88Instruments and controlsAirbag deactivationV illuminates yellow.
The front passenger airbag is
activated.
* illuminates yellow.
The front passenger airbag is
deactivated 3 61.9 Danger
Risk of fatal injury for a child using
a child restraint system together
with activated front passenger
airbag.
Risk of fatal injury for an adult
person with deactivated front
passenger airbag.
Charging system
p illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Stop, switch off engine. Vehicle
battery is not charging. Engine
cooling may be interrupted. The
brake servo unit may cease to be
effective. Seek the assistance of a
workshop.
Malfunction indicator light Z illuminates or flashes yellow.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Fault in the emission control system. The permitted emission limits may be exceeded. Seek the assistance of a
workshop immediately.Flashes when the engine is
running
Fault that could lead to catalytic converter damage. Ease up on the
accelerator until the flashing stops.
Seek the assistance of a workshop
immediately.
Brake and clutch system
R illuminates red.
The brake and clutch fluid level is too low 3 192.9 Warning
Stop. Do not continue your
journey. Consult a workshop.
Illuminates after the ignition is
switched on if the manual parking
brake is applied 3 149.
Operate pedal - illuminates or flashes yellow.

92Instruments and controls9Warning
When the engine is off,
considerably more force is needed
to brake and steer. During an
Autostop the brake servo unit will still be operational.
Do not remove key until vehicle is stationary, otherwise the steeringwheel lock could engage
unexpectedly.
Check oil level before seeking the
assistance of a workshop 3 189.
Low fuel
i illuminates or flashes yellow.
Illuminates
Level in fuel tank is too low.
Flashes
Fuel used up. Refuel immediately.
Never run the tank dry.
Catalytic converter 3 141.
Bleeding the diesel fuel system
3 193.
Immobiliser
d flashes yellow.
Fault in the immobiliser system. The
engine cannot be started.
Exterior light 8 illuminates green.
The exterior lights are on 3 110.
High beam
C illuminates blue.
Illuminates when high beam is on or
during headlight flash 3 112 , or when
high beam is on with high beam assist
or intelligent light range 3 114.
High beam assist
l illuminates green.
The high beam assist or intelligent light range is activated 3 112,
3 114.
Adaptive forward lighting f illuminates or flashes yellow.Illuminates
Fault in system.
Seek the assistance of a workshop.
Flashes
System switched to symmetrical low
beam.
Control indicator f flashes for approx.
4 seconds after the ignition is
switched on as a reminder that the
system has been activated 3 113.
Automatic light control 3 111.
Fog light > illuminates green.
The front fog lights are on 3 118.
Rear fog light
r illuminates yellow.
The rear fog light is on 3 118.
Cruise control
m illuminates white or green.

Driving and operating133Driving and
operatingDriving hints ............................... 134
Control of the vehicle ...............134
Steering ................................... 134
Ground clearance ....................134
Starting and operating ...............135
New vehicle running-in ............135
Ignition switch positions ...........135
Retained power off ..................135
Starting the engine ..................135
Overrun cut-off ........................ 136
Stop-start system ....................136
Parking .................................... 138
Engine exhaust .......................... 140
Diesel particle filter ..................140
Catalytic converter ...................141
AdBlue ..................................... 141
Automatic transmission ..............144
Transmission display ...............144
Selector lever .......................... 145
Manual mode ........................... 146
Electronic driving programmes 146
Fault ........................................ 147
Interruption of power supply ....147Manual transmission ..................148
Brakes ........................................ 148
Antilock brake system .............148
Parking brake .......................... 149
Brake assist ............................. 151
Hill start assist ......................... 151
Ride control systems .................151
Traction Control system ..........151
Electronic Stability Control ......152
Interactive driving system ........153
Driver assistance systems .........155
Cruise control .......................... 155
Speed limiter ........................... 157
Forward collision alert .............158
Following distance indication ...160
Parking assist .......................... 161
Side blind spot alert .................168
Rear view camera ...................170
Traffic sign assistant ................172
Lane departure warning ..........175
Fuel ............................................ 176
Fuel for petrol engines .............176
Fuel for diesel engines ............177
Refuelling ................................ 178
Fuel consumption - CO 2-
Emissions .............................. 180
Trailer hitch ................................ 181
General information .................181Driving characteristics and
towing tips .............................. 181
Trailer towing ........................... 181
Towing equipment ...................182

Driving and operating141Caution
If possible, do not interrupt
cleaning process. Drive until
cleaning is completed to avoid the need for service or repair by a
workshop.
Cleaning process not possible
If cleaning is not possible for anyreason, control indicator Z
illuminates and a warning message
appears in the Driver Information
Centre. Engine power may be
reduced. Seek the assistance of a
workshop immediately.
Catalytic converter
The catalytic converter reduces the
amount of harmful substances in the
exhaust gases.
Caution
Fuel grades other than those listed on pages 3 176, 3 240 could
damage the catalytic converter or
electronic components.
Unburnt petrol will overheat and
damage the catalytic converter.
Therefore avoid excessive use of the starter, running the fuel tank
dry and starting the engine by
pushing or towing.
In the event of misfiring, uneven
engine running, a reduction in engine performance or other unusual
problems, have the cause of the fault
rectified by a workshop as soon as
possible. In an emergency, driving
can be continued for a short period,
keeping vehicle speed and engine
speed low.
AdBlue
General information
The selective catalytic reduction
(BlueInjection) is a method to
substantially reduce the nitrogen
oxides in the exhaust emission. This
is achieved by injecting a Diesel
Exhaust Fluid (DEF) into the exhaust
system. The ammonia released by
the fluid reacts with nitrous gases
(NO x) from the exhaust and turns it
into nitrogen and water.
The designation of this fluid is
AdBlue ®
. It is a non-toxic, non-
flammable, colourless and odourless
fluid which consists of 32% urea and
68% water.9 Warning
Avoid contact of your eyes or skin
with AdBlue.
In case of eye or skin contact,
rinse off with water.

146Driving and operatingWhen a gear is engaged, the vehicle
slowly begins to creep when the
brake is released.
Engine braking To utilise the engine braking effect,
select a lower gear in good time when
driving downhill, see manual mode.
Rocking the vehicle Rocking the vehicle is only
permissible if the vehicle is stuck in
sand, mud or snow. Move the selector
lever between D and R in a repeat
pattern. Do not race the engine and
avoid sudden acceleration.
Parking Apply the parking brake and engageP .
The ignition key can only be removed
when the selector lever is in position
P .Manual mode
Move selector lever out of position D
towards the left to select manual
mode M.
Tap selector lever
forwards <:shift to a higher gearbackwards ]:shift to a lower gear
The selected gear is indicated in the
instrument cluster.
If a higher gear is selected when
vehicle speed is too low, or a lower
gear when vehicle speed is too high,
the shift is not executed. This can
cause a message in the Driver
Information Centre.
In manual mode, no automatic
shifting to a higher gear takes place
at high engine revolutions.
Electronic driving programmes
● Following a cold start, the operating temperature
programme increases engine
speed to quickly bring the
catalytic converter to the required
temperature.
● The automatic neutral shift function automatically shifts to
idling when the vehicle is stopped with a forward gear engaged andthe brake pedal is pressed.
● When SPORT mode is engaged,
the vehicle shifts at higher engine
speeds (unless cruise control is
on). SPORT mode 3 153.
● Special programmes automatically adapt the shifting
points when driving up inclines or
down hills.

258IndexAAccessories and vehicle modifications .......................... 187
Active head restraints ...................46
Adaptive forward lighting ....92,
114, 196
AdBlue .................................. 91, 141
Adjustable air vents ...................131
Airbag, belt tensioners and roll bars ........................................... 87
Airbag deactivation ................61, 88
Airbag label................................... 57 Airbag system .............................. 57
Air conditioning regular operation ................................ 132
Air conditioning system .............. 124
Air intake .................................... 131
Air vents...................................... 131
Antilock brake system ................ 148
Antilock brake system (ABS) .......89
Anti-theft alarm system ................26
Anti-theft locking system .............. 26
Appearance care ........................228
Armrest ......................................... 53
Armrest storage ........................... 70
Ashtrays ....................................... 82
Automatic anti-dazzle ..................30
Automatic light control ...............111
Automatic locking ........................23
Automatic transmission .............144Autostop..................................... 136
Auxiliary heater ........................... 130
B Battery discharge protection ......122
Battery voltage ........................... 100 BlueInjection ............................... 141
Bonnet ....................................... 188
Brake and clutch fluid .................232
Brake and clutch system .............88
Brake assist ............................... 151
Brake fluid .................................. 192
Brakes ............................... 148, 191
Breakdown.................................. 226
Bulb replacement ....................... 194
C Capacities .................................. 245
Car Pass ...................................... 20
Catalytic converter .....................141
Central locking system ................21
Centre console storage ...............70
Changing tyre and wheel size ...214
Charging system .......................... 88
Child restraint installation locations ................................... 65
Child restraints.............................. 63
Child restraint systems ................63
Cigarette lighter ........................... 82
Climate control ............................. 14
Climate control systems .............123
