process data for
operation of the vehicle.
This data includes, e.g.: ● vehicle status information (e.g. wheel rotation rate, speed,
movement delay, lateral
acceleration, "seatbelts
fastened" display),
● ambient conditions (e.g. temperature, rain sensor,
distance sensor).
As a rule such data is transient, not
stored for longer than an operational
cycle, and only processed on board
the vehicle itself. Control units often
include data storage (including the
vehicle key). This is used to allow information to be documented
temporarily or permanently on vehicle
condition, component stress,
maintenance requirements and
technical events and errors.Depending on the technical
equipment level, the data stored is as follows:
● system component operating states (e.g. fill level, tyre
pressure, battery status)
● faults and defects in important system components (e.g. lights,
brakes)
● system reactions in special driving situations (e.g. triggering
of an airbag, actuation of the
stability control systems)
● information on events damaging the vehicle
● for electric vehicles the amount of
charge in the high-voltage
battery, estimated range
In special cases (e.g. if the vehicle
has detected a malfunction), it may be
necessary to save data that would
otherwise just be volatile.
When you use services (e.g. repairs,
maintenance), the operating data
saved can be read together with the
vehicle identification number and
used when necessary. Staff working
for the service net-work ( e.g. garages,manufacturers) or third parties (e.g.
breakdown services) can read the
data from the vehicle. The same
applies to warranty work and quality
assurance measures.
Data is generally read via the OBD
(On-Board Diagnostics) port
prescribed by law in the vehicle. The operating data which is read out,
documents the technical condition of
the vehicle or individual components
and assists with fault diagnosis,
compliance with warranty obligations
and quality improvement. This data,
in particular information on
component stress, technical events,
operator errors and other faults, is
transmitted to the manufacturer
where appropriate, together with the
vehicle identification number. The
manufacturer is also subject to
product liability. The manufacturer
potentially also uses operating data
from vehicles for product recalls. This
data can also be used to check
customer warranty and guarantee
claims.
Fault memories in the vehicle can be
reset by a service company when
carrying out servicing or repairs.

310Head restraint adjustment .............8
Head restraints ............................ 46
Heated mirrors ............................. 40
Heated rear window ..................... 43
Heated steering wheel .................92
Heating .................................. 54, 56
Heating and ventilation system . 145
High beam ......................... 112, 135
High beam assist ........................112
Hill start assist ........................... 180
Horn ....................................... 13, 92
I
Identification plate .....................281
Ignition switch positions .............156
Immobiliser .......................... 38, 112
Indicators .................................... 102
Info Display ................................. 120
Information displays.................... 114
Instrument cluster ........................99
Instrument panel fuse box .........249
Instrument panel illumination .....246
Instrument panel illumination control .................................... 142
Instrument panel overview ........... 10
Interior care ............................... 275
Interior lighting ............................ 142
Interior lights ...................... 142, 246
Interior mirrors .............................. 40Interruption of power supply ......173
Introduction .................................... 3
J Jump starting ............................. 270
K Key, memorised settings ..............24
Keys ............................................. 20
Keys, locks ................................... 20
L
Lane keep assist ................110, 215
Lashing eyes ............................... 81
LED headlights ...................112, 136
Lighting features .........................143
Light switch ................................ 134
Load compartment ................30, 73
Load compartment cover .............79
Load compartment fuse box ......251
Loading information .....................88
Low fuel ..................................... 112
M
Malfunction indicator light ..........109
Manual anti-dazzle ......................40
Manual mode .....................172, 176
Manual seat adjustment ...............48
Manual transmission .................. 173
Manual transmission automated 174
Manual windows ..........................41Massage....................................... 55
Maximum speed ......................... 255
Memorised settings ......................24
Midlevel display .......................... 114
Mirror adjustment ........................... 9 Misted light covers .....................141
N
Natural gas ......................... 104, 220
New vehicle running-in ..............156
Number plate light .....................245
O
Object detection systems ...........200
Odometer ................................... 103 Oil, engine .......................... 278, 283
OnStar ........................................ 130
Outside temperature ....................95
Overrun cut-off ........................... 161
P Parking ................................ 18, 164
Parking assist ............................ 200
Parking brake ............................ 178
Parking lights ............................. 141
Particulate filter ........................... 166
Performance .............................. 288
Performing work ........................230
Pollen filter ................................. 154
Power button .............................. 157
Power outlets ............................... 97

311Power seat adjustment ................50
Power windows ............................ 41
Preheating ................................. 111
Puncture ..................................... 265
Q
Quickheat ................................... 153
R Radio Frequency Identification (RFID) ..................................... 307
Radio remote control ...................21
REACH ....................................... 301
Reading lights ............................ 142
Rear floor storage cover ..............81
Rear fog light .............113, 141, 239
Rear seats .................................... 55
Rear storage ................................. 79
Rear view camera ...................... 209
Rear window wiper and washer ..94
Recommended fluids and lubricants ........................ 278, 283
Refuelling ................................... 220
Registered trademarks ...............304
Retained power off .....................159
Reversing lights .........................141
Ride control systems ..................180
Roof .............................................. 44
Roof load ...................................... 88
Roof rack ..................................... 88S
Safety belts ................................... 56
Safety net .................................... 84
Seat adjustment ............................. 7 Seat belt ........................................ 8
Seat belt reminder .....................107
Seat belts ..................................... 56
Seat heating Seat heating, front .....................54
Seat heating, rear .....................56
Seat position ................................ 47
Selective catalytic reduction .......168
Selector lever ..................... 171, 175
Service ............................... 154, 277
Service display .......................... 106
Service information ....................277
Side airbag system ......................62
Side blind spot alert ....................208
Sidelights .................................... 134
Side turn lights ........................... 245
Software acknowledgement .......301
Software update ......................... 303
Spare wheel ............................... 265
Speed limiter....................... 113, 185
Speedometer ............................. 102
Sport mode ................................ 182
Starting and operating ................156
Starting off ................................... 16
Starting the engine ....................159
Steering ...................................... 156Steering wheel adjustment ......9, 91
Steering wheel controls ...............91
Stop-start system........................ 161
Storage ......................................... 71
Storage compartments .................71
Sunroof ........................................ 44
Sunvisor lights ........................... 143
Sun visors .................................... 43
Symbols ......................................... 4
T
Tachometer ............................... 104
Tail lights ................................... 239
Three-point seat belt .................... 57
Tools .......................................... 253
Tow bar....................................... 223 Towing ................................ 223, 272
Towing another vehicle .............273
Towing equipment .....................224
Towing the vehicle .....................272
Traction Control system ............. 180
Traction Control system off......... 111
Traffic sign assistant ...........113, 211
Trailer coupling ........................... 223
Trailer stability assist .................227
Trailer towing ............................. 223
Transmission ............................... 15
Transmission display .........170, 174
Tread depth ............................... 260
Trip odometer ............................ 103
