6In briefIn briefInitial drive informationVehicle unlocking
Press button c briefly to unlock the
doors and boot lid. Open the doors by
pulling the handles.
Soft top 3 34, Windows 3 31.
To open the boot lid, push the brand
emblem at the bottom half.
Pressing button x opens the boot
lid while the vehicle remains locked.
Radio remote control 3 20, Central
locking system 3 21, Load
compartment 3 24.

22Keys, doors and windows
Unlocking
Press button c.
Two settings are selectable in the
vehicle personalisation 3 103:
■ Press button c once briefly to
unlock both doors, load
compartment and fuel filler flap.
Hold button c pressed again to
open the windows and the soft top
3 31,
or
■ to unlock only the driver's door, load
compartment and fuel filler flap,
press button c once briefly. To
unlock the entire vehicle, press
button c twice briefly.
The setting can be changed in the Settings menu in the Info-Display
3 103.
The setting can be saved for the key
being used. Memorised settings
3 21.
Unlocking and opening the boot lid 3 24.
Locking Close doors, load compartment and
fuel filler flap.
Press button e briefly.
If the driver's door is not closed
properly, the central locking system will not work.
Hold button e pressed again to close
the soft top and the windows 3 31.
Central locking buttons Locks or unlocks both doors, the load compartment and fuel filler flap from
the passenger compartment.

24Keys, doors and windows
Additionally, it is configurable to
unlock the driver's door or both doors after the ignition is switched off and
the ignition key is removed (manual
transmission) or the selector lever is
moved to position P (automatic
transmission).
Settings can be changed in the
Settings menu in the Info-Display.
Vehicle personalisation 3 103.
The settings can be saved for the key being used 3 21.Doors
Load compartment
Boot lid Opening
Press button x on radio remote
control or after unlocking push the
brand emblem at the bottom half to
open the boot lid.
Pressing button x opens the boot
lid while the vehicle remains locked.
Central locking system 3 21.
Load compartment 3 72.

Keys, doors and windows25
Closing
Use the interior handle.
Do not touch the brand emblem whilst closing as this could unlock the boot
lid again.
Central locking system 3 21.
Blockage of boot lid
The boot lid can only be opened when
the soft top is completely opened or
closed. The soft top lid must be
closed.
Manual closing of the soft top 3 34.
Blockage of soft top
The soft top can only be operated
when the boot lid is closed.
General hints for operating the
boot lid9 Danger
Do not drive with the boot lid open
or ajar, e.g. when transporting
bulky objects, since toxic exhaust
gases, which can not be seen or
smelled, could enter the vehicle.
This can cause unconsciousness
and even death.
Caution
Before opening the boot lid check
overhead obstructions, such as a
garage door, to avoid damage to
the boot lid. Always check the
moving area above and behind the
boot lid.
Notice
The installation of certain heavy
accessories onto the boot lid may
affect its ability to remain open.

26Keys, doors and windowsVehicle security
Anti-theft locking system9 Warning
Do not use the system if there are
people in the vehicle! The doorscannot be unlocked from the
inside.
The system deadlocks the doors. The
doors must be closed otherwise the
system cannot be activated.
If the ignition was on, the driver's door
must be opened and closed once so
that the vehicle can be secured.
Unlocking the vehicle disables the
mechanical anti-theft locking system.
This is not possible with the central
locking button.
Activating
Press e on the radio remote control
twice briefly within 15 seconds. Long press will activate soft top closing.
Anti-theft alarm system The anti-theft alarm system is
combined with the central locking
system.
It monitors:
■ Doors, boot lid, bonnet
■ Passenger compartment including adjoining load compartment
■Vehicle inclination, e.g. if it is raised
■ Ignition
Activation ■ Self-activated 30 seconds after locking the vehicle (initialisation of
the system)
■ Directly by pressing e on the radio
remote control twice briefly. Long
press will activate soft top closing.
Notice
Changes to the vehicle interior, such as the use of seat covers and openwindows, could impair the function
of passenger compartment
monitoring.

Keys, doors and windows27
Activation without monitoring of
passenger compartment and
vehicle inclination
Switch off the monitoring of
passenger compartment and vehicle
inclination when animals are being
left in the vehicle, because of high
volume ultrasonic signals or
movements triggering the alarm. Also switch off when the vehicle is on a
ferry or train.
1. Close boot lid, bonnet, windows and soft top.
2. Press button o. LED in the
button o illuminates for a
maximum of 10 minutes.
3. Close doors.
4. Activate the anti-theft alarm system.
To prevent false alarms passenger
compartment monitoring is
deactivated if the soft top is open. The
LED in the button o does not
illuminate.
If only the windows are open,
passenger compartment monitoring operates restricted and the LED in the
button o illuminates.
Status message is displayed in the
Driver Information Centre.Status LED
Status LED is integrated in the sensor
on top of the instrument panel.
Status during the first 30 seconds of
anti-theft alarm system activation:
LED illuminates=test, arming delay.LED flashes
quickly=doors, boot lid, soft
top or bonnet not
completely closed, or system fault.
Status after system is armed:
LED flashes
slowly=system is armed.

36Keys, doors and windows
Safety stop
The button on the remote control or
the switch in the centre console must
be actuated until the soft top is in its
respective end position. Releasing
the button or the switch during
operation stops soft top movement
immediately. The soft top remains in
intermediate position only for a
certain time. After this time a warning chime sounds, the hydraulic pressure
in the system decreases and the soft
top can start to move by itself.
Actuating button or switch once more
continues operation.
Requirements for operation ■ Vehicle is stationary or driving with a speed up to 31 mph.
■ Load compartment partition isfolded out, pass-through flap is
closed 3 72.
■ Soft top lid is engaged in closed position.
■ Boot lid is completely closed.
■ Outside temperature is not lower than -7 °C for opening and -10 °C
for closing.
■ Vehicle battery voltage is sufficient.
■ The system is not overloaded by repeated operation (max. 5
complete cycles in succession).If any of these requirements are not fulfilled, a warning chime sounds
and a message appears in the
Driver Information Centre when the
switch is actuated and the soft top
will not open or close.
■ There must be no objects in front of
the rear window or in the pivot area
of the soft top and the soft top lid.
If the automatic drive is not
operational when the soft top is open,
execute a manual closing process,
see the following instructions in
"Manual closing in the event of a
system fault".

38Keys, doors and windows
■Allen key with 4 mm hexagon on the
long side and 6 mm hexagon on the short side, located in the glovebox,
■ two strings, located in the glovebox,
■ screwdriver, located in the tool box in the load compartment 3 202.
1. Switch off ignition.
2. Open the boot lid and remove the
screwdriver from the tool box.3. On the inside of the upper load compartment edge is a lever for
releasing the soft top lid. Locate
the lever and unlatch by swivelling the lever downwards.
Notice
The boot lid cannot be opened from
next step on.
Remove the screwdriver from the
toolbox for further operation. It is
possible that the load compartment
cannot be opened until the vehicle is
at a workshop. Therefore remove
any required objects from the load
compartment.
4. Close boot lid.5. Lift up soft top lid from both sides simultaneously up to approx. the
half raised position.

Keys, doors and windows41
18.Push down firmly each side of the
tension bow. Simultaneously pull
the string with a screwdriver cross in the loop slowly and continuous
to the front. Possibly support
yourself on the door frame with
the other hand. Execute this on
both sides to latch the soft top at
the rear.
After the last step, the boot lid can be
opened again. Allow the strings to be removed by your workshop.
The soft top may not be opened with
fixed strings.
Wind deflector
There are two wind deflectors located in a bag behind the rear seat
backrests. Fold down the rear
backrests 3 72, open the Velcro
fasteners and move out the bag from
the recess.
■ The small wind deflector can be placed between the rear head
restraints.
■ The big wind deflector can be placed behind the front seats.
Do not place any objects on the wind
deflector.
To install the deflectors, the soft top
should be opened.
Fitting of the small wind
deflector ■ Fold down left rear backrest 3 72.
■ Remove the cover from the
guidance between the rear head
restraints by sliding sideways to the
left vehicle side.

72StorageLoad compartmentLoad compartment extension
Folding load compartment partition
To enlarge the load compartment
when the soft top is closed, the load
compartment partition can be folded
in.
■ Close soft top 3 34.
■ Open the boot lid 3 24.
■ To fold in, push the load
compartment partition at the loop
area upwards to the inside.
■ To fold out the load compartment partition, pull the strap downwardsto the rear. The pass-through flap
must be closed in vertical position
by the Velcro fasteners.
During soft top operation or when it is opened, the load compartment
partition must be folded out.A warning chime sounds and a
message appears in the Driver
Information Centre if the load
compartment partition is not folded
out fully, including the pass-through
flap behind the rear seats, when actuating the switch to open the soft
top.
Folding rear backrests
To enlarge load compartment further
or to gain access to the wind deflector
bag, both rear backrests can be
folded down.
