84Instruments and controlsEngine coolant
temperature gauge
Number of LEDs displays the coolant temperature.
up to 3 LEDs=engine operating
temperature not
yet reached4 to 6 LEDs=normal operating
temperaturemore than 6
LEDs=temperature too
highCaution
If engine coolant temperature is
too high, stop vehicle, switch off
engine. Danger to engine. Check
coolant level.
Service display
The engine oil life system lets you
know when to change the engine oil
and filter. Based on driving
conditions, the interval at which an
engine oil and filter change will be
indicated can vary considerably.
To display the remaining engine oil
life duration use turn signal lever
buttons:
Press the MENU button to select the
Vehicle Information Menu .
Turn the adjuster wheel to select Remaining Oil Life .

100Instruments and controls
To exit the Settings menu, press
button BACK in steps or press button
CONFIG after confirming the
changes.
Vehicle personalisation 3 103.
Memorised settings 3 22.Vehicle messages
Messages are indicated mainly in the
Driver Information Centre (DIC), in
some cases together with a warning
and signal buzzer.
Press the SET/CLR button, the
MENU button or turn the adjuster
wheel to confirm a message.
Vehicle messages on Base- and
Midlevel-Display
The vehicle messages are displayed
as code numbers.
No.Vehicle message1Change engine oil3Engine coolant level low4Air conditioning off5Steering wheel is locked7Turn steering wheel, switch
ignition off and then on

132Driving and operating
Indication
An Autostop is indicated by control
indicator D.
During an Autostop, the heating and
brake performance will be
maintained.
Conditions for an Autostop
The stop-start system checks if each
of the following conditions is fulfilled:
■ The stop-start system is not manually deactivated.
■ The bonnet is fully closed.
■ The driver's door is closed or the driver's seat belt is fastened.
■ The vehicle battery is sufficiently charged and in good condition.
■ The engine is warmed-up.
■ The engine coolant temperature is not too high.
■ The engine exhaust temperature is
not too high, e.g. after driving with
high engine load.
■ The ambient temperature is above -5 °C.
■ The climate control system allows an Autostop.
■ The brake vacuum is sufficient.
■ The self-cleaning function of the diesel particle filter is not active.
■ The vehicle was driven at least at walking speed since the last
Autostop.
Otherwise an Autostop will be
inhibited.
Certain settings of the climate control
system may inhibit an Autostop. See
'Climate control' chapter for further
information 3 121.
Immediately after motorway driving
an Autostop may be inhibited.
New vehicle running-in 3 129.Vehicle battery discharge protection
To ensure reliable engine restarts, several vehicle battery discharge
protection features are implemented
as part of the stop-start system.
Power saving measures
During an Autostop, several electrical
features, e.g. the rear window
heating, are disabled or switched into
a power saving mode. The fan speed of the climate control system is
reduced to save power.
Restart of the engine by the
driverVehicles with manual transmission
Depress the clutch pedal to restart the
engine.
When the engine is restarted, control
indicator D in the Driver Information
Centre (DIC) extinguishes.
If the selector lever is shifted out of
neutral before depressing the clutch
pedal first, control indicator -
illuminates or is shown as a symbol in
the DIC.
Control indicator - 3 89.

176Vehicle careVehicle careGeneral Information...................176
Vehicle checks ........................... 177
Bulb replacement .......................184
Electrical system ........................193
Vehicle tools .............................. 198
Wheels and tyres .......................199
Jump starting ............................. 215
Towing ....................................... 217
Appearance care .......................219General Information
Accessories and vehicle
modifications
We recommend the use of genuine parts and accessories and factory
approved parts specific for your
vehicle type. We cannot assess or
guarantee reliability of other products
- even if they have a regulatory or
otherwise granted approval.
Do not make any modifications to the electrical system, e.g. changes of
electronic control units (chip tuning).Caution
When transporting the vehicle on
a train or on a recovery vehicle, the
mud flaps may be damaged.
Vehicle storage
Storage for a long period of time If the vehicle is to be stored for severalmonths:
■ Wash and wax the vehicle.
■ Have the wax in the engine compartment and underbody
checked.
■ Clean and preserve the rubber seals.
■ Fill up fuel tank completely.
■ Change the engine oil.
■ Drain the washer fluid reservoir. ■ Check the coolant antifreeze and corrosion protection.
■ Adjust tyre pressure to the value specified for full load.
■ Park the vehicle in a dry, well ventilated place. Engage first orreverse gear or set selector lever to P . Prevent the vehicle from rolling.
■ Do not apply the parking brake.

Vehicle care177
■ Open the bonnet, close all doorsand lock the vehicle.
■ Disconnect the clamp from the negative terminal of the vehicle
battery. Beware that all systems are
not functional, e.g. anti-theft alarm
system.
Putting back into operation
When the vehicle is to be put back into
operation:
■ Connect the clamp to the negative terminal of the vehicle battery.
Activate the electronics of the
power windows.
■ Check tyre pressure.
■ Fill up the washer fluid reservoir.
■ Check the engine oil level.
■ Check the coolant level.
■ Fit the number plate if necessary.End-of-life vehicle
recovery
Information on end-of-life vehicle
recovery centres and the recycling of
end-of-life vehicles is available on our website. Only entrust this work to an
authorised recycling centre.
Gas vehicles must be recycled by a
service centre authorised for gas
vehicles.Vehicle checks
Performing work9 Warning
Only perform engine compartment
checks when the ignition is off.
The cooling fan may start
operating even if the ignition is off.

180Vehicle careCaution
Overfilled engine oil must be
drained or suctioned out.
Capacities 3 236, Engine oil quality/
viscosity 3 223.
Fit the cap on straight and tighten it.
Engine coolant The coolant provides freeze
protection down to approx. -28 °C. In
northern countries with very low
temperatures the factory filled coolant
provides frost protection down to
approx. -37 °C.
Caution
Only use approved antifreeze.
Coolant levelCaution
Too low a coolant level can cause engine damage.
Different coolant reservoirs are used
depending on engine variant.
If the cooling system is cold, the
coolant level should be above the
filling line mark.
Top-up if the level is low.

Vehicle care1819Warning
Allow the engine to cool before
opening the cap. Carefully open
the cap, relieving the pressure
slowly.
To top up use a 1:1 mixture of
released coolant concentrate mixed
with clean tap water. If no coolant
concentrate is available, use clean
tap water. Install the cap tightly. Have
the coolant concentration checked
and have the cause of the coolant
loss remedied by a workshop.
Washer fluid
Fill with clean water mixed with a
suitable quantity of windscreen
washer fluid which contains
antifreeze.
Caution
Only washer fluid with a sufficient
antifreeze concentration provides
protection at low temperatures or
a sudden drop in temperature.
Brakes
In the event of minimum thickness ofthe brake lining, a squealing noise
sounds during braking.
Continued driving is possible but
have the brake lining replaced as
soon as possible.
Once new brake linings are installed,
do not brake unnecessarily hard for
the first few journeys.
Brake fluid9 Warning
Brake fluid is poisonous and
corrosive. Avoid contact with eyes, skin, fabrics and painted surfaces.

224Service and maintenance
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 227.
Additional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.
Engine oil viscosity grades
The SAE viscosity grade gives
information of the thickness of the oil.
Multigrade oil is indicated by two
figures, e.g. SAE 5W-30. The first
figure, followed by a W, indicates the
low temperature viscosity and the
second figure the high temperature viscosity.
Select the appropriate viscosity grade
depending on the minimum ambient
temperature 3 227.
All of the recommended viscosity
grades are suitable for high ambient
temperatures.Coolant and antifreeze
Use only silicate-free long life coolant
(LLC) antifreeze. Consult a
workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -28 °C. In
northern countries with very low
temperatures the factory filled coolant
provides frost protection down to
approx. -37 °C. This concentration
should be maintained all year round.
The use of additional coolant
additives that intend to give additional corrosion protection or seal against
minor leaks can cause function
problems. Liability for consequences
resulting from the use of additional
coolant additives will be rejected.
Brake and clutch fluid Over time, brake fluid absorbs
moisture which will reduce braking
effectiveness. The brake fluid should
therefore be replaced at the specified
interval.

243
Control indicators.......................... 85
Control of the vehicle .................128
Controls ........................................ 74
Convex shape .............................. 28
Coolant and antifreeze ...............223
Corner lighting ............................ 111
Cruise control ...................... 92, 147
Cupholders .................................. 56
Curtain airbag system .................. 46
D Danger, Warnings and Cautions ...3
Daytime running lights ...............110
Declaration of conformity ............239
Diesel fuel system bleeding .......184
Diesel particle filter ...............91, 134
Door open .................................... 93
Doors ............................................ 25
Driver assistance systems ..........147
Driver Information Centre .............93
Driving characteristics and towing tips .............................. 171
Driving hints ................................ 128
E Easy entry..................................... 37
Electric adjustment ......................28
Electrical system......................... 193
Electronic climate control system 121Electronic driving programmes .
........................................ 138, 142
Electronic Stability Control.......... 145
Electronic Stability Control and Traction Control system ............90
End-of-life vehicle recovery .......177
Engine compartment fuse box ...194
Engine coolant ........................... 180
Engine coolant temperature gauge ....................................... 84
Engine data ............................... 230
Engine exhaust .......................... 134
Engine identification ...................226
Engine oil ................... 178, 223, 227
Engine oil pressure ......................91
Entry lighting .............................. 116
Event data recorders ..................240
Exit lighting ................................ 116
Exterior care .............................. 219
Exterior light ................................. 92
Exterior lighting ....................12, 108
Exterior mirrors ............................. 28
F
Fault ................................... 138, 143
First aid ......................................... 71
First aid kit ................................... 71
Fixed air vents ........................... 126
Flex-Fix system ............................ 58
Fog light ....................................... 92Fog lights ................................... 188
Folding mirrors ............................. 28
Following distance indication ......152
Forward collision alert................. 150
Front airbag system .....................44
Front fog lights ........................... 113
Front seats.................................... 35
Front storage ................................ 57
Front turn signal lights ...............188
Fuel............................................. 168
Fuel consumption - CO 2-
Emissions ............................... 170
Fuel for diesel engines ..............169
Fuel for petrol engines ...............168
Fuel gauge ................................... 83
Fuses ......................................... 193
G Gauges ......................................... 82
Gear shifting ................................. 89
General information ...................171
Glovebox ..................................... 56
Graphic-Info-Display .....................99
H
Halogen headlights ....................184
Hand brake ......................... 143, 144
Hazard warning flashers ............112
Headlight flash ........................... 109
Headlight range adjustment ......110
