phone VAUXHALL COMBO 2016 Infotainment system

Introduction.................................... 4
Radio ........................................... 24
CD Player .................................... 31
AUX input ..................................... 35
USB port ...................................... 37
Voice recognition .........................42
Phone .......................................... 50
Index ............................................ 64Contents

4IntroductionIntroductionGeneral information.......................4
Theft-deterrent feature ...................6
Control elements overview ............8
Usage .......................................... 14
Tone settings ............................... 18
Volume settings ........................... 19General information
Infotainment system The Infotainment system provides
you with state-of-the-art in-car
infotainment.
The Radio is equipped with 6 station
buttons for storing radio stations on
FM and AM wavebands, Autostore -
an automatic radio station storing
function - and Radio data system
(RDS) for enhanced reception and
traffic information.
The CD player can play audio CDs,
CD-R and CD-RW CDs and,
depending on version, also plays
MP3 CDs.
The digital sound processor provides
you with preset and user-defined
equalizer modes for sound
optimisation 1)
.
The well-thought-out design of the
control elements and the clear
displays enable you to control the
system easily and intuitively.Notice
This manual describes all options
and features available for the
various Infotainment systems.
Certain descriptions, including those
for display and menu functions, may
not apply to your vehicle due to
model variant, country
specifications, special equipment or
accessories.
Handsfree system with
multimedia
The Handsfree system is compatible
with the Radio with CD / MP3 player
and allows you to operate various
phone and audio functions with the
steering wheel controls or the Voice
recognition system.
The Handsfree system is equipped
with Bluetooth technology for mobile
phone operation, SMS text message
reader, USB Media player and is
programmed to recognise a wide
range of voice commands.
Bluetooth technology enables you to
establish a connection between a Bluetooth mobile phone and the1)
Only Radio with CD / MP3 player .

Introduction5Handsfree system, so you can
transfer phone operation to the
vehicle.
The SMS Message reader uses voice
synthesis and Bluetooth technology
to read incoming mobile phone text
messages over the vehicle speakers.
Notice
Not all Handsfree phone system
functions are supported by every
mobile phone. The possible phone functions depend on the relevant
mobile phone and network provider.
Refer to the operating instructions in your mobile phone handbook or
consult your network provider.
The Media player allows you to play
and control digital audio stored on a USB device. External data storage
devices, e.g. iPod or MP3 player can
be connected to the Media player via
the USB port.
The Voice recognition system
enables you to make and receive
phone calls, access SMS text
messages and operate the Mediaplayer using a series of voice
commands, for increased safety and
convenience.
Further external devices, e.g.
portable CD player, can also be
connected to the AUX input and
played over the Infotainment system.
Important information on
operation and traffic safety9 Warning
Drive safely at all times when
operating the Infotainment and
Handsfree systems.
If in doubt, stop the vehicle before operating.
Using this manual
● This manual describes the options and features available.
Certain controls and
descriptions, including symbols,
displays and menu functions may
not apply to your vehicle due to
model variant, country
specifications, special equipment or accessories.
● The table of contents at the beginning of this manual and
within each section shows where the information is located.
● The index will enable you to search for specific information.
● The vehicle display screens may not support your specific
language.
● Display messages and interior labelling are written in bold
letters.
Warnings and Cautions9 Warning
Text marked 9 Warning provides
information on risk of accident or
injury. Disregarding this
information may lead to injury.

Introduction131Â / MENU ............................. 54
Short press: Access menus ..14
Short press: Confirm
menu options ........................ 54
Phone - Short press:
Accept call ............................. 54
Short press: Change
phone conversation during
call ......................................... 54
Long press: Reject call,
end call .................................. 54
Message reader - Select
displayed text message ........54
2 Ã / q .................................... 54
Exit menu or return to
previous menu without
saving .................................... 54
Media player - Pause/
unpause ................................ 50
Phone - Mute/unmute
microphone during phone
conversation .......................... 50Mute ringtone for incoming calls ....................................... 50
Message reader - Interrupt
reading of a text message ....54
Voice recognition -
Interrupt a voice message ....42
Deactivate voice
recognition ............................ 42
3 s........................................... 42
Short press: Activate voice recognition ............................ 42
Short press: Interrupt a
voice message and say a
new voice command .............42
Long press: Repeat last
voice message ......................42
4 < / ] ..................................... 19
Adjust volume ....................... 19
5 R / S .................................... 54
Scroll through display
menu options ........................ 54Media player - Select tracks .. 38
Message reader - Scroll
through text messages .........54
6 SRC/OK ................................ 54
Confirm menu options ...........54
Change audio source
(radio, CD player, Media
player) ................................... 54
Phone - Transfer phone
conversation between
Handsfree system and
mobile phone ........................ 54
Message reader - Select
displayed text message ........54

Introduction17Control operations for Handsfree
system:
The Handsfree system is equipped
with steering wheel controls for
Bluetooth phone, SMS Message
reader and Media player operation and for activating Voice recognition.
Volume
Press < or ] to adjust the volume.
The current setting is shown on the
display.
Mute / pause
Press à / q to mute phone calls and
ringtones or pause the Media player.
Mute or Pause is shown on the
display.
To unmute/unpause, press à / q
again.
Notice
Adjusting the volume automatically
cancels the mute/pause function.Menus on the display screen
Access and navigate menus on the
display using the steering wheel
controls:
● Press  / MENU to access
menus.
● Press R or S to scroll through
display menu options.
● Press SRC/OK (or  / MENU ) to
confirm menu options.
● Press à / q to exit menu or
return to previous menu without saving.
Changes are saved and menus are
exited automatically after a brief
period.
Using the Handsfree phone system
3 50.
Modes of operation Use the steering wheel controls to
operate the functions of the
Handsfree system:Phone
The most important Phone functions
are operated as follows:
● Accept a phone call: Press  /
MENU .
● End or reject a phone call: Press and hold  / MENU .
● Mute microphone during a phone
conversation: Press à / q .
● Transfer phone conversation between Handsfree system and
mobile phone: Press SRC/OK.
● Change to another phone conversation during a phone call:Press  / MENU .
Using the Phone 3 54.
SMS Message reader
The most important Message reader
functions are operated as follows:
● Scroll through text messages: Press R or S.
● Select displayed text message: Press SRC/OK (or  / MENU ).
● Interrupt reading of a text message: Press à / q .
Using the Message reader 3 54.

22IntroductionIf the volume is adjusted while in
mute/pause mode, the mute/pause
function will be overridden and the
volume will be set to the new level
selected.
Notice
To access the other menus of the
Infotainment system, the Mute and
Pause functions must be
deactivated first
If an emergency or traffic
announcement is broadcast with the
mute/pause function on, the function
will be temporarily overridden, and
will be resumed at the end of the
announcement.
AUX input volume adjustment
This function enables you to align the volume of the AUX source,
depending on the portable player, to
the one of the other sources.
The volume of the external audio
source connected to the AUX input,
can only be operated via the controls
on the audio source itself. It is not
possible to adjust the volume via the
Infotainment system or the steering
wheel controls.To activate the AUX input volume
function, connect your auxiliary audio
device and ensure that it is turned off.
Using the buttons on the Infotainment
system or the steering wheel, select
the following:
● Press the MEDIA or SRC/OK
button
● Press the R or S buttons to
select the AUX mode on the
display
● Turn the auxiliary audio device on
● Press the _ or 6 buttons to
decrease or increase the volume
level
An audio source that is connected to
the AUX input can only be operated
via the controls on the audio source itself.
Speech volume
The fixed phone volume can be
adjusted by using the Speech
volume function.To activate the function using the
buttons on the Infotainment system,
select the following:
● Press the MENU button
● Press the R or S buttons to
select the Speech volume option
on the display
● Press the _ or 6 buttons to
decrease or increase the volume level
If the _ button is set to 0, the
display will show Speech off.
To adjust the preset volume, press
the < or ] buttons on the steering
wheel or press the R or S buttons on
the Infotainment system.
To temporarily adjust the preset
volume of an ongoing call or vocal
announcement in progress, press the
< or ] buttons on the steering wheel.
At the end of the call/announcement,
the volume will return to its original level.

42Voice recognitionVoice recognitionVoice recognition.........................42Voice recognition
General information
Voice recognition allows you to
operate certain functions of a paired
Bluetooth mobile phone using a
series of programmed voice
commands.
After pairing a Bluetooth mobile
phone and copying phonebook
contacts to the Handsfree system,
Voice recognition enables you to e.g.
call a contact without manually selecting the caller name or number.
Pairing a mobile phone 3 52.
It is also possible to operate the SMS Message reader and the Media
player (CD or USB device) and
change various settings using voice
commands.
Message reader 3 54.
CD player 3 31.
USB audio device 3 37.To ensure that conversations inside
the vehicle do not lead to
unintentional triggering of system
functions, Voice recognition does not
start until it has been activated.
Activating Voice recognition
To activate the Voice recognition
system:
Press s on the steering wheel.
Activation is confirmed by an audible
signal.
Deactivating Voice recognition
To deactivate the Voice recognition
system:
● Say " Cancel", or
● Press à / q , or
● Do not say a voice command after activating the system.
Deactivation is confirmed by an
audible signal.

44Voice recognitionVoice commandsNotice
When the vehicle is stationary, all
voice commands are available
within the current menu.
While driving, the list of available
voice commands is reduced, for
safety reasons.
If the SETTINGS menu is activated
during driving, it can only be
operated using voice commands.
Phone voice commands
To access the phone voice
commands menu:
1. Press s and wait for the audible
signal.
2. Say " Telephone ".
The following list of recognised voice
commands can then be used:
● Call
● Dial
● Redial
● Call backTo call a phonebook contact:
1. Press s and say " Telephone ".
2. Say " Call".
3. Say the contact name, e.g. "Mark".
4. If prompted by a system message, specify " Work",
" Home ", "Mobile " or "Other ".
5. A system message will ask you to
confirm your choice.
Say " Yes" to confirm or say " No"
to cancel the operation.
6. Say " Call" to start the dialling
process.
If the specific phone number for the
contact is not recognised, the system will display a suggestion. Say " Next"
or " Previous " to show other phone
numbers for this contact.
When the correct phone number is
shown on the display, say " Call" to
start the dialling process.
To dial a phone number: 1. Press s and say " Telephone ".
2. Say " Dial".3. After the system message, enter
the desired phone number using
the following voice commands:
● Say " Zero" (inserts the
numeral 0).
● Say " One" through to " Nine"
(inserts numerals 1 - 9).
● Say " Plus" (inserts the +
symbol).
● Say " Star" (inserts the *
symbol).
● Say " Hash" (inserts the #
symbol).
4. The phone number is repeated by
the system and also shown on the
display.
(Say " Repeat " to repeat the
telephone number entered and
recognised by the Handsfree
system).
5. Check the phone number entered
is correct and modify it if
necessary.
(Say " DELETE " to delete the last
digits entered).
6. Say " Dial" to start the dialling
process.

Voice recognition45To dial an international phone
number, enter the international
dialling code first, e.g. +44 for UK:
● Say " Plus" (+), or
● Say " Zero Zero " (00 ) followed by
the international dialling code.
To redial the last dialled telephone number:
1. Press s and say " Telephone ".
2. Say " Redial".
3. A system message will ask you to
confirm your choice.
Say " Yes" to confirm and start the
dialling process or say " No" to
cancel the operation.
To call back the last received
telephone number:
1. Press s and say " Telephone ".
2. Say " Call".
3. A system message will ask you to
confirm your choice.
Say " Yes" to confirm and start the
dialling process or say " No" to
cancel the operation.For further information on Phone
functions, refer to Operation in the
Phone section 3 54.
Message reader voice commands
When the Handsfree system signals
the arrival of a new text message, the system can read out the message:
● Say " Yes" to read the message.
- or -
● Say " No" to ignore the message
and save it in the Inbox.
The Message reader must be
switched on to receive any
notification of an incoming text
message (see SIGNAL TYPE menu
options below).
To access the Message reader voice
commands menu:
1. Press s and wait for the audible
signal.
2. Say " MESSAGE READER ".
The following list of recognised voice
commands can then be used:
● Read last one
● INBOX●Delete all
● SIGNAL TYPE
● Exit
To read the last received text
message:
1. Press s and say " MESSAGE
READER ".
2. Say " Read last one ".
The voice recognition system is
deactivated automatically after the
message is read and the text
message remains in the Inbox.
To access the text messages in the
Inbox:
1. Press s and say " MESSAGE
READER ".
2. Say " INBOX" to access the text
message Inbox. The system will
display the first message in the
Inbox.
3. Say " Next" to move to the next
message.
Say " Previous " to move to the
previous message.
4. Say " Read" to read the currently
selected text message.

46Voice recognitionSay "Re-read " to repeat the
currently selected text message.
Say " Call" to dial the sender of the
currently selected text message.
Say " DELETE " to delete the
currently selected text message.
To delete all text messages: 1. Press s and say " MESSAGE
READER ".
2. Say " Delete all " to delete all of the
messages in the Inbox.
3. A system message will ask you to
confirm your choice.
Say " Yes" to confirm or say " No"
to cancel the operation.
To change how you are notified of an incoming text message:
1. Press s and say " MESSAGE
READER ".
2. Say " SIGNAL TYPE " to access
the following notification options:
3. Say " Reader off " to deactivate the
SMS Message reader. When a
new SMS text message arrives on your mobile phone, you will not be
notified by the Handsfree system.or
Say " Visual and acoustic signal ".
The Handsfree system signals the
arrival of a new text message via
the display and with an acoustic
signal.
or
Say " Visual signal only ". The
arrival of a new text message is
signalled via the display only.
To exit the SMS text Message reader:
Press s and say " Exit".
For further information on Message
reader functions, refer to Operation in
the Phone section 3 54.
Media player voice commands To change the audio source to Mediaplayer:
1. Press s and wait for the audible
signal.
2. Say " Player".Press button s each time before
saying any of the following
recognised voice commands:
● Say " Play"
(plays the audio tracks)
● Say " Stop"
(stops playing the audio tracks)
● Say " Next"
(moves to the next track)
● Say " Previous"
(moves to the previous track)
● Say " SHUFFLE "
(plays tracks in a random order)
Press s and say " SHUFFLE "
again to switch function on/off.
● Say " Loop"
(plays the same audio tracks
continuously)
Press s and say " Loop" again to
switch function on/off.
● Say " FOLDERS "
(allows you to select folders and
play all tracks in the folders on
your USB device)
