16In briefAutomatic transmissionP:parkR:reverseN:neutralD:automatic modeM:manual mode: move selector
lever from D to the left.<:manual mode upshifting]:manual mode downshifting
The selector lever can only be moved
out of P when the ignition is on and
the brake pedal is applied. To engage
P or R, press the release button.
Automatic transmission 3 146.
Starting off
Check before starting off ● Tyre pressure and condition 3 214, 3 247.
● Engine oil level and fluid levels 3 190.
● All windows, mirrors, exterior lighting and number plates are
free from dirt, snow and ice and
are operational.
● Proper position of mirrors, seats and seat belts 3 29, 3 47,
3 55.
● Soft top must be completely opened or closed 3 34.
● Brake function at low speed, particularly if the brakes are wet.Starting the engine
● Turn key to position 1.
● Move the steering wheel slightly to release the steering wheel
lock.
● Manual transmission: operate clutch and brake pedal.
Automatic transmission: operate
brake pedal and move selector to
P or N.
● Do not operate accelerator pedal.

146Driving and operatingExchanging AdBlue
If less than 5 litres of AdBlue have
been refilled during the last 2 years,
the remaining fluid should be
exchanged since AdBlue has a
limited durability. Seek the assistance of a workshop.Caution
Disregard could lead to damage to
the selective catalytic reduction
system.
Automatic transmission
The automatic transmission permits
automatic gearshifting (automatic
mode) or manual gearshifting
(manual mode).
Manual shifting is possible in manual
mode by tapping the selector lever
3 148.
Transmission display
The mode or selected gear is shown
in the transmission display.
In automatic mode, the driving
programme is indicated by D in the
Driver Information Centre.
In manual mode, M and the number
of the selected gear is indicated.
R indicates reverse gear.
N indicates neutral position.
P indicates park position.

226Vehicle careJump startingDo not start with quick charger.
A vehicle with a discharged vehicle
battery can be started using jump
leads and the vehicle battery of
another vehicle.9 Warning
Be extremely careful when starting
with jump leads. Any deviation
from the following instructions can
lead to injuries or damage caused
by battery explosion or damage to the electrical systems of both
vehicles.
9 Warning
Avoid contact of the battery with
eyes, skin, fabrics and painted
surfaces. The fluid contains
sulphuric acid which can cause
injuries and damage in the event
of direct contact.
● Never expose the battery to naked flames or sparks.
● A discharged vehicle battery canalready freeze at a temperature
of 0 °C. Defrost the frozen battery
before connecting jump leads.
● Wear eye protection and protective clothing when
handling a battery.
● Use a booster battery with the same voltage (12 Volts). Its
capacity (Ah) must not be much less than that of the discharged
battery.
● Use jump leads with insulated terminals and a cross section of
at least 16 mm 2
(25 mm 2
for
diesel engines).
● Do not disconnect the discharged
battery from the vehicle.
● Switch off all unnecessary electrical consumers.
● Do not lean over the battery during jump starting.
● Do not allow the terminals of one
lead to touch those of the other
lead.
● The vehicles must not come into contact with each other during
the jump starting process.● Apply the parking brake, transmission in neutral,
automatic transmission in P.
● Open the positive terminal protection caps of both batteries.
Lead connection order:
1. Connect the red lead to the positive terminal of the booster
battery.
2. Connect the other end of the red lead to the positive terminal of the
discharged battery.

256IndexAAccessories and vehicle modifications .......................... 188
Active head restraints ...................46
Adaptive forward lighting ....94,
116, 197
AdBlue .................................. 92, 143
Adjustable air vents ...................133
Airbag, belt tensioners and roll bars ........................................... 89
Airbag deactivation ................61, 89
Airbag label................................... 57 Airbag system .............................. 57
Air conditioning regular operation ................................ 134
Air conditioning system .............. 126
Air intake .................................... 133
Air vents...................................... 133
Antilock brake system ................ 150
Antilock brake system (ABS) .......91
Anti-theft alarm system ................26
Anti-theft locking system .............. 26
Appearance care ........................229
Armrest ......................................... 53
Armrest storage ........................... 70
Ashtrays ....................................... 83
Automatic anti-dazzle ..................30
Automatic light control ...............113
Automatic locking ........................23
Automatic transmission .............146Autostop..................................... 138
Auxiliary heater ........................... 132
B Battery discharge protection ......124
Battery voltage ........................... 103 BlueInjection ............................... 143
Bonnet ....................................... 189
Brake and clutch fluid .................234
Brake and clutch system .............90
Brake assist ............................... 152
Brake fluid .................................. 193
Brakes ............................... 150, 193
Breakdown.................................. 227
Bulb replacement ....................... 195
C Capacities .................................. 246
Car Pass ...................................... 20
Catalytic converter .....................143
Central locking system ................22
Centre console storage ...............70
Changing tyre and wheel size ...216
Charging system .......................... 89
Child restraint installation locations ................................... 64
Child restraints.............................. 62
Child restraint systems ................62
Cigarette lighter ........................... 82
Climate control ............................. 14
Climate control systems .............125
