VAUXHALL ASTRA K 2019 Owner's Manual

Service and maintenance279Dexos is the newest engine oil quality
that provides optimum protection for
gasoline and diesel engines. If it is
unavailable, engine oils of other listed qualities have to be used.
Recommendations for gasoline
engines are also valid for
Compressed Natural Gas (CNG),
Liquified Petroleum Gas (LPG) and
Ethanol (E85) fuelled engines.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 283.
Topping up engine oilCaution
In case of any spilled oil, wipe it up and dispose it properly.
Engine oils of different manufacturersand brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oils for all petrol
engines with only ACEA quality is
prohibited, since it can cause engine
damage under certain operating
conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 283.
Additional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.
Engine oil viscosity grades
The SAE viscosity grade gives
information of the thickness of the oil.
Multigrade oil is indicated by two
figures, e.g. SAE 5W-30. The first
figure, followed by a W, indicates the
low temperature viscosity and the
second figure the high temperature viscosity.
Select the appropriate viscosity grade depending on the minimum ambient
temperature 3 283.All of the recommended viscosity
grades are suitable for high ambient
temperatures.
Coolant and antifreeze
Use only organic acid type-long life
coolant (LLC) antifreeze approved for
the vehicle. Consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -28 °C. In
northern countries with very low
temperatures the factory filled coolant
provides frost protection down to
approx. -37 °C. This concentration
should be maintained all year round.
The use of additional coolant
additives that intend to give additional
corrosion protection or seal against
minor leaks can cause function
problems. Liability for consequences resulting from the use of additional
coolant additives will be rejected.

280Service and maintenanceWasher fluid
Use only washer fluid approved for
the vehicle to prevent damage of wiper blades, paintwork, plastic and
rubber parts. Consult a workshop.
Brake and clutch fluidOver time, brake fluid absorbs
moisture which will reduce braking
effectiveness. The brake fluid should therefore be replaced at the specified
interval.

Technical data281Technical dataVehicle identification..................281
Vehicle Identification Number ..281
Identification plate ...................281
Engine identification ................282
Vehicle data ............................... 283
Recommended fluids and lubricants ................................ 283
Engine data ............................. 286
Performance ............................ 288
Vehicle weight ......................... 290
Vehicle dimensions .................292
Capacities ................................ 293
Tyre pressures ........................ 294Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number
may be stamped on the identification plate and on the floor pan, under thefloor covering, visible under a cover.
The Vehicle Identification Number
may be embossed on the instrument
panel, visible through the windscreen,
or in the engine compartment on the
right body panel.
Identification plate
The identification plate is located on
the front left or right door frame.

282Technical dataInformation on identification label:1:manufacturer2:type approval number3:vehicle identification number4:permissible gross vehicle weight
rating in kg5:permissible gross train weight
in kg6:maximum permissible front axle
load in kg7:maximum permissible rear axle
load in kg8:vehicle-specific or country-
specific data
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight. For
example, if the front axle is bearing its
maximum permissible load, the rear
axle can only bear a load that is equal
to the gross vehicle weight minus the front axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identification
The technical data tables show the
engine identifier code. Engine data
3 286.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided
with your vehicle or other national
registration documents.

Technical data283Vehicle data
Recommended fluids and lubricants
European service schedule Required engine oil qualityAll European countries with European service interval 3 277Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos1 Gen2✔–dexos2–✔
Diesel engines only: In case dexos quality is unavailable, you may use max. one litre engine oil quality ACEA C3 once
between each oil change.
Engine oil viscosity grades
All European countries with European service interval 3 277Ambient temperaturePetrol and diesel enginesdown to -25 °CSAE 0W-20 or SAE 0W-30 or SAE 0W-40SAE 5W-30 or SAE 5W-40below -25 °CSAE 0W-20 or SAE 0W-30 or SAE 0W-40

284Technical dataInternational service schedule
Required engine oil qualityAll countries with international service interval 3 277Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos1 Gen2✔–dexos2–✔
In case dexos quality is unavailable you may use the oil qualities listed below:
All countries with international service interval 3 277Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesACEA A3/B4–✔ACEA C3–✔
Engine oil viscosity grades
All countries with international service interval 3 277Ambient temperaturePetrol and diesel enginesdown to -25 °CSAE 0W-20 or SAE 0W-30 or SAE 0W-40SAE 5W-30 or SAE 5W-40

Technical data285All countries with international service interval 3 277below -25 °CSAE 0W-20 or SAE 0W-30 or SAE 0W-40down to -20 °CSAE 10W-30 1)
or SAE 10W-40 1)1)
Permitted, but usage of oil with dexos quality is recommended.

286Technical dataEngine dataEngine identifier codeD10XFLD10XFLD14XFLB14XFT / D14XFTD14XNTD16SHTSales designation1.01.01.41.41.4 CNG1.6Engineering codeD10XFTD10XFTD14XFTB14XFTD14XNTD16SHTPiston displacement [cm3
]9999991399139913991598Engine power [kW]77 / 66 2)9211081147at rpm3700-60004000-56005000-560056005500Torque [Nm]170245/230 3)245/2303)200280at rpm1800-43002000-35002000-40002000-36001650-5000Fuel typePetrolPetrolPetrolNatural gas/PetrolPetrolOctane rating RON 4)recommended9595959598possible9898989895possible9191919191Additional fuel type–––Natural gas (CNG)–2)
Ecotec version
3) With Stop-start system.
4) A country-specific label at the fuel filler flap can supersede the engine-specific requirement.

Technical data287Engine identifier codeD16DTND16DTID16DTHD16DTRSales designation1.61.61.61.6Engineering codeD16DTND16DTID16DTHB16DTRPiston displacement [cm3
]1598159815981598Engine power [kW]11081100110at rpm350035003500-40004000Torque [Nm]300300320350at rpm1750-20001750-20002000-22501500-2250Fuel typeDieselDieselDieselDiesel

288Technical dataPerformance
5-door HatchbackEngineD10XFLD14XFLB14XFT / D14XFT
D14XNT
CNG
D16SHT
Maximum speed [mph]Manual transmission121/117 2)127134121146Manual transmission automated–––––Automatic transmission––130–1462)
Ecotec versionEngineD16DTND16DTI / D16DTLB16DTH / D16DTHB16DTRMaximum speed [mph]Manual transmission124124132137––––Automatic transmission––129–
