Vehicle care191
4. Remove the bulb by pushingslightly into the socket and
rotating anticlockwise. Replace
the bulb.
5. Insert the bulb socket into the assembly and turn to secure.
6. Attach light assembly into the tailgate and secure with the
screw.
Side turn signal lights
To replace bulb, remove lamp
housing:
1. Slide lamp to its left side and remove with its right end.
2. Turn bulb holder anticlockwiseand remove from housing.
3. Pull bulb from bulb holder and replace it.

192Vehicle care
4. Insert bulb holder and turnclockwise.
5. Insert left end of the lamp, slide to
the left and insert right end.
Centre high-mounted
brake light Have LEDs replaced by a workshop.
Number plate light
1. Insert screwdriver in recess of the
cover, press to the side and
release spring.
2. Remove lamp downwards, taking care not to pull on the cable.
3. Remove bulb holder from lamp housing by turning anticlockwise.
4. Pull bulb from bulb holder andreplace it.
5. Insert bulb holder into lamp housing and turn clockwise.
6. Insert lamp into bumper and let engage.
Interior lights Courtesy light, reading lights
Have bulbs replaced by a workshop.
Load compartment light Have bulbs replaced by a workshop.
Dome light
Have bulbs replaced by a workshop.
Instrument panel
illumination
Have bulbs replaced by a workshop.

242IndexAAccessories and vehicle modifications .......................... 176
Adjustable air vents ...................126
Airbag and belt tensioners ...........88
Airbag deactivation ................46, 88
Airbag label................................... 41 Airbag system .............................. 41
Air conditioning regular operation ................................ 127
Air conditioning system .............. 119
Air intake .................................... 127
Air vents...................................... 126
Antilock brake system ................ 143
Antilock brake system (ABS) .......89
Anti-theft alarm system ................26
Anti-theft locking system .............. 26
Appearance care ........................219
Ashtrays ....................................... 81
Automatic anti-dazzle ..................29
Automatic light control ...............109
Automatic locking ........................24
Automatic transmission .............136
Autostop ....................................... 92
B Battery discharge protection ......117
Battery voltage ........................... 103 Belts.............................................. 38Bicycle rack .................................. 58
Bonnet ....................................... 178
Brake and clutch fluid .................223
Brake and clutch system .............89
Brake assist ............................... 144
Brake fluid .................................. 181
Brakes ............................... 143, 181
Breakdown.................................. 217
Bulb replacement ....................... 184
C Capacities .................................. 236
Car Pass ...................................... 20
Catalytic converter .....................135
Central locking system ................22
Centre high-mounted brake light 192
Changing tyre and wheel size ...205
Charging system .......................... 88
Child locks ................................... 24
Child restraint installation locations ................................... 50
Child restraints.............................. 48
Child restraint systems ................48
Cigarette lighter ........................... 81
City mode ................................... 146
Climate control ............................. 15 Climate control systems .............118
Clock ............................................ 79
Code ........................................... 100
Colour-Info-Display .......................98
