12In brief
1Power windows .....................32
2 Exterior mirrors .....................29
3 Cruise control .....................153
Speed limiter ....................... 155
Forward collision alert .........156
4 Side air vents ...................... 130
5 Turn and lane-change
signals, headlight flash,
low beam and high beam,
high beam assist .................116
Exit lighting ......................... 120
Parking lights ...................... 117
Buttons for Driver
Information Centre (DIC) ....... 95
6 Instruments .......................... 84
7 Steering wheel controls .......77
8 Driver Information Centre
(DIC) ..................................... 95
9 Windscreen wiper,
windscreen washer
system, headlight washer
system ................................... 7910 Sport mode ........................ 151
Central locking system ..........22
Hazard warning flashers ....116
Control indicator for airbag deactivation .......................... 89
Control indicator for front
passenger seat belt .............89
Tour mode .......................... 151
11 Info-Display ........................ 100
12 Anti-theft alarm system
status LED ........................... 27
13 Centre air vents .................. 130
14 Glovebox, lockable ...............69
Fuse box ............................. 203
15 Traction Control system
(TC) ..................................... 149
Electronic Stability Control (ESC) .................................. 150
Parking assist systems .......159
Lane departure warning .....173
Eco button for stop-start
system ................................. 13516 Climate control system ........ 122
17 AUX input, USB input ..........11
18 Power outlet .......................... 83
19 Soft top operation switch .....34
Central window switch .........32
20 Selector lever, transmission
21 Parking brake, manual or
electric operation ................147
22 Ignition switch with
steering wheel lock ............133
23 Horn ..................................... 78
Driver airbag ........................ 60
24 Bonnet release lever ..........186
25 Storage compartment ..........70
Fuse box ............................ 203
26 Steering wheel adjustment ..77
27 Light switch ........................ 109
Rear fog light ...................... 117
Instrument illumination .......118
Headlight range
adjustment ......................... 112
Front fog lights ...................117

16In briefClimate controlHeated rear window, heatedexterior mirrors
The heating is operated by pressing
the Ü button.
Heated rear window 3 34.
Demisting and defrosting the
windows, Air conditioning system
Press button V.
Set the temperature control to the
highest level.
Switch on heated rear window Ü.
Air conditioning system 3 123.
Demisting and defrosting the
windows, Electronic climate control
Press button V.
Temperature and air distribution are
set automatically and the fan runs at
high speed.
Switch on heated rear window Ü.
Electronic climate control 3 125.

100Instruments and controls
in 5 mile steps and shows the effectof topography or driving behaviour
on fuel consumption.
Graphic-Info-Display,
Colour-Info-Display
Depending on the vehicle
configuration the vehicle has a
Graphic-Info-Display or a Colour-
Info-Display.
The Info-Display is located in the instrument panel above the
Infotainment system.
Graphic-Info-DisplayDepending on the Infotainment
system, the Graphic-Info-Display is
available in two versions.
Graphic-Info-Display indicates:
■ time 3 81
■ outside temperature 3 81
■ date 3 81
■ electronic climate control settings 3 125
■ Infotainment system, see description in the Infotainment
system manual
■ settings for vehicle personalisation 3 104
Colour-Info-Display
The Colour-Info-Display indicates in
colour:
■ time 3 81
■ outside temperature 3 81
■ date 3 81
■ electronic climate control settings 3 125
■ rear view camera 3 168
■ Infotainment system, see description in the Infotainment
system manual
■ navigation, see description in the Infotainment system manual

Instruments and controls105
■Sport steering : Steering support is
reduced.
■ Swap backlight colour main instr. :
Changes the instrument
illumination colour.
Languages
Selection of the desired language.
Time Date
See 'Clock' 3 81.
Radio settings
See Infotainment system manual for further information.
Phone settings
See Infotainment system manual for further information.Vehicle settings
■ Climate and air quality
Auto fan speed : Modifies the level
of the cabin airflow of the climate
control in automatic mode.
Climate control mode : Controls the
state of the cooling compressor
when the vehicle is started. Last
setting (recommended) or at
vehicle start is either always ON or
always OFF.
Auto rear demist : Activates heated
rear window automatically.
■ Comfort settings
Chime volume : Changes the
volume of warning chimes.
Personalization by driver : Activates
or deactivates the personalisation
function.
■ Park assist / Collision detection
Park assist : Activates or
deactivates the ultrasonic sensors.
Activation is selectable with or
without attached trailer coupling.
Side blind zone alert : Changes the
settings for the side blind spot alert
system.

Instruments and controls107
Sport Mode Profile■ Engine Sport Performance :
Accelerator pedal and gear change
characteristics become more
responsive.
■ Sport Mode Back Lighting :
Changes the instrument
illumination colour.
■ Sport Suspension : Damping
becomes harder.
■ Sport Steering : Steering support is
reduced.
Languages
Selection of the desired language.
Time and Date
See Infotainment system manual for
further information.
Radio Settings
See Infotainment system manual for
further information.
Phone Settings
See Infotainment system manual for
further information.Navigation Settings
See Infotainment system manual for
further information.
Display Settings ■ Home Page Menu :
See Infotainment system manual
for further information.
■ Rear Camera Options :
Press to adjust the rear camera
options 3 168.
■ Display Off :
See Infotainment system manual
for further information.
■ Map Settings :
See Infotainment system manual
for further information.
Vehicle Settings ■ Climate and Air Quality
Auto Fan Speed : Modifies the level
of the cabin airflow of the climate
control in automatic mode.
Air Conditioning Mode : Controls the
state of the cooling compressor
when the vehicle is started. Last setting (recommended) or atvehicle start is either always ON or
always OFF.
Auto Rear Demist : Activates
heated rear window automatically.
■ Comfort and Convenience
Chime Volume : Changes the
volume of warning chimes.
Personalisation by Driver :
Activates or deactivates the
personalisation function.
■ Collision Detection Systems
Park Assist : Activates or
deactivates the ultrasonic sensors.
Activation is selectable with or
without attached trailer coupling.
Side Blind Zone Alert : Activates or
deactivates the side blind spot alert
system.
■ Lighting
Vehicle Locator Lights : Activates or
deactivates the entry lighting.
Exit Lighting : Activates or
deactivates and changes the
duration of exit lighting.

122Climate controlClimate controlClimate control systems ............. 122
Air vents ..................................... 130
Maintenance .............................. 131Climate control systems
Heating and ventilation
system
Controls for: ■ temperature
■ air distribution
■ fan speed
■ demisting and defrosting
Heated rear window Ü 3 34.
Temperature
red=warmblue=coldHeating will not be fully effective until
the engine has reached normal
operating temperature.
Air distributions=to windscreen and front door
windowsM=to head area via adjustable air
ventsK=to foot well
All combinations are possible.
Fan speed
Adjust the air flow by switching the fan to the desired speed.

Climate control123
Demisting and defrosting
■Press button V: fan automatically
switches to higher speed, the air distribution is directed towards the
windscreen.
■ Set temperature control to warmest
level.
■ Switch on heated rear window Ü.
■ Open side air vents as required and
direct them towards the door
windows.
Air conditioning system
In addition to the heating and
ventilation system, the air
conditioning system has controls for:
n=cooling4=air recirculation
Heated seats ß 3 53, Heated
steering wheel * 3 78.
Cooling n
Press button
n to switch on cooling.
Activation is indicated by illumination
of the LED in the button. Cooling is
only functional when the engine is
running and climate control fan is switched on.
Press button n again to switch off
cooling.
The air conditioning system cools and
dehumidifies (dries) as soon as the
outside temperature is slightly above
the freezing point. Therefore
condensation may form and drip from under the vehicle.

124Climate control
If no cooling or drying is required,
switch off the cooling system for fuel
saving reasons. Activated cooling
may inhibit autostops.
Air recirculation system 4
Press button
4 to activate air
recirculation mode. Activation is
indicated by the LED in the button.
Press button 4 again to deactivate
air recirculation mode.
9 Warning
The exchange of fresh air is
reduced in air recirculation mode.
In operation without cooling the air humidity increases, so the
windows may mist up from inside.
The quality of the passenger
compartment air deteriorates,
which may cause the vehicle
occupants to feel drowsy.
In warm and very humid ambient air conditions, the windscreen may mist
up from outside, when cold air is
directed to it. If windscreen mists up
from outside, activate windscreen
wiper and deactivate s.
Maximum cooling
Briefly open the windows so that hot
air can disperse quickly.
■ Switch on cooling n.
■ Air recirculation system 4 on.
■ Press air distribution switch M.
■ Set temperature control to coldest level.
■ Set fan speed to highest level.
■ Open all vents.

Climate control125
Demisting and defrosting the
windows V
■
Press button V: fan automatically
switches to higher speed, the air distribution is directed towards the
windscreen.
■ Set temperature control to warmest
level.
■ Switch on heated rear window Ü.
■ Open side air vents as required and
direct them towards the door
windows.
Notice
If the V button is pressed while the
engine is running, an Autostop will
be inhibited until the V button is
pressed again.
If the s button is pressed with the fan
switched on and the engine running, an Autostop will be inhibited until the
s button is pressed again or until the
fan is switched off.
If the V button is pressed while the
engine is in an Autostop, the engine will restart automatically.
If the s button is pressed with the fan
switched on while the engine is in an Autostop, the engine will restart
automatically.
Stop-start system 3 135.
Electronic climate control
system The dual zone climate control allows
different climatisation temperatures
for driver side and front passenger
side.In Automatic mode, temperature, fan speed and air distribution are
regulated automatically.
Controls for:
■ temperature on driver side
■ air distribution
■ fan speed
■ temperature on front passenger side
n=coolingAUTO=automatic mode4=manual air recirculationV=demisting and defrosting
