In brief11
1Fixed air vents ..................... 100
2 Side air vents ........................ 99
3 Light switch .......................... 88
Turn and lane-change
signals, headlight flash,
low beam and high beam .....90
4 Instruments .......................... 67
Driver Information Centre ...... 79
5 Windscreen wiper,
windscreen washer
system, rear window
wiper/washer ........................ 62
Trip odometer reset ............... 67
6 Centre air vents .................... 99
7 Headlight range
adjustment ........................... 89
Driver Information Centre
controls ................................ 79
Trip computer ........................ 86
Instrument illumination ..........91
Hazard warning flashers .......90
Front fog lights .....................90Rear fog light ........................ 91
Heated rear window ..............31
Heated exterior mirrors .........28
8 Front passenger airbag ........44
9 Glovebox .............................. 54
10 Climate control system .......... 95
Electronic climate control
system ................................... 97
11 Selector lever, manual
transmission ....................... 107
Manual transmission
automated ........................... 108
12 Ignition switch with
steering wheel lock ............102
13 Steering wheel controls .......61
14 Horn ..................................... 62
Driver airbag ........................ 44
15 Steering wheel adjustment ..61
16 Cruise control .....................115
17 Fuse box ............................. 140
18 Bonnet release lever ..........127Exterior lighting
Turn light switch:
§=off / daytime running lights9=sidelights / headlights
Lighting 3 88, Daytime running
lights 3 89.

12In brief
Fog lights
Press light switch:
>=front fog lightsr=rear fog lightHeadlight flash, high beam and
low beamheadlight flash=pull leverhigh beam=push leverlow beam=pull lever
High beam 3 88, Headlight flash
3 88.
Turn and lane-change signalslever up=right turn signallever down=left turn signal
Turn and lane-change signals
3 90.

Instruments and controls79
One or more of the exterior lights is
faulty 3 132.
Depending on version, 9 will
illuminate as an alternative if control
indicator µ is not present. A warning
message may also be displayed in
the Driver Information Centre 3 79.
Generic warning 9 3 73.
High beam
C illuminates blue.
Illuminated when high beam is on and during headlight flash 3 88.
Fog light > illuminates green.
The front fog lights are on 3 90.
Rear fog light
r illuminates yellow.
The rear fog light is on 3 91.
Cruise control m illuminates green.The system is on.
Cruise control 3 115.
Door open
\ illuminates red.
A door or the tailgate is open.Information displays
Driver Information Centre
The Driver Information Centre is
located in the instrument cluster
between the speedometer and
tachometer. Two versions are
available; a Standard version

88LightingLightingExterior lighting............................ 88
Interior lighting ............................. 91
Lighting features ..........................94Exterior lighting
Light switch
Turn light switch:
§=off / daytime running lights9=sidelights / headlights
Control indicator 8 3 78.
Tail lights
Tail lights are illuminated together
with headlights and sidelights.
High beam
To switch from low to high beam,
push lever.
To switch to low beam, pull lever.
Headlight flash
To activate the headlight flash, pull
lever.

132Vehicle care
Wiper blade on tailgate
Lift wiper arm, press retaining clips to
detach wiper blade.
Attach the wiper blade to the wiper
arm and push until it engages.
Lower wiper arm carefully.
Bulb replacement
Switch off the ignition and switch off
the relevant switch or close the doors.
Only hold a new bulb at the base! Do not touch the bulb glass with bare
hands.
Use only the same bulb type for
replacement.
Replace headlight bulbs from within
the engine compartment.
Bulb check After a bulb replacement, switch on
the ignition, operate and check the
lights.Halogen headlights
Headlights have separate systems for low beam/sidelight 1 (outer bulb),
high beam/daytime running light 2
(inner bulb).
To access bulbs, pull off protective
covers.
Low beam 1. Remove protective cover.
2. Detach connector from bulb.
3. Disengage wire clip and remove bulb from reflector.

Vehicle care133
4.Insert new bulb in reflector so that
the locating tab of the bulb aligns
with the reflector recess.
5. Attach connector to bulb.
6. Engage wire clip.
7. Install protective cover.
High beam 1. Remove protective cover.
2. Detach connector from bulb.
3. Disengage wire clip and remove bulb from reflector.4.Insert new bulb in reflector so that
the bulb aligns with the reflector
recess.
5. Engage wire clip and attach connector onto bulb.
6. Install protective cover.
Sidelight 1. Remove protective cover. Withdraw bulb holder from
reflector by turning anticlockwise.2. Remove bulb from socket, insert new bulb.
3. Insert bulb holder in reflector. 4. Rotate clockwise to engage.
5. Install protective cover.
Daytime running light 1. Remove protective cover.

140Vehicle care
No.CircuitF09Rear door switchF10HornF14High beamF15PTCI heaterF19Air conditioning systemF20Heated rear windowF21Fuel pumpF30Fog lightsF84CNG systemF85Power outletsF86Cigarette lighter, heated seatsF87Stop-start systemF88Mirror heating
After having changed defective fuses
refit the fuse box cover.
If the fuse box cover is not closed
correctly, malfunction may occur.
Instrument panel fuse box
The fuse box is located behind a
cover on the lower part of the
instrument panel, on the driver's side.

182
HHalogen headlights ....................132
Hand brake ................................. 112
Hazard warning flashers ..............90
Headlight flash ............................. 88
Headlight range adjustment ........89
Headlights..................................... 88
Headlights when driving abroad ..89
Head restraint adjustment .............8
Head restraints ............................ 32
Heated mirrors ............................. 28
Heated rear window ..................... 31
Heating ........................................ 35
Heating and ventilation system ...95
High beam ............................. 79, 88
Hill start assist ...................... 75, 113
Horn ....................................... 13, 62
I
Identification plate .....................161
Ignition switch positions .............102
Immobiliser ............................ 26, 78
Indicators ...................................... 67
Information displays...................... 79
Instrument cluster ........................67
Instrument panel fuse box .........140
Instrument panel illumination .....138
Instrument panel illumination control ...................................... 91Instrument panel overview ........... 10
Instrument panel storage ..............53
Interior care ............................... 156
Interior lighting ........................ 79, 91
Interior lights ........................ 92, 137
Interior mirrors .............................. 28
Introduction .................................... 3
ISOFIX child restraint systems ....52
J
Jump starting ............................. 152
K Kerb weight................................... 59Keys ............................................. 19
Keys, locks ................................... 19
L
Language ..................................... 79
Lashing eyes ......................... 58, 59
Light switch .................................. 88
Load compartment ................25, 55
Load compartment cover .............55
Load compartment lighting ...........93
Loading ......................................... 55
Loading information .....................59
Low engine oil level .....................78
Low fuel ....................................... 78M
Malfunction indicator light ............74
Manual adjustment ......................27
Manual anti-dazzle ......................28
Manual mode ............................. 110
Manual transmission .................. 107
Manual transmission automated 108
Manual windows ..........................29
Mirror adjustment ........................... 8
Misted light covers .......................91
Multifunction display .....................79
N New vehicle running-in ..............101
Number plate light .....................136
O Object detection systems ...........116
Odometer ..................................... 67
Oil, engine .......................... 159, 162
Operating windows from outside ..29
Outside temperature ....................63
Overhead console .......................54
Overrun cut-off ........................... 103
P Parking ................................ 17, 105
Parking assist ............................ 116
Parking brake ............................ 112
Particulate filter ........................... 106
