Driving and operating173
sound and the following symbol is
indicated until the next traffic sign is detected.
In some cases, traffic sign assistant is
cleared up automatically by the
system.
Fault The traffic sign assistant system may
not operate correctly when:
■ The area of the windscreen, where the front camera is located, is not
clean.
■ Traffic signs are completely or partially covered or difficult to
discern.
■ There are adverse environmental conditions, e.g. heavy rain, snow,
direct sunlight or shadows. In this
event, No Traffic Sign Detection
due to Weather is indicated on the
display.
■ Traffic signs are incorrectly mounted or damaged.
■ Traffic signs do not comply with the
Vienna Convention on traffic signs
(Wiener Übereinkommen über
Straßenverkehrszeichen).Caution
The system is intended to help the driver within a defined speed
range to discern certain traffic
signs. Do not ignore traffic signs
which are not displayed by the
system.
The system does not discern any other than the conventional traffic
signs that might give or end a
speed limit.
Do not let this special feature
tempt you into taking risks when
driving.
Always adapt speed to the road
conditions.
The driver assistance systems do not relieve the driver from full
responsibility for vehicle
operation.
Lane departure warning
The lane departure warning systemobserves the lane markings between
which the vehicle is driving via a front camera. The system detects lane
changes and warns the driver in the
event of an unintended lane change
via visual and acoustic signals.
Criteria for the detection of an
unintended lane change are:
■ no operation of turn signals
■ no brake pedal operation
■ no active accelerator operation or speeding-up
■ no active steering

Vehicle care203Instrument panel fuse box
In left-hand drive vehicles, the fuse
box is behind the storage
compartment in the instrument panel.
Open the compartment and push it to the left to unlock. Fold the
compartment down and remove it.
In right-hand drive vehicles, the fuse
box is located behind a cover in the
glovebox. Open the glovebox, then
open the cover and fold it down.
No.Circuit1Displays2Body control unit, exterior lights3Body control unit, exterior lights4Infotainment system5Infotainment system, instru‐
ment6Power outlet, cigarette lighter7Power outlet8Body control module, left low
beam9Body control module, right low
beam10Body control module, door locks11Interior fan12Driver power seat13Passenger power seat14Diagnostic connector15Airbag

Vehicle care209
Turn the adjuster wheel to select the
tyre pressure monitoring system.
System status and pressure warnings
are displayed by a message with the
corresponding tyre flashing in the
DIC.A detected low tyre pressure
condition is indicated by the control
indicator w 3 93.
If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 242.
If w flashes for 60-90 seconds and
then illuminates continuously, there is a fault in the system. Consult a
workshop.
After inflating, driving may be
required to update the tyre pressure
values in the DIC. During this time w
may illuminate.
If w illuminates at lower temperatures
and extinguishes after some driving,
this could be an indicator for
approaching a low tyre pressure
condition. Check tyre pressure.
Vehicle messages 3 102.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w
illuminates continuously.
A temporary spare wheel is not
equipped with pressure sensors. The
tyre pressure monitoring system is
not operational for these wheels.
Control indicator w illuminates. For
the further three wheels the system
remains operational.
The use of commercially available
liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
External high-power radio equipment
could disrupt the tyre pressure
monitoring system.

210Vehicle care
Each time the tyres are replaced, tyrepressure monitoring system sensors
must be dismounted and serviced. For the screwed sensor: replace
valve core and sealing ring. For
clipped sensor: replace complete
valve stem.
Vehicle loading status Adjust tyre pressure to load condition according to tyre information label or
tyre pressure chart 3 242, and select
the relevant setting in the menu Tire
Load in the DIC, Vehicle Information
Menu 3 95.Select:
■ Light for comfort pressure up to
3 people
■ Eco for Eco pressure up to
3 people
■ Max for full loading
TPMS sensor matching process
Each TPMS sensor has a unique
identification code. The identification
code must be matched to a new tyre/
wheel position after rotating the tyres
or exchanging the complete wheel set and if one or more TPMS sensors
were replaced. The TPMS sensor
matching process should also be
performed after replacing a spare tyre
with a road tyre containing the TPMS
sensor.
The malfunction light and the warning
message or code should go off at the next ignition cycle. The sensors are
matched to the tyre/wheel positions,
using a TPMS relearn tool, in the
following order: left side front tyre,
right side front tyre, right side rear tyreand left side rear tyre. The turn signal
light at the current active position is
illuminated until sensor is matched.
Consult your workshop for service or
to purchase a relearn tool. There are
2 minutes to match the first tyre/wheel position, and 5 minutes overall to
match all four tyre/wheel positions. If
it takes longer, the matching process
stops and must be restarted.
The TPMS sensor matching process
is:
1. Apply the parking brake; on vehicles with automatic
transmission set the selector lever to P.
2. Turn the ignition on.
3. Use the MENU button on the turn
signal lever to select the Vehicle
Information Menu in the DIC.
4. Turn the adjuster wheel to scroll to
the tyre pressure menu.
5. Press the SET/CLR button to
begin the sensor matching process. A message requesting
acceptance of the process should
display.

Vehicle care211
6. Press the SET/CLR button again
to confirm the selection. The horn sounds twice to signal the
receiver is in relearn mode.
7. Start with the left side front tyre.
8. Place the relearn tool against the tyre sidewall, near the valve stem.
Then press the button to activate
the TPMS sensor. A horn chirp
confirms that the sensor
identification code has been
matched to this tyre and wheel
position.
9. Proceed to the right side front tyre,
and repeat the procedure in
Step 8.
10. Proceed to the right side rear tyre,
and repeat the procedure in
Step 8.
11. Proceed to the left side rear tyre, and repeat the procedure in
Step 8. The horn sounds twice to
indicate the sensor identification
code has been matched to the left side rear tyre, and the TPMS
sensor matching process is no
longer active.12. Turn off the ignition.
13. Set all four tyres to the recommended air pressure level
as indicated on the tyre pressure
label.
14. Ensure the tyre loading status is set according selected pressure
3 95.
Temperature dependency Tyre pressure depends on the
temperature of the tyre. During
driving, tyre temperature and
pressure increase.
The tyre pressure value displayed in
the DIC shows the actual tyre
pressure. Therefore it is important to
check tyre pressure with cold tyres.
Tread depth
Check tread depth at regular
intervals.
Tyres should be replaced for safety
reasons at a tread depth of 2-3 mm
(4 mm for winter tyres).For safety reasons it is recommended
that the tread depth of the tyres on
one axle should not vary by more than 2 mm.
The legally permissible minimum
tread depth (1.6 mm) has been
reached when the tread has worn
down as far as one of the tread wear
indicators (TWI). Their position is
indicated by markings on the
sidewall.
If there is more wear at the front than
the rear, swap round front wheels and rear wheels periodically. Ensure that
the direction of rotation of the wheels
is the same as before.

Vehicle care227
UnderbodySome areas of the vehicle underbody
have a PVC undercoating while other critical areas have a durable
protective wax coating.
After the underbody is washed, check
the underbody and have it waxed if
necessary.
Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.
Towing equipment
Do not clean the coupling ball bar with
a steam-jet or high-pressure jet
cleaner.
Interior care Interior and upholsteryOnly clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.Clean the leather upholstery with
clear water and a soft cloth. In case of
heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

228Service and maintenanceService and
maintenanceGeneral information ...................228
Recommended fluids, lubricants and parts .................................... 229General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 86.
European service intervals
Maintenance of your vehicle is
required every 20,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania, San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display 3 86.
International service intervals Maintenance of your vehicle is
required every 10,000 miles or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 86.

Service and maintenance229
Confirmations
Confirmation of service is recorded in the Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service interval with remaining engine oil life duration The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 86.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants Only use products that meet the
recommended specifications.
Damage resulting from the use of
products not in line with these
specifications will not be covered by
the warranty.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for gasoline and diesel engines. If it is
unavailable, engine oils of other listed qualities must be used.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 233.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 233.

250
Graphic-Info-Display, Colour-Info-Display ............................ 100
Ground clearance .......................133
H Halogen headlights ....................192
Hand brake ......................... 146, 147
Hazard warning flashers ............116
Headlight flash ........................... 111
Headlight range adjustment ......112
Headlights................................... 109
Headlights when driving abroad 112
Head restraint adjustment .............8
Head restraints ............................ 45
Heated mirrors ............................. 30
Heated rear window ..................... 34
Heated steering wheel .................78
Heating ........................................ 53
Heating and ventilation system . 122
High beam ........................... 94, 110
High beam assist ..................94, 111
Hill start assist ........................... 149
Horn ....................................... 15, 78
I
Identification plate .....................231
Ignition switch positions .............133
Immobiliser ............................ 29, 94
Indicators ...................................... 84
Information displays...................... 95Instrument cluster ........................84
Instrument panel fuse box .........203
Instrument panel illumination .....199
Instrument panel illumination control .................................... 118
Instrument panel overview ........... 11
Interactive driving system ...........151
Interior care ............................... 227
Interior lighting ............................ 118
Interior lights ...................... 118, 199
Interior mirrors .............................. 31
Interruption of power supply ......145
Introduction .................................... 3
ISOFIX child restraint systems ....68
J
Jump starting ............................. 221
K
Key, memorised settings ..............22
Keys ............................................. 20
Keys, locks ................................... 20
L
Lane departure warning .......92, 173
Lashing eyes ............................... 75
Light switch ................................ 109
Load compartment ................25, 72
Load compartment fuse box ......204Loading information .....................76
Low fuel ....................................... 94
M
Malfunction indicator light ............90
Manual anti-dazzle ......................31
Manual mode ............................. 144
Manual transmission .................. 146
Memorised settings ......................22
Mirror adjustment ........................... 9
Misted light covers .....................118
N
New vehicle running-in ..............133
Number plate light .....................199
O Object detection systems ...........159
Odometer ..................................... 85
Oil, engine .......................... 229, 233
Operate pedal ............................... 90
Outside temperature ....................81
Overrun cut-off ........................... 135
P
Parking ................................ 19, 137
Parking assist ............................ 159
Parking brake ............................ 147
Parking lights ............................. 117
Particulate filter ........................... 138

251
Performance .............................. 238
Performing work ........................185
Pollen filter ................................. 131
Power outlets ............................... 83
Power seat adjustment ................51
Power steering.............................. 92
Power windows ............................ 32
Preheating ................................... 92
Puncture ..................................... 216
Q
Quickheat ................................... 130
R Radio Frequency Identification (RFID) ..................................... 247
Radio remote control ...................21
Reading lights ............................ 119
Rear floor storage cover ..............74
Rear fog light ............................... 94
Rear fog lights ........................... 117
Rear storage ................................. 74
Rear view camera ...................... 168
Recommended fluids and lubricants ........................ 229, 233
Refuelling ................................... 175 Retained power off .....................133
Reversing lights .........................118
Ride control systems ..................149
Rollover protection system ...........44S
Seat adjustment ....................... 7, 48
Seat belt ........................................ 8
Seat belt reminder .......................89
Seat belts ..................................... 54
Seat folding .................................. 50
Seat position ................................ 47
Selective catalytic reduction .......140
Selector lever ............................. 143
Service ............................... 131, 228
Service display ............................ 86
Service information ....................228
Side airbag system ......................61
Side blind spot alert ....................166
Sidelights .................................... 109
Side turn signal lights ................198
Soft top ........................................ 34
Spare wheel ............................... 218
Speed limiter............................... 155
Speedometer ............................... 84
Starting and operating ................133
Starting off ................................... 17
Starting the engine ....................134
Steering ...................................... 132
Steering wheel adjustment ....10, 77
Steering wheel controls ...............77
Stop-start system........................ 135
Storage ......................................... 69
Storage compartments .................69Sunvisor lights ........................... 119
Sun visors .................................... 34
Symbols ......................................... 4
T
Tachometer ................................. 85
Tail lights ................................... 196
Three-point seat belt .................... 56
Tools .......................................... 205
Top-tether fastening eyes ............68
Tow bar....................................... 178
Towing ................................ 178, 223
Towing another vehicle .............224
Towing equipment .....................180
Towing the vehicle .....................223
Traction Control system ............. 149
Traction Control system off........... 92
Traffic sign assistant ...................170
Trailer coupling ........................... 178
Trailer towing ............................. 179
Transmission ............................... 17
Transmission display .................142
Tread depth ............................... 211
Trip odometer .............................. 85
Turn and lane-change signals ...116
Turn signal ................................... 89
Tyre chains ................................ 212
Tyre designations ......................207
Tyre pressure ............................ 207
